DO NOT DIVE OR JUMP , SHALLOW WATER!
WARNING : THIS POOL IS NOT DESIGNED FOR DIVING AND/OR JUMPING.
WARNING : The pool owner is responsible to ensure everyone who accesses the yard, fol-
lows all safety instructions.
WARNING : Be sure you have read and understand the 'Safety Information' sheets before
you begin your pool installation.
• Never dive, jump or slide into an above ground swimming pool.
Diving, jumping or sliding may result in permanent injury or death.
• The homeowner is responsible to install all safety labels.The
safety labels shall be placed above the water line, never covered
and always visible from any potential entry points of the pool. Also,
make sure to install safety labels at all access points of your yard.
• Adult supervision is always necessary. Never take your eyes off
children or swimmers in the water or near the pool.
• Designate an adult pool watcher. Make sure that you or your pool
watcher are able to intervene in less then 10 seconds to save a life
or avoid injury.
• Do not swim during thunder, electrical or wind storms.
• Keep rescue equipment such as life rings and reaching poles etc,
in a prominent area by the pool at all times. Please consult your
municipality to get a rescue equipment list.
• An emergency phone number such as: nearest available police,
fire, ambulance and/or rescue unit, must be visible from pool area.
A functioning fixed or cellular phone must be reachable immedi-
ately.
WARNING : this product contains chemicals which are known to the state of California to cause
cancer and/or reproductive harm. p65warnings.ca.gov
ASSEMBLY INSTRUCTIONS
OVAL POOLS NBS
• It is important that all users be able to see the bottom of the pool.
Foggy water must be cleared up before entering the pool. At night,
sufficient lighting must be available. It's the homeowner's sole
responsibility to provide adequate lighting for pool bottom, safety
labels and walkways, which exceeds minimum standards of the IES
of North America.
• Never swim alone, under the influence of drugs or alcohol, tired
or ill.
• All accessories and liners : the homeowner must follow the manu-
facturer's instructions and safety warnings.
• Do not affix any other products to your pool other then required
by your local code.
• Do not sit, climb or stand on the top ledges of the pool.
OVAL POOL
MODEL G
Advertisement
Table of Contents
Related Manuals for Cornelius G
Summary of Contents for Cornelius G
- Page 1 OVAL POOL ASSEMBLY INSTRUCTIONS OVAL POOLS NBS MODEL G DO NOT DIVE OR JUMP , SHALLOW WATER! WARNING : THIS POOL IS NOT DESIGNED FOR DIVING AND/OR JUMPING. WARNING : The pool owner is responsible to ensure everyone who accesses the yard, fol- lows all safety instructions.
-
Page 2: Safety Labels
SAFETY LABELS If you require additional labels, you can order more free of charge by calling 1-888-777-0447 SAFETY INFORMATION WARNING : All pool components, such as the filtration system, pump and heater should not be positioned in such a way that someone could use them to gain access to the pool. Be sure that filter, pump, all toys, chairs, tables, buildings or similar objects are at least at a minimum of 4’... -
Page 3: Parts List
PARTS LIST * SEE DRAWING PARTS NEXT PAGE ITEM DESCRIPTION POOL WALL BOLT & NUT FOR WALL & TENSION STRAPS 1/4" X 5/8" (6,35 mm X 15,88 mm) COPING (OPTIONAL) LEDGE - ROUND SECTION LEDGE - STRAIGHT SECTION BOTTOM CONNECTOR UPRIGHT TOP CONNECTOR TOP CAP... - Page 4 PARTS LIST (continued)
-
Page 5: Site Preparation
SITE PREPARATION When selecting a site for your pool, take into account your local to ensure proper installation and avoid problems further on. regulations regarding fences and utility laws pertaining to elec- trical cables, as well as the landscaping which you are planning Draw two half circles from the A and B stakes using the radius (R) once the pool is installed. - Page 6 LEVELLING AND TRENCH PREPARATION DO NOT ALLOW WATER TO ACCUMULATE AROUND POOL. Make them. sure to provide good drainage away from the pool. Refer to illustration 2.3 for trench layout detail, all grey shaded SITE LEVELLING areas. The entire area must be perfectly levelled, using a proper levelling Place and level patio blocks into trenches.
- Page 7 PATIO COMPACTION STONE SIZE DISTANCE (A-B) POOL RADIUS (R) POOL WIDTH (D) POOL LENGTH (E) BLOCK SAND DUST 5'-6" (1.68 m) 3' 6" (1.07 m) (2.13 m) 12' 6" (3.81 1 ton 1/3 ton 7'x13' 8'x14' 5'-6" (1.68 m) 4' 1/2" (1.40 m) 8' 1"...
- Page 8 PATIO COMPACTION STONE SIZE DISTANCE (A-B) POOL RADIUS (R) POOL WIDTH (D) POOL LENGTH (E) BLOCK SAND DUST 8'-3" (2.51 m) 3' 6" (1.07m) (2.13 m) 15' 3" (4.65 1 ton 1/3 ton 7'x15' 8'x16' 8'-3" (2.51 m) 4' 1/2" (1.40 m) 8' 1"...
