SPECIFICATIONS:
Gas fired boiler Super Steamer, Vulcan-Hart Model No. (VHL2G)
(VHL3G). 6 psi pressure steam cooker. Cooker body is 8 gauge
satin finish type 304 stainless steel exterior. Doors have a
removable aluminum alloy inner liner with full perimeter gasket
and sealed by turning a "T" type handle. The door cannot be
opened while the steamer is on. Automatic timed compartment
controls with 60 minute timer, add the suffix "S" to the model
number. Lift-out stainless steel wire Adapt-A-Pan
eight 2 1 / ", six 4", or four 6" deep food pans (one for 2 compart-
2
ments)(two for 3 compartments) and one manual pull out shelf.
Water fall compartments interior bottom to lip out at front.
Steamer mounted on 28" high base cabinet with stainless steel
frame, front full height doors, slip-off stainless steel side and
aluminized rear panel with 6" adjustable legs with flanged feet for
anchoring. 270,000 BTU/hr. high efficiency steam boiler with
electronic ignition builds 5.5 BHP. Includes CSD-1 compliant high
pressure limit switch (15 psi), low water cut-off, automatic water
fill, automatic boiler blowdown, 15 psi pressure relief valve and
15 psi kettle connection. Service connections include: 1" gas
1
connection, / " water connection for boiler feed and
2
condenser, 120 volt control circuit and 1
Exterior dimensions:
7
VHL2G: 36"w x 35 / "d x 65"h.
16
VHL3G: 36"w x 35 7 / "d x 80"h.
16
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
CSA design certified. Classified by U L to NSF Std. #4. Meets
ASME code.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32425 (8-04)
TM
supports
1
/ " cold water
2
1
/ " drain connection.
4
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
VHLG SERIES
SUPER STEAMER, HIGH EFFICIENCY GAS BOILER
TWO OR THREE COMPARTMENT MODELS
VHL2G (S) (P) 2 compartments
VHL3G (S) (P) 3 compartments
STANDARD FEATURES
6 psi pressure steam cooker.
Cooker body is 8 gauge satin finish type 304 stainless steel
exterior. Doors have a removable aluminum alloy inner liner
with full perimeter gasket and sealed by turning a "T" type
handle. The door cannot be opened when the steamer is on.
Automatic timed compartment controls with 60 minute timer
add the suffix "S" to the model number.
Lift-out stainless steel wire Adapt-A-Pan
six 4" or four 6" deep food pans (one for 2 compartments)(two
for 3 compartment) and one manual pull out shelf.
Water fall front edge compartment interior bottom to lip out at
front.
Steamer mounted on 28" high base cabinet with stainless steel
frame, front full height doors, slip-off stainless steel side and
aluminized rear panel with 6" adjustable legs with flanged feet
for anchoring.
270,000 BTU/hr. high efficiency steam boiler with electronic
ignition builds 5.5 BHP. Includes CSD-1 compliant high
pressure limit switch (15 psi), low water cut-off, automatic
water fill, automatic boiler blowdown, 15 psi pressure relief
valve and 15 psi kettle connection.
Service connections include 1" gas connection,
water connection for boiler feed and
120 volt control circuit and 1
One year limited parts and labor warranty.
OPTIONS
TM
PreVent , automatic load compensated timed, combination
pressure and free venting cooking with automatic exhaust,
add the suffix "P" to the model number.
Correction facility package:
a. Cabinet door with hasp (lock by others).
b. Security type tamper resistant fasteners.
c. Control cover (lock by others).
Control circuit step down transformer to 120V, if higher than
120 volts.
Mount and interconnect boiler base with kettle at factory.
Includes steam supply piping. Shipped on one skid.
Second year extended limited parts and labor warranty.
ACCESSORIES
Stainless steel back panel.
Interconnecting steam supply plumbing kit.
Manual sliding shelf (Qty. ____).
Removable 12 x 20 sliding shelf (Qty. ____).
Adapt-A-Pan™ support (Qty. ____).
Water treatment system.
C.S.I. Section 11420
TM supports eight 2 1
1
/ " cold
2
1 / " cold water condenser,
2
1 / " drain connection.
4
/ ",
