Vulcan-Hart GCO2D Specifications

Shown on optional S/S stand with casters
SPECIFICATIONS:
Half size gas convection oven, Model No. GCO2D, manufac-
tured by Vulcan-Hart. Porcelain enamel on steel oven interior
measures 15 1 / "w x 21"d x 20"h. Furnished with nine position
4
nickel plated rack guides and five nickel plated racks
measuring 14 / " x 20 / ". Heated by 25,000 BTU/hr. gas burner.
3 7
8 8
Electronic spark ignition system. Stainless steel front, sides, top
and rear enclosure panel. Insulation applied to the top, rear,
both sides, bottom and door. Stainless steel door with double
pane window. Solid state temperature controls adjustable from
200° to 500°F. 60 minute electrical timer with continuous
sounding buzzer. Single speed
oven blower-motor. Requires 120/60/1 power supply. 8 amps
total draw. Furnished with cord and plug.
Exterior dimensions: 30"w x 28
CSA design certified for use in the U.S. and Canada. NSF listed.
Specify type of gas and finish when ordering. Specify
altitude if above 2,000 ft.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32192 (03-08)
1 / H.P. permanently lubricated
2
/ "d x 30 / "h on 4" legs.
1 5
4 8
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
MODEL GCO2D
HALF SIZE GAS CONVECTION OVEN
STANDARD FEATURES
■ Stainless steel front, sides, top and rear enclosure panel.
■ Stainless steel door with double pane window.
■ Cool to the touch oven door handle.
■ Stainless steel oven door gaskets.
■ 25,000 BTU/hr. input.
■ Electronic spark ignition system.
■ Solid state temperature control adjusts from 200° to 500°F.
■ 60 minute electric timer with time expired buzzer.
■ / H.P. single speed fan motor.
1
2
■ Oven cool switch for rapid cool down when door is open.
■ Oven interior liners are porcelain on steel.
■ Nine position rack guide with five nickel plated racks.
■ 4" adjustable chrome plated legs.
■ Manual shut-off valve and gas pressure regulator.
connection required.
■ Requires 120/60/1 power supply. 8 amps total draw.
Furnished with cord and plug.
■ One year limited parts and labor warranty.
OPTIONS AT EXTRA COST
Set of four 16 / " stainless steel legs with adjustable feet
3
4
and stack set.
Set of four 16 / " stainless steel legs with casters and
3
4
stack set.
34" stainless steel stand with legs and nine position rack
storage capacity.
34" stainless steel stand with casters and nine position rack
storage capacity.
Additional oven racks.
Rack hanger.
Second year extended limited parts and labor warranty.
C.S.I. Section 11420
3 / " gas
4