- Page 9 PATIO COMPACTION STONE SIZE DISTANCE (A-B) POOL RADIUS (R) POOL WIDTH (D) POOL LENGTH (E) BLOCK SAND DUST 8'x19' 11'-0" (3.35 m) 4' 1/2" (1.40 m) 8' 1" (2.46 m) 19' 1" (5.82 m) 1 ton 1/3 ton 11'-0" (3.35 m) (1.52 m) (3.05 m) (6.40 m)
- Page 10 PATIO COMPACTION STONE SIZE DISTANCE (A-B) POOL RADIUS (R) POOL WIDTH (D) POOL LENGTH (E) BLOCK SAND DUST 14'-8" (4.47 m) 5' 11-3/4" (1.82 m) 11' 11-1/2" (3.65 m) 26' 8-1/4" (8.14 m) 1 1/2 ton 3/4 ton 12'x27' 5-3/4" (4,39 m) 22-3/4”...
- Page 11 PATIO COMPACTION STONE SIZE DISTANCE (A-B) POOL RADIUS (R) POOL WIDTH (D) POOL LENGTH (E) BLOCK SAND DUST 15'-7" (4.75 m) 6" (2.44 m) (4.57 m) 30' 7-1/4" (9.33 m) 2 tons 1 1/2 ton 15'x31' 16'-1" (4.90 m) 7' 11-1/2" (2.59 m) 15' 11"...
- Page 12 PATIO COMPACTION STONE SIZE DISTANCE (A-B) POOL RADIUS (R) POOL WIDTH (D) POOL LENGTH (E) BLOCK SAND DUST 20'-6" (6.25 m) 8'-11" (2.72 m) 17' 10" (5.44 m) 38' 4" (11.68 m) 3 tons 2 1/2 ton 18'x38' 8" (6,91 m) 22-3/4”...
- Page 13 PATIO COMPACTION STONE SIZE DISTANCE (A-B) POOL RADIUS (R) POOL WIDTH (D) POOL LENGTH (E) BLOCK SAND DUST 26'-0" (7.92 m) 8'-11" (2.72 m) 17' 10" (5.44 m) 43' 10" (13.36 m) 3 tons 2 1/2 ton 18'x44' 2-1/2" (8,60 m) 3-1/4"...
- Page 14 STRAIGHT SECTION FOOT BEAM ASSEMBLY Refer to Illustration 3.1. Join splice brackets (T) to the foot beam Illustration 3.1 (S) using bolts 1/2" X 3" (12.7 mm x 76.2 mm) (U), spacers (UB), nuts (UU) and washers (V). Remember to insert both spacers (UB) in the foot beam aligned with the holes, so the bolts go through the SPLICE BRACKET (T) spacers when they are inserted.
- Page 15 BOTTOM TRACK (straight section) AND PRESSURE PLATE Position the buttress post assemblies in the center of the patio block Refer to Illustration 5.2 : Attach pressure plates in between the foot in the previously dug trenches. beams with 4 standard screw ''Z'' (silver). Refer to Illustration 5.1 : Once the buttress post assemblies are placed in the trenches, install the straight section bottom tracks.
- Page 16 ROUND SECTION BOTTOM TRACK INSTALLATION Refer to illustration 7.1. Starting with round section : Place the end of the first round section bottom track on the foot beam so it is in- serted into the outside notch of the last buttress post of each straight section.
-
Page 17: Wall Installation
WALL INSTALLATION WARNING Never use an impact gun for wall and tension straps screws. SKIMMER HOLE Minimum torque force of 60 inch pounds to maximum of 85 inch pounds. WATER RETURN When installing the steel wall, it is important to do so in a loca- HOLE tion protected from the wind or on a day without any wind. - Page 18 WALL INSTALLATION (CONTINUED) Chart 1.4 Chart of actual wall lenghts 8x14 8x16 8x19 7x13 7x15 10x16 10x18 10x21 12x18 12x21 12x24 12x27 13x17 33' 0" 38' 6" 36' 5" 41' 11" 47' 5" 42' 5" 47' 11" 53' 5" 50' 7" 56' 1"...
- Page 19 VINYL LINER INSTALLATION See the liner manufacturer's instruction TOP TRACK INSTALLATION (3 OPTIONS) This is to complement liner manufacturer’s instructions. If you have any questions, please refer to the liner manufacturer’s in- TOP TRACK structions, first. 1- Overlap liner : Install the coping strip* around the perimeter of COPING STRIP* the pool, then the top track on the wall, followed by the top plate on...
- Page 20 TOP CONNECTOR INSTALLATION ROUND SECTIONS Install the top connector into the upright and secure with 1 screw ''Z'' on each side. TOP CONNECTOR SCREW ‘’Z’’ UPRIGHT STRAIGHT SECTIONS Install the top connector into the uprights and secure with 1 screw ''Z'' on each side.
-
Page 21: Top Cap Installation
LEDGE INSTALLATION Verify that each upright and buttress post are completely plumbed. Evenly distribute ledges all around the pool before securing them. Make sure the correct size ledges are utilized in the round and oval sections. Secure ledges in place with 4 screws ''ZL'' per illustration. SCREW ‘’ZL’’... -
Page 22: Safety Information
SAFETY INFORMATION DO NOT DIVE OR JUMP , SHALLOW WATER! WARNING : THIS POOL IS NOT DESIGNED FOR DIVING AND/OR JUMPING. WARNING : The pool owner is responsible to ensure everyone who accesses the yard, fol- lows all safety instructions. WARNING : Be sure you have read and understand the 'Safety Information' sheets before you begin your pool installation. - Page 23 SAFETY LABELS If you require additional labels, you can order more free of charge by calling 1-888-777-0447 SAFETY INFORMATION WARNING : All pool components, such as the filtration system, pump and heater should not be positioned in such a way that someone could use them to gain access to the pool. Be sure that filter, pump, all toys, chairs, tables, buildings or similar objects are at least at a minimum of 4’...
