Vulcan-Hart G260 Replacement Parts Manual
Endurance series gas ranges
Hide thumbs
Also See for G260:
- Installation and operation manual (25 pages) ,
- Service manual (23 pages) ,
- Installation & operation manual (49 pages)
Advertisement
Quick Links
ENDURANCE SERIES
GAS RANGES
MODELS
G36
ML-136472
G36C
ML-136746
G36F, X
ML-136474, ML-136475
G36S
ML-136473
G48
ML-136491
G48C
ML-136493
G48F
ML-136492
G60
ML-136479
G60C
ML-136482
G60CC
ML-136485
G60F, X
ML-136480, ML136481
G60FC
ML-136483
G60XC
ML-136484
G60FCC
ML-136486
G60XCC
ML-136487
G260
ML-136488
G260C
ML-136489
G260CC
ML-136490
For additional information on Vulcan-Hart or to locate an authorized parts
and service provider in your area, visit our website at www.vulcanhart.com
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM
REPLACEMENT PARTS
CATALOG OF
P.O. BOX 696, LOUISVILLE, KY 40201-0696
TEL. (502) 778-2791
F-35647 Rev. A (5-07)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vulcan-Hart G260
Summary of Contents for Vulcan-Hart G260
-
Page 1: Replacement Parts
G260 ML-136488 G260C ML-136489 G260CC ML-136490 For additional information on Vulcan-Hart or to locate an authorized parts and service provider in your area, visit our website at www.vulcanhart.com VULCAN-HART DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC WWW.VULCANHART.COM CATALOG OF REPLACEMENT PARTS P.O. - Page 2 ENDURANCE SERIES GAS RANGES Fig. 1 OVEN BODY - 2 -...
- Page 3 1, 1 2, 2 1, 1 1, 1 1, 1 4, 4 1, 1 1, 1 1, 1 1, 1 1, 1 1, 1 1, 1 4, 4 - 3 - ENDURANCE SERIES GAS RANGES AMT. G60C G60CC G260 G260C G260CC...
- Page 4 ENDURANCE SERIES GAS RANGES Fig. 2 OVEN BODY - 4 -...
- Page 5 ILLUS. PART NO. Fig. 2 00-428982-00001 Back Splash ... 1 00-428981-00001 Rear Heat Shield ... 1 00-428405-00001 Bayonet Channel ... 2 00-428978-000G1 Plate Shelf Assy ... 1 00-428879-00001 Front Grate Casting ... 4 00-428880-00001 Rear Grate Casting ... 4 00-429983-000G1 Front Top Assembly ...
- Page 6 ENDURANCE SERIES GAS RANGES Fig. 3-A PIPING - 6 -...
- Page 7 Flex Tube Assy. (60/260 Top) ... 00-498125-000G1 Flex Tube Assy. (60/260 Rear) ... Assembly Contains the Oven Pilot and Oven Burner Flex Tubing PIPING NAME OF PART G36C - 7 - ENDURANCE SERIES GAS RANGES AMT. G60C G60CC G260 G260C G260CC...
- Page 8 ENDURANCE SERIES GAS RANGES Fig. 4-A PIPING - 8 -...
- Page 9 ILLUS. PART NO. Fig. 4-A 00-428675-00001 Burner Head 6" ... 8 00-428614-00001 Venturi Casting ... 4 00-428719-00001 Restrictor Plate ... 8 00-428894-00001 Venturi Pilot Quick Disconnect ... 4 00-404060-00001 Air Shutter ... 8 00-428495-000G1 U-Burner Assy ... 1 00-497240-00001 Griddle Valve ... 00-404076 Burner Control Valve ...
- Page 10 ENDURANCE SERIES GAS RANGES Fig. 5 CONVECTION OVEN VENT MOTOR - 10 -...
- Page 11 ILLUS. PART NO. Fig. 5 SC-113-05 Bolt, Hex Head, 1/4-20 x 3" ... 4 00-428960-00001 Motor Grate ... 1 00-411289-00003 Spacer ... 4 00-415780-00008 Rotor Blower ... 1 00-428343-00001 Motor Mounting Plate ... 1 SD-036-92 Bolt, Hex Head ... 4 00-414367-00001 Insulation ...
- Page 12 ENDURANCE SERIES GAS RANGES Fig. 6 BROILER GRIDDLE ASSEMBLY - 12 -...
- Page 13 Broiler Drip Tray ... 1 00-428802-000G1 Grease Drawer ... 1 00-428798-000G1 Broiler Drip Drawer ... 1 00-417632-00001 Broiler Grate ... 1 00-408726-000G6 Broiler Brick Set ... 1 BROILER GRIDDLE ASSEMBLY NAME OF PART - 13 - ENDURANCE SERIES GAS RANGES AMT. G260...
-
Page 14: Griddle Assembly
ENDURANCE SERIES GAS RANGES Fig. 7 GRIDDLE ASSEMBLY - 14 -... - Page 15 ILLUS. PART NO. Fig. 7 00-428921-000G1 Griddle Plate Assembly 12" ... 1 00-428922-000G1 Griddle Plate Assembly 24" ... 00-428927-000G1 Griddle Plate Assembly 36" ... 00-428915-00001 Pilot Tube Assembly ... 1 00-413302-00001 Pilot Mounting Clip ... 1 00-428857-000G1 Burner Griddle, RH ... 1 00-428857-000G2 Burner Griddle, LH ...
-
Page 16: Recommended Spare Parts
ENDURANCE SERIES GAS RANGES PART NO. NAME OF PART 00-428879-00001 Front Grate ... 2 00-428880-00001 Rear Grate ... 2 00-497027-00001 RH Door Spring Hinge ... 2 00-497027-00002 LH Door Spring Hinge ... 2 00-428675-00001 Burner Head ... 2 00-428719-00001 Restrictor Plate ... 2 00-428495-000G1 Oven Burner ...
