Vulcan-Hart E12FP Specifications

model E12Fp
SpECIFICATIONS:
E12HT (Hot Top)
1 - 12" x 24" (305 mm x 610 mm) 5 KW cast hot top
thermostatically controlled. Temperatures range from 340°
to 750°F (171° to 427°C). Hot top not suitable
for griddle work. (Available in single phase only.)
E12Fp (French Plate)
2 - 91⁄2" (241 mm) diameter, infinite heat controlled 2 KW
round cast* surface units supported in top sections of
porcelain enameled steel. Total 4 KW input for range top.
*The 9 1/2" round cast surface units are identified as E.G.O. units.
Each 9 1/2" round casting is rated 2000 watts at either 208, 240
or 480 volts. Each 9 1/2" round casting is controlled by an infinite
heat switch on 208 and 240 volt units. On 480 volt units each
casting is controlled by a 3 position heat switch.
High= 2000 W
Med= 1000 W
Low= 500 W
NSF listed. U L listed. U L listed to Canadian safety standards.
SpECIFy VOLTAGE AND pHASE WHEN ORDERING.
VULCAN-HART COmpANy, p.O. BOX 696, LOUISVILLE, Ky 40201, TEL. 1-800-814-2028
F-32153 (4-07)
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
E12HT & E12Fp
ELECTRIC EXpANDO RANGES
E12HT Hot Tops
■
E12Fp French Hot plates
■
STANDARD FEATURES
■ Stainless steel front, 2 stainless sides.
■ Stainless steel front top ledge.
■ 5" stainless steel vented back splash.
■ Fully enclosed 31"h body with removable front panel.
■ 6" stainless steel adjustable legs.
■ One year limited parts and labor warranty.
OpTIONS
480 volts, 60 Hz, 1 ph (E12HT & E12FP).
■
480 volts, 60 Hz, 3 ph (E12FP only).
■
Second year extended limited parts and labor warranty.
■
C.S.I. Section 11420
