- Page 1 Quality Changes the World Motor Grader SMG200 Safety, Operation & Maintenance Manual...
- Page 2 Find manuals at https://best-manuals.com...
- Page 3 SMG200 Motor Grader SMG200 Motor Grader Operation & Maintenance Manual WARNING Read and understand all safety precautions and instructions in this manual before reading any other manuals provided with this machine and before operating or maintaining it. Failure to do...
- Page 4 Scan here to download the Service Cloud APP Android ©2016 by Sany Group. All rights reserved. No part of this publication may be reproduced, used, distributed or disclosed except during normal operation of the machine as described herein. All information included within this publication was accurate at the time of publication.
- Page 5 Information in this manual is used to guide qualified operators to operate and maintain graders cor- rectly. Sany expressly bears no liability for any consequence due to any use not observing the in- formation in this manual.
- Page 6 • Ensure the operators are trained and fully understand the Safety, Operation and Maintenance Manual supplied by Sany. Ensure they are in physical fitness and have the certification of opera- tion. Otherwise, it is forbidden to operate the grader. •...
- Page 7 Table of Contents SMG200 Motor Grader Table of Contents 1 Introduction........................1-1 1.1 About This Manual ........................1-3 1.2 Contact Information ......................1-4 1.3 Your Documentation Package.....................1-4 1.3.1 Introduction........................1-4 1.3.2 Safety, Operation & Maintenance Manual ..............1-4 1.3.3 Parts Book ........................1-4 1.4 Your Sany Machine.......................1-5 1.4.1 Directional Reference of the Machine ...............1-5...
- Page 8 Table of Contents SMG200 Motor Grader 2.4.1 Introduction......................... 2-18 2.4.2 Lockout/Tagout Procedures ..................2-20 2.4.3 Clean the Machine ....................2-20 2.4.4 Fluid Systems......................2-20 2.4.5 Electrical System ....................... 2-22 2.4.6 Environmental Precautions..................2-23 2.5 Machine Decals........................2-23 3 System Functions......................3-1 3.1 Main Body Components.......................3-5...
- Page 9 Table of Contents SMG200 Motor Grader 3.4.5 Radio/MP3 Player ..................... 3-45 3.5 Monitor..........................3-50 3.5.1 Initialization Screens ....................3-50 3.5.2 Main Menu Screen ....................3-51 3.5.3 Operating System Screens ..................3-57 4 Operation..........................4-1 4.1 New Machine Run-In ......................4-5 4.2 Pre-Start Checks........................4-6 4.2.1 Introduction........................4-6...
- Page 10 5.1.1 Introduction........................5-5 5.1.2 Checks Before Maintenance..................5-5 5.1.3 Checks After Maintenance or Repairs...............5-6 5.1.4 Hour Meter Reading.....................5-6 5.1.5 Genuine Sany Replacement Parts ................5-7 5.1.6 Sany-Approved Lubricants..................5-7 5.1.7 Weld, Drill, Cut or Grind on the Machine..............5-7 5.1.8 Clean Parts or the Machine..................5-8 5.1.9 Covers and Locks......................5-8...
- Page 11 Table of Contents SMG200 Motor Grader 5.3.2 Location, Capacity and Type ................... 5-14 5.3.3 Fuel..........................5-15 5.3.4 Engine Oil Viscosity/Temperature Data ..............5-16 5.3.5 Engine Oil Viscosity/Temperature Data (Continued)..........5-17 5.3.6 Lubricating Grease/Temperature Data..............5-17 5.3.7 Industrial Gear Oil/Temperature Data ..............5-18 5.3.8 Hydraulic Oil/Ambient Temperature Data ..............
- Page 12 SMG200 Motor Grader Safety, Operation and Maintenance Manual-January 2017...
-
Page 13: Table Of Contents
SMG200 Motor Grader Introduction Introduction 1 Introduction........................1-1 1.1 About This Manual ........................1-3 1.2 Contact Information ......................1-4 1.3 Your Documentation Package.....................1-4 1.3.1 Introduction ........................1-4 1.3.2 Safety, Operation & Maintenance Manual...............1-4 1.3.3 Parts Book........................1-4 1.4 Your Sany Machine.......................1-5 1.4.1 Directional Reference of the Machine..............1-5 1.4.2 Serial Number Location....................1-5... - Page 14 Introduction SMG200 Motor Grader WARNING Read and understand all safety precautions and instructions in this manual before reading any other manuals provided with this machine and before operation or maintaining it.Failure to do this could result in death or serious injury.
