X20(c)SA4430
Information:
B&R makes every effort to keep data sheets as current as possible. From a safety point of view, how-
ever, the current version of the data sheet must always be used.
The certified, currently valid data sheet can be downloaded from the B&R website
tion.com.
Organization of notices
Safety notices
Contain only information that warns of dangerous functions or situations.
Signal word
Danger!
Warning!
Caution!
Notice!
General notices
Contain useful information for users and instructions for avoiding malfunctions.
Signal word
Information:
1 General information
The modules are equipped with 2 safe analog input pairs for current measurement. Each input pair has its own
sensor power supply. The channels with their respective sensor supplies are galvanically isolated from each other.
It is possible to acquire current signals in the range of 0.5 to 25 mA.
The safe analog input modules are suitable for safely acquiring current signals for safety-related applications up
to PL e or SIL 3.
These modules are designed for X20 16-pin terminal blocks.
• 2 safe analog input pairs for current measurement 0.5 to 25 mA
• 24-bit digital converter resolution
• Channels individually galvanically isolated
• Sensor power supplies galvanically isolated
• Input filter configurable
Data sheet V1.141 X20(c)SA4430 Translation of the original documentation
Description
Failure to observe these safety guidelines and notices will result in death, severe injury or substantial damage to property.
Failure to observe these safety guidelines and notices can result in death, severe injury or substantial damage to property.
Failure to observe these safety guidelines and notices can result in minor injury or damage to property.
Failure to observe these safety guidelines and notices can result in damage to property.
Table 1: Organization of safety notices
Description
Useful information, application tips and instructions for avoiding malfunctions.
Table 2: Organization of general notices
X20(c)SA4430
www.br-automa-
1
Advertisement
Table of Contents
Related Manuals for B&R X20SA4430
Summary of Contents for B&R X20SA4430
- Page 1 X20(c)SA4430 X20(c)SA4430 Information: B&R makes every effort to keep data sheets as current as possible. From a safety point of view, how- ever, the current version of the data sheet must always be used. The certified, currently valid data sheet can be downloaded from the B&R website www.br-automa- tion.com.
- Page 2 X20(c)SA4430 1.1 Function Safe analog inputs This safe analog input module is suitable for safely acquiring current signals for safety-related applications up to PL e or SIL 3. openSAFETY This module uses the protective mechanisms of openSAFETY when transferring data to the various bus systems. Because the data is encapsulated in the openSAFETY container in a fail-safe manner, the components on the network that are involved in the transfer do not require any additional safety-related features.
-
Page 3: Order Data
I/O power supply continuous X20cBM33 X20 bus module, coated, for X20 SafeIO modules, internal I/O power supply continuous Terminal blocks X20TB5F X20 terminal block, 16-pin, safety-keyed Table 4: X20SA4430, X20cSA4430 - Order data Data sheet V1.141 X20(c)SA4430 Translation of the original documentation... -
Page 4: Technical Data
<1*10 * Number of openSAFETY packets per hour <1*10 (regardless of whether SHUNTTEST is enabled or disabled) Proof test interval (PT) 20 years Table 5: X20SA4430, X20cSA4430 - Technical data Data sheet V1.141 X20(c)SA4430 Translation of the original documentation... - Page 5 -40 to 60°C Vertical mounting orientation 0 to 40°C -40 to 40°C Derating See section "Derating". Storage -40 to 85°C Transport -40 to 85°C Table 5: X20SA4430, X20cSA4430 - Technical data Data sheet V1.141 X20(c)SA4430 Translation of the original documentation...
- Page 6 "Installation notes for X20 modules" on page Derating Modules next to the X20SA4430 can only have a maximum power consumption of 1 W. Beginning at 50°C (hori- zontal mounting orientation) and 35°C (vertical mounting orientation), a dummy module must be inserted next to the X20SA4430.
-
Page 7: Led Status Indicators
X20(c)SA4430 5 LED status indicators Figure Color Status Description Green No power to module Single flash Reset mode Double flash Updating firmware Blinking PREOPERATIONAL mode RUN mode No power to module or everything OK Pulsating Boot loader mode Triple flash Updating safety-related firmware Error or I/O component not provided with voltage e + r... - Page 8 SAI- 1 V24+ 1 SAI+ 2 GND 1 SAI- 2 V24+ 2 SAI+ 3 GND 2 SAI- 3 V24+ 2 SAI+ 4 GND 2 SAI- 4 Figure 1: X20SA4430 - Pinout Data sheet V1.141 X20(c)SA4430 Translation of the original documentation...
-
Page 9: Connection Examples
(EN 62061:2013), max. SIL 3 (IEC 61508:2010) or max. SIL 3 (IEC 61511:2004). X20SA4430 - 2-wire connection, 2x SIL 2 − − +24 VDC +24 VDC Figure 2: X20SA4430 - 2-wire connection, 2x SIL 2 Data sheet V1.141 X20(c)SA4430 Translation of the original documentation... - Page 10 X20(c)SA4430 X20SA4430 - 3-wire connection, 2x SIL 2 +24 VDC +24 VDC Figure 3: X20SA4430 - 3-wire connection, 2x SIL 2 X20SA4430 - 4-wire connection, 2x SIL 2 − − +24 VDC +24 VDC Figure 4: X20SA4430 - 4-wire connection, 2x SIL 2...
