Vulcan-Hart ECO2D Specifications

Model ECO2D
Shown on optional S/S stand with casters
SPECIFICATIONS:
Half size electric convection oven, Model No. ECO2D, manu-
factured by Vulcan Hart. Porcelain enamel on steel oven interior
measures 15 / "w x 21"d x 20"h. Furnished with nine position
1
4
nickel plated rack guides and five nickel plated racks measur-
ing 14 3 / " x 20 7 / ". Heated by enclosed tubular heating elements
8 8
rated at 5.5 KW. Stainless steel front, sides, top and rear
enclosure panel. Insulation applied to the top, rear, both sides,
bottom and door. Stainless steel door with double pane win-
dow. Solid state temperature controls adjustable from 200° to
500°F. 60 minute electrical timer with continuous sounding
buzzer. Two speed / H.P. permanently lubricated oven blower
1
3
motor. Requires 208/240 volt, 60 Hz, 1 or 3 phase supply.
Exterior dimensions: 30"w x 28
NSF listed. U L listed. U L listed to Canadian safety standards.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32190 (03-08)
/ "d x 30 / "h on 4" legs.
1 5
4 8
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
MODEL ECO2D
HALF SIZE ELECTRIC CONVECTION OVEN
STANDARD FEATURES
■ Stainless steel front, sides, top and rear enclosure panel.
■ 4" adjustable chrome plated legs.
■ Stainless steel door with double pane window.
■ Cool to the touch oven door handle.
■ Stainless steel oven door gaskets.
■ 5.5 KW input.
■ Solid state temperature control adjusts from 200° to 500°F.
■ 60 minute electric timer with time expired buzzer.
■ / H.P. two speed fan motor.
1
3
■ Oven cool switch for rapid cool down when door is open.
■ Oven interior liners are porcelain on steel.
■ Nine position rack guide with five nickel plated racks.
■ Requires 208/240 volt, 60 Hz, 1 or 3 phase power supply.
■ One year limited parts and labor warranty.
OPTIONS
Set of four 16 3 / " stainless steel legs with adjustable feet
4
and stack set.
Set of four 16 / " stainless steel legs with casters and
3
4
stack set.
34" stainless steel stand with legs and nine position rack
storage capacity.
34" stainless steel stand with casters and nine position rack
storage capacity.
Rack hanger.
Second year extended limited parts and labor warranty.
C.S.I. Section 11420
