Summary of Contents for Hans Grohe Vivenis 75445 7 Series
- Page 1 ZH 用户手册 ⁄组装说明 EN Instructions for use ⁄Assembly instructions Vivenis 75445XX7...
- Page 2 中文 安全技巧 符号说明 装配时为避免挤压和切割受伤, 必须戴上手套. 请勿使用含有乙酸的硅胶! 本产品只允许作为洗浴, 卫生和洁身之用. 调节 (参见第页 5) 不得让儿童和肢体, 精神和/或意识有障碍的成人在不受监管的情况下使 用淋浴系统. 受酒精或毒品影响的人员不得使用淋浴系统. 热水温度调节. 如果使用即热式喷头, 则不建议安装热水阀门. 必须避免让身体敏感部位 (如眼睛) 接触到莲蓬头喷水. 必须保持莲蓬头 与人头之间有足够的距离. 保养 (参见第页 7) 该产品不得作扶柄使用. 必须安装单独的扶柄. 冷热水管间过大的压力差必须予以平衡. 单向阀必须在符合国家或当地的法律的情况下按照EN 806-5定期检查 (至 少一年一次). 安装提示 大小 (参见第页 10) • 安装前必须检查产品是否受到运输损害. 安装后将不认可运输损害或表 面损伤. 流量示意图 (参见第页 10) • 管道和阀门必须根据通用标准进行安装, 冲洗和检查. • 请遵守当地国家现行的安装规定. 备用零件 (参见第页 11) • 首次调试时和维护作业之后, 管接头中的空气可能产生噪音. 大约使用管 接头 15 次后噪音消失. XX = 颜色代码 • 必须装上花洒所附带的滤网密封垫, 以过滤管道里的杂质污物. 杂质污物 00 = 镀铬 会影响花洒的功能和/或损坏花洒的功能部件, 由此而产生的产品损坏不 67 = Matt Black 属于汉斯格雅的保修范围.
- Page 3 English Safety Notes Symbol description Gloves should be worn during installation to prevent crushing and cutting Do not use silicone containing acetic acid! injuries. Adjustment (see page 5) The product may only be used for bathing, hygienic and body cleaning purposes. To adjust the hot water limiter. Using a hot water limiter in combination with a Children as well as adults with physical, mental and/or sensoric impairments continuous flow water heater is not recommended. must not use this product without proper supervision. Persons under the influence Maintenance (see page 7) of alcohol or drugs are prohibited from using this product. Do not allow the streams of the shower touch sensitive body parts (such as your The check valves must be checked regularly according to EN 806-5 in accordance eyes). An adequate distance must be kept between the shower and you. with national or regional regulations (at least once a year). The product may not be used as a holding handle. A separate handle must be Dimensions (see page 10) installed. The hot and cold supplies must be of equal pressures. Flow diagram (see page 10) Installation Instructions Spare parts (see page 11) • Prior to installation, inspect the product for transport damages. After it has been installed, no transport or surface damage will be honoured. XX = Colors • The pipes and the fixture must be installed, flushed and tested as per the 00 = Chrome Plated applicable standards.
- Page 4 10452187 Service (M10x35) SW 8 mm SW 1,5 mm > 2 min SW 1,5 mm (1 Nm)
- Page 5 60 °C 10 °C 0,3 MPa SW 2,5 mm 36°C 60°C 38°C 55°C 43°C 50°C 开 / open 关 / close 热 / hot 冷 / cold...
-
Page 6: Warranty
English Cleaning Recommendation for Hansgrohe Products Today, modern sanitary and kitchen tapware, showers, accessories, washstands, tubs and radiators consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and reclamations, it is necessary to consider certain criteria when cleaning. - Page 7 > 1 min > 1 min...
- Page 8 180° SW 8 mm 180° SW 6 mm SW 6 mm (6 Nm)
- Page 9 180° (M10x35) SW 8 mm...
- Page 10 Vivenis 75445XX7 2 4 6 2 3 6 max. 115 12 4 Ø 4 4 Ø 12 4 min. 70 R p 1 / 2 Ø 14 8 Vivenis 75445XX7 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00...
- Page 11 Vivenis 94277XX0 75445XX7 93735460 (75445000) (M5x5) 94027XX0 93735610 SW 2,5 mm (75445700) 93735700 93995000 92114000 (75445700) (M37x1,5) (35x1,5) SW30 mm 95008000 93895000 94409XX7 98186000 (30x2) 97981XX0 93339007 97979XX0 94246000 96295XX0 97978000 (M3x12) SW 1,5 mm 93916000 28282XX0 98058000 94038XX0 98162000 (44x2,5) 97670000 93882000 (60 mm) 98162000 (44x2,5) 98371000 98419000...
- Page 12 Hansgrohe · Auestraße 5 – 9 · D-77761 Schiltach · Telefon +49 (0) 78 36/51-1282 · Telefax +49 (0) 7836/511440 E-Mail: info@hansgrohe.com · Internet: www.hansgrohe.com...
