1
Tableau 1.1 - Zones de déterrement (Figure 1.1)
DIMENSION RÉELLE DE LA PISCINE
2,46 x 4,14 m (8' 1"x 13' 7")
2,46 x 4,72 m (8' 1"x 15' 6")
2,46 x 5,82 m (8' 1"x 19' 1")
3,05 x 4,72 m (10' x 15' 5-3/4")
3,05 x 5,53 m (10' x 18' 2-1/2")
3,05 x 6,38 m (10' x 20' 11-1/8")
3,65 x 5,63 m (11' 11-1/2"x 18' 6")
3,65 x 7,30 m (11' 11-1/2"x 23' 11-1/2")
3,65 x 8,12 m (11' 11-1/2"x 26' 8-1/4")
3,96 x 5,17 m (13' x 16' 11-3/4")
3,96 x 6,83 m (13' x 22' 5")
4,29 x 5,97 m (14' 1"x 19' 7")
4,29 x 7,65 m (14' 1"x 25' 1")
4,57 x 5,99 m (15' x 19' 8")
4,57 x 7,65 m (15' x 25' 1-3/8")
4,57 x 9,33 m (15' x 30' 7-1/4")
4,85 x 8,08 m (15' 11"x 26' 6")
4,85 x 9,75 m (15' 11"x 32' )
5,44 x 10,00 m (17' 10" x 32' 10")
5,44 x 11,61 m (17' 10" x 38' 4")
5,44 x 13,36 m (17' 10" x 43' 10")
Choisissez l'emplacement idéal pour votre piscine en tenant compte des lois municipales sur la distance des clôtures, celles des
services publics sur la distance des fils électriques, ainsi que l'aménagement paysager prévu après l'installation.
PRÉPARATION DE L'EMPLACEMENT
MODÈLE
DISTANCE (A-B)
8'x14'
1,68m (5'-6")
8'x16'
2,26m (7'-5")
8'x19'
3,35m (11'-0")
10'x16'
1,68m (5'-6")
10'x18'
2,45m (8'-3")
10'x21'
3,35m (11'-0")
12'x18'
1,98m (6'-6 1/2")
12'x24'
3,65m (12'-0")
12'x27'
4,47m (14'-8")
13'x17'
1,18m (3'-10 1/2")
13'x23'
2,84m (9'-3 3/4")
14'x20'
1,68m (5'-6")
14'x25'
3,35m (11'-0")
15'x20'
1,42m (4'-7 3/4")
15'x26'
3,07m (10'-1")
15'x31'
4,75m (15'-7")
16'x26'
3,23m (10'-7 1/2")
16'x32'
4,90m (16'-1")
18'x33'
4,57m (15'-0")
18'x38'
6,25m (20'-6")
18'x44'
7,92m (26'-0")
INSTRUCTIONS D'ASSEMBLAGE
PISCINES OVALES
RAYON (R)
LARGEUR (D) LONGUEUR TOTALE (E)
2,75m (9')
1,40m (4'7 1/2")
1,40m (4'7 1/2")
2,75m (9')
1,40m (4'7 1/2")
2,75m (9')
3,35m (11')
1,70m (5'7")
1,70m (5'7")
3,35m (11')
3,35m (11')
1,70m (5'7")
3,96m (13')
1,98m (6'6 3/4")
3,96m (13')
1,98m (6'6 3/4")
3,96m (13')
1,98m (6'6 3/4")
2,13m (7')
4,27m (14')
4,27m (14')
2,13m (7')
2,31m (7'7 1/2")
4,57m (15')
2,31m (7'7 1/2")
4,57m (15')
4,88m (16')
2,44m (8')
4,88m (16')
2,44m (8')
2,44m (8')
4,88m (16')
2,59m (8'6 1/2")
5,18m (17')
2,59m (8'6 1/2")
5,18m (17')
5,79m (19')
2,90m (9'-6")
5,79m (19')
2,90m (9'-6")
5,79m (19')
2,90m (9'-6")
INSAO_ V4_2021-05-09
AVEC SUPPORTS LATÉRAUX
MODÈLE A
TRANCHÉE (F)
4,45m (14'-7")
1,90m (6'-3 1/2")
5,03m (16'-6")
3,33m (10'-11")
6,12m (20'-1")
3,58m (11'-9")
5,03m (16'-5 3/4")
1,90m (6'-3 1/2")
5,85m (19-2 1/2")
3,33m (10'-11")
6,69m (21-11")
3,33m (10'-11")
5,94m (19'-6")
1,90m (6'-3 1/2")
7,59m (24'-11 1/2")
3,58m (11'-9")
8,43m (27'-8 1/4")
5,23m (17'-2 1/2")
5,48m (17'-11 3/4")
1,66m (5'-5 1/2")
7,14m (23'-5")
3,33m (10'-11")
6,27m (20'-7")
1,90m (6'-3 1/2")
7,95m (26'-1")
3,58m (11'-9")
6,30m (20'-8")
1,66m (5'-5 1/2")
7,96m (26'-1 1/2")
3,33m (10'-11")
9,64m (31'-7 1/4")
4,99m (16'-4 1/2")
8,38m (27'-6")
3,58m (11'-9")
10,05m (33')
5,23m (17'-2 1/2")
10,31m (33'-10")
5,24m (16'-4 1/2")
11,98m (39'-4")
6,90m (22'-8")
13,66m (44'-10")
8,56m (28'-1 1/2")
A-FRAME

Advertisement

loading
Need help?

