Product Description:

Front Panel
1. Volume Control Knob
2. Play/Pause
3. Next +
4. Bass Control Knob
5. Microphone Input
Back Panel
A : AUDIO INPUT (AUX) - STEREO INPUT
• These jacks are used to receive the STEREO signal
from a CD/DVD (2CH) Player
• You can also use the included RCA to 3.5mm cable
to and connect the other end of the cable to the input
audio source
1
6
7
8
4
5
AUDIO INPUT (AUX)
STEREO INPUT
6. Input Mode
7. Prev-
8. USB Port
IS 616 : 2017/
IEC 60065 : 2014
Tower Speak er
LEGEND
Input Power : AC 220-240V 50/60Hz
Output Power (RMS) : 80W
R-81008958
www.bis.gov.in
www.zebronics.com