-
Page 15: Introduction
Continuing improvements in the design of this machine can lead to changes in detail which may not be covered in this manual. Always consult your Sany dealer for the latest avail- able information on your machine or if you have questions regarding information in this manual. -
Page 16: Contact Information
Introduction SMG200 Motor Grader 1.2 Contact Information Thank you for purchasing a Sany machine. If you need to contact us for any reason, you can reach us as follows: Sany Industry Town, Economic and Techno- logical Z one, Changsha, Hunan, China 410100 E-mail: crd@sany.com.cn... -
Page 17: Your Sany Machine
A. Front C. Left side B. Back (rear) D. Right side 1.4.2 Serial Number Location The data plate (a) includes information that will be needed by your Sany dealer when or- dering replacement parts or providing assis- tance your machine. Record this information in this manual for future use. - Page 18 Introduction SMG200 Motor Grader Fig.1-4 Safety, Operation and Maintenance Manual-January 2017...
-
Page 19: Record Of Serial Number And Dealer Information
This location is for you to record information relating to your machine. It is required that you keep this manual with your machine at all times for reference. Model No. SMG200 T3 Motor Grader Machine Serial Number Engine Serial Number Transmission Serial Number Rear Axle Serial Number Right Tandem Case Serial No. -
Page 20: Cab Interior
Introduction SMG200 Motor Grader 1.4.4 Cab Interior Fig.1-5 1. Seat 6. Steering wheel 2. Clutch pedal 7. Brake pedal 3. Control levers 8. Accelerator pedal 4. Console 9. Gear selector 5. Display 10. Key switch Safety, Operation and Maintenance Manual-January 2017... -
Page 21: Correction Request
SMG200 Motor Grader Introduction 1.5 Correction Request If you find a problem with this manual, please email techpubs@sanyamerica. com with the page (s) where the problem was found and a description of the problem. Safety, Operation and Maintenance Manual-January 2017... - Page 22 Introduction SMG200 Motor Grader 1-10 Safety, Operation and Maintenance Manual-January 2017...
- Page 23 SMG200 Motor Grader Safety Safety 2 Safety.............................2-1 2.1 Safety - General ........................2-5 2.1.1 Introduction ........................2-5 2.1.2 Hazard Alerts in This Manual ..................2-5 2.1.3 Operator Safety Information ..................2-7 2.1.4 Mount and Dismount the Machine................2-8 2.2 Machine Safety........................2-9 2.2.1 Authorized Use of the Machine .................2-9 2.2.2 Unauthorized Use of the Machine ................2-9...
- Page 24 Safety SMG200 Motor Grader 2.5 Machine Decals........................2-23 Safety, Operation and Maintenance Manual-January 2017...
- Page 25 Safety SMG200 Motor Grader Safety, Operation and Maintenance Manual-January 2017...
- Page 26 Safety SMG200 Motor Grader WARNING Read and understand all safety precautions and instructions in this manual before reading any other manuals provided with this machine and before operation or maintaining it.Failure to do this could result in death or serious injury.
- Page 27 SMG200 Motor Grader Safety 2.Safety 2.1 Safety - General 2.1.1 Introduction This section of the manual provides detailed information on basic safety precautions and preventative measures to be followed during operation and maintenance of this machine. 2.1.2 Hazard Alerts in This Manual...
- Page 28 This symbol is used within a graphic to alert the user not to do something. Sany cannot foresee every circumstance that might involve a potential hazard in operation or maintenance. Therefore, some hazard alerts in this manual and on the machine may not include all possible safety precautions.
- Page 29 Any faults found shall be reported to your Sany dealer. Stop all work immediately if any operator aid is found to not be working properly.
- Page 30 Safety SMG200 Motor Grader beforeoperating this machineor performing maintenance on it. • Inspect the maintenance log before the start of each workday shift. Ensure that routine maintenance has been performed as stated in this manual. Do not operate a damaged or poorly maintained machine.
- Page 31 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...