Need help?

Do you have a question about the A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cornelius A

  • Page 1 INSAO_ V4_2021-05-09 A-FRAME INSTRUCTIONS D’ASSEMBLAGE PISCINES OVALES AVEC SUPPORTS LATÉRAUX MODÈLE A PRÉPARATION DE L’EMPLACEMENT Tableau 1.1 - Zones de déterrement (Figure 1.1) DIMENSION RÉELLE DE LA PISCINE MODÈLE DISTANCE (A-B) RAYON (R) LARGEUR (D) LONGUEUR TOTALE (E) TRANCHÉE (F) 2,46 x 4,14 m (8' 1"x 13' 7")
  • Page 2 PRÉPARATION DE L’EMPLACEMENT (suite) 1) Plantez un pieu aux points A et B en respectant la distance de la 4) Vérifiez que la longueur totale soit conforme (E) section centrale entre ces deux points (A-B). 5) Ajoutez ensuite sur chaque côté des tranchées d’une largeur de 2) Tracez deux demi-cercles selon le bon rayon (R).
  • Page 3 INSTALLATION DU DRAIN DE FOND (optionnel) Creusez un trou de 30 cm (12") de largeur par environ 25 cm (10") de profondeur en plein centre de la circonférence. Creusez une tranchée d'environ 15 cm (6") de largeur à partir du trou central jusqu'à...
  • Page 4 ASSEMBLAGE DES BANDES DE TENSION (suite) 2) Se reférer à l’illustration 4.1: S’il y a plusieurs bandes par 3) Se reférer à l’illustration 4.2: Fixez les bandes de tension section, assemblez les bandes de tension ensemble avec 4 boulons ainsi assemblées aux lisses des deux côtés, à l'aide de quatre (4) et écrous (BB) 1/4"...
  • Page 5 ASSEMBLAGE DES ANGLES DE BASE 1) Positionnez les poteaux de renfort assemblés de l’étape 5 sur droite devant les poteaux de renfort sur les bandes de tension. Fixez les angles de base aux poteaux de renfort à l’aide de huit (8) les dalles préalablement positionnées.
  • Page 6 1.1, ajuster les Sécurisez-le avec la boulonnerie dans chaque trou et bien sécuriser rainures et les plaques s'il y a lieu et recommencer le déroulage. Si avec une clé (la tête du boulon doit être à l’intérieur du mur d’acier).
  • Page 7 FINITION DU FOND Étendez maintenant environ 10 cm (4") de sable à compactage au bas du mur intérieur de façon à former un remblai destiné à protéger MUR D'ACIER 30 cm (12") la toile des extrémités coupantes des rainures du bas et de la pous- sière de roche (si applicable).
  • Page 8 INSTALLATION DE LA TOILE DE VINYLE (SUITE) Détail de l’installation de la toile avec jonc d’accrochage. Finalement, vous pouvez introduire l'eau et la laisser monter jusqu'au Accrochez la toile sur le sommet du mur et installez la rainure du bas du mur avant d'arrêter l'aspirateur et de le retirer. haut par dessus la toile.
  • Page 9 INSTALLATION DES SIÈGES Placez les sièges sur les parties supérieures des poteaux. Installez Maintenez les sièges en place à l’aide de quatre (4) vis ‘’Z’’. les sièges en vous assurant d’avoir un espace égal entre chacun. Assurez-vous de vérifier la verticalité des poteaux avant de fixer les Même procédure d’installation pour la section droite.
  • Page 10 MONTAGE DU SYSTÈME DE FILTRATION Assemblez l’écumoire, le drain de fond, le retour d’eau et le système de filtration selon les instructions d’assemblage des manufacturiers. Note : Voir les “Informations de sécurité”.
  • Page 11 LISTE DES PIÈCES * VOIR LE DESSIN DES PIÈCES SUR LA PROCHAINE PAGE ITEM DESCRIPTION MUR D'ACIER (LONGUEUR RÉELLE, PIEDS-POUCES) BOULON & ÉCROU POUR MUR D'ACIER 52" (OU 54") TOILE INTÉRIEURE COUPLEUR EN PLASTIQUE (VENDU SÉPARÉMENT) SIÈGE - SECTION RONDE SIÈGE - SECTION DROITE PLAQUE DU BAS POTEAU 52'' OU 54''...
  • Page 12 LISTE DES PIÈCES (suite) SECTION DROITE SECTION RONDE...
  • Page 13 LE PLAISIR PASSE D’ABORD ET AVANT TOUT PAR LA SÉCURITÉ CONSIGNES DE SÉCURITÉ Veuillez lire ceci avant de procéder à l’installation de votre piscine hors terre. 12 775, rue Brault, Mirabel, Québec, Canada J7J 0C4 Téléphone : 1 800 448-7384 Télécopieur : 1 866 777-0167...
  • Page 14 ériger une pente de deux (2) degrés pour fa- dommages résultant d’une mauvaise installation de la part de l’a- voriser le drainage de l’eau. La pente de drainage est très importante.
