Freelap Tx Pad Pro Quick Start Manual

Further information
Battery and battery life
The Tx Pad Pro has a 3.7V 320mAH LiPo rechargeable battery.
• Low battery indicator: When the battery becomes low, the LED flashes red.
• Recharging the battery:
- Insert the magnetic USB cable into the USB port located on the side of the transmitter.
- It is recommended to make complete charges (charging time: 2h).
- When the battery is fully charged, the device has a battery life of 300h.
- The Tx Pad Pro has an automatic shutdown function (after 12h), to save the battery.
Technical sheet
• Weight: 130 g
• Dimensions: 170 x 100 x 15 / 3 mm
• Start zone dimension: Diameter 30 mm
• Compatibility: FxChip / FxChip BLE
• Transmitter with 1 code: START
• Detection field: 1.5 meters
• Minimum time between 2 transmitters: 0,7 second
• Accuracy: 1/100 of a second
• Battery: 3.7V 320mAH LiPo rechargeable battery, automatic shutdown after 12h
• Battery life: 300 hours
• Water resistance: IP67
• Operating temperatures: -20°C to +50°C
Technical support
Find our FAQ (Frequently Asked Questions), as well as other manuals and user guides,
on our website at: www.freelap.com/support
If you cannot find the answers to your questions, please contact your Freelap dealer.
Find the list of Freelap dealers at: www.freelap.com/freelap-contact
After-sales service & warranty
The Tx Pad Pro is guaranteed 2 years. If you have any questions or if you need
assistance with your device, please contact your Freelap dealer.
FREELAP SA
Av. D.-Jeanrichard 2A CH-2114 Fleurier – Switzerland
+41 32 861 52 42 - www.freelap.com
@freelap
Tx Pad Pro
V060623