  • Page 15 CONSIGNES DE SÉCURITÉ LORS DE L’UTILISATION DE LA PISCINE...
  • Page 16 Failure to follow the installation procedures may result in damage to your pool or property and void your warranty. We recommend that you make a preliminary study of the instruction booklet to familiarize yourself with the different parts of your pool. Make sure that you understand each step thoroughly before you begin assembling.
  • Page 17 SITE PREPARATION (continued) 1) Drive a stake into the ground at points A and B respecting the 4) Verify that the total length is consistent. (E) distance of the straight section between those two points (A-B). 5) Add 89cm (36”) wide trenches on each side, respecting the 2) Draw two half circles respecting the radius (R).
  • Page 18 BOTTOM DRAIN ASSEMBLY (if applicable) Dig a hole 30 cm (12") wide by approximately 25 cm (10") deep in the center of the circumference. From the center hole to the projected location of the pool motor, dig a 15 cm (6") wide trench. Place the removed soil aside to be used later to cover the hose.
  • Page 19 TENSION STRAPS ASSEMLBY (continued) 2) Refer to Illustration 4.1: If there is more than one metallic 3) Refer to Illustration 4.2.: Attach the assembled tension straps strap per row, assemble the straps together using 4 bolts and nuts to bottom braces on both sides, using four (4) bolts and nuts (BB) (BB) 1/4"...
  • Page 20 BEARING PLATE ASSEMBLY 1) Position the buttress posts assembled in step 5 on the patio tress posts and on the tension straps. Fix the bearing plate using blocks in the trenches previously placed. eight (8) bolts and nuts (BB) 1/4"#20 X 5/8" (6,35 mm X 15,88 mm), taking care of placing the bolt head on bearing plate and nut 2) Refer to Illustration 6.1 : Once the buttress posts are placed on buttress post.
  • Page 21 IMPORTANT! Installing the wall joint in non-compliance with the specifications dictated by the manufacturer will void the warranty. A faulty installation will cause the wall/joint to split which could result in serious and/or fatal injuries! CHART OF ACTUAL LENGTHS OF STEEL WALL ACCORDING TO MODEL...
  • Page 22 Lift up a section of the liner over the top of the wall leaving a 10 cm to 15 cm (4" to 6") fringe outside the wall. Secure the liner with a Maintain the hose in place with adhesive tape.
  • Page 23 VINYL LINER INSTALLATION (continued) Installation detail of a bead liner with top track. Fill the pool with water up to the base of the wall before stopping Hang the liner on the top of the wall and install the top track to se- and removing the vacuum cleaner.
  • Page 24 Same installation procedure for the straight section. Be sure to have a vertical (plumb) upright before fixing the top seat. ROUND SECTION STRAIGHT SECTION SCREW ‘’Z’’...
  • Page 25 LABEL FILTRATION SYSTEM ASSEMBLY Assemble skimmer, inlet, drain, filter, pumps, hoses according to separate manufacturer’s instructions. Note: See 'Safety Information" Manual.
  • Page 26 PARTS LIST * SEE DRAWING PARTS NEXT PAGE ITEM DESCRIPTION POOL WALL (finished lenght, inch) BOLT & NUT FOR 52" (OR 54") WALL POOL LINER PLASTIC COUPLER (SOLD SEPARATELY) TOP SEAT - ROUND SECTION TOP SEAT- STRAIGHT SECTION BOTTOM PLATE - ROUND SECTION UPRIGHT 52'' or UPRIGHT 54'' TOP PLATE - ROUND SECTION SEAT CAP...
  • Page 27 PARTS LIST STRAIGHT SECTION ROUND SECTION...
  • Page 28 SAFETY AND FUN GO TOGETHER! SAFETY INFORMATION Read this before installing your above-ground pool. 12 775, Brault Street, Mirabel, Quebec, Canada J7J 0C4 Phone: 1 800 448-7384 Fax: 1 866 777-0167...
  • Page 29 A light, strong and rigid pole, frequently referred to as a Shepard’s recommend that lifesaving equipment be on hand near Crook, at least twelve feet long or a throwing rope at least ¼ inch in the pool at all times.
  • Page 30 USAGE SAFETY INFORMATION...