- Page 11 X20SA4430 - 2-wire connection, 1x SIL 3 − +24 VDC +24 VDC Figure 5: X20SA4430 - 2-wire connection, 1x SIL 3 X20SA4430 - 3-wire connection, 1x SIL 3 +24 VDC +24 VDC Figure 6: X20SA4430 - 3-wire connection, 1x SIL 3...
- Page 12 X20(c)SA4430 X20SA4430 - 4-wire connection, 1x SIL 3 − +24 VDC +24 VDC Figure 7: X20SA4430 - 4-wire connection, 1x SIL 3 Data sheet V1.141 X20(c)SA4430 Translation of the original documentation...
-
Page 13: Error Detection
X20(c)SA4430 8 Error detection 8.1 Internal module errors The red "SE" LED makes it possible to evaluate the following error states: • Module error, e.g. defective RAM, defective CPU, etc. • Overtemperature/Undertemperature • Overvoltage/Undervoltage • Incompatible firmware version Errors that occur within the module are detected according to the requirements of the standards listed in the certificate and within the minimum safety response time specified in the technical data. -
Page 14: Wiring Errors
X20(c)SA4430 8.2 Wiring errors The wiring errors described in the following section are indicated by the red channel LED according to the appli- cation. If a module detects an error, then: • The channel LED is lit constantly red. • Status signal (e.g. (Safe)ChannelOK, (Safe)InputOK, (Safe)OutputOK, etc.) is set to (SAFE)FALSE. •... - Page 15 X20(c)SA4430 Errors Detection Comment Open line Detected Channel errors Short circuit between signal lines May not be detected The user must take appropriate measures to ensure that this error does not lead to a safety-critical state. Signal and supply lines must be installed in such a way that fault exclusion is possible per EN ISO 13849-2:2012, table D.5.
-
Page 16: Channel Diagnostics
If the behavior of firmware version 321 is desired for compatibility reasons, this can be implemented using para- meter "Measurement Result while Testing = Averaged". An active channel test is indicated by channel "TestActive". The sequence for channel diagnostics is independent of the firmware version and structured as follows: X20SA4430 X20ST4492 Diagnostic Window 1 Hourly... -
Page 17: Module Function
X20(c)SA4430 9 Module function The safe analog input module is suitable for safely acquiring current signals for safety-related applications up to PL e or SIL 3. Danger! Possible failure of safety function Dangerous system behavior due to incorrect use of analog signal values When using analog signal values, note the information listed in the data sheet regarding the function- ality, precision and scope of the data. -
Page 18: Input Circuit Diagram
X20(c)SA4430 10 Input circuit diagram Channel 1 + Shunt 1 Hardware filter converter 1 Shunt 2 Channel 1 - Galvanic isolation Channel 2 + Shunt 1 Hardware filter converter 2 Shunt 2 Channel 2 - Current measurement Shunt Sensor power supply 1 + DC-to-DC 29 V Sensor power supply 1 -... -
Page 19: Minimum Cycle Time
X20(c)SA4430 11 Minimum cycle time The minimum cycle time specifies the time up to which the bus cycle can be reduced without communication errors occurring. Minimum cycle time 200 μs 12 I/O update time The time needed by the module to generate a sample is specified by the I/O update time. Danger! With regard to the I/O update time, an I/O update time of 200 ms should generally be considered for analog input modules with firmware version 301 or lower. - Page 20 X20(c)SA4430 13 Restart behavior Each digital input channel is not equipped with an internal restart interlock, which means that the associated channel data reverts back to the proper state automatically after an error situation on the module and/or network. It is the responsibility of the user to connect the channel data of the safe input channels correctly and to provide them with a restart interlock.
-
Page 21: Register Description
X20(c)SA4430 14 Register description 14.1 Parameters in the I/O configuration Group: Function model Parameter Description Default value Unit Function model This parameter is reserved for future functional expansions. Default Table 12: I/O configuration parameters: Function model Group: General Parameter Description Default value Unit Module supervised... - Page 22 X20(c)SA4430 14.2 Parameters in SafeDESIGNER - up to Release 1.9 Group: Basic Parameter Description Default value Unit Min_required_FW_Rev This parameter is reserved for future functional expansions. Basic Release Optional This parameter can be used to configure the module as "optional". Optional modules do not have to be present, i.e.
- Page 23 X20(c)SA4430 Danger! With "Disable_Shunttest = Yes-ATTENTION", the module has reduced error detection capabilities and no longer meets the requirements of Cat. 4 per EN ISO 13849-1:2015. As a result, the module meets the requirements up to max. Cat. 3 per EN ISO 13849-1:2015. Data sheet V1.141 X20(c)SA4430 Translation of the original documentation...
- Page 24 X20(c)SA4430 Group: Safety_Response_Time Parameter Description Default value Unit Manual_Configuration This parameter makes it possible to manually and individually configure the safety response time for the module. The parameters for the safety response time are generally set in the same way for all stations involved in the application. For this reason, these parame- ters are configured for the SafeLOGIC controller in SafeDESIGNER.
- Page 25 X20(c)SA4430 Group: SafeCurrentxxyy Parameter Description Default value Unit Limit_Threshold_High_1, This parameter specifies the current maximum permissible analog input value. 20000 µA Limit_Threshold_High_2, • Permissible values: 3600 to 21,000 µA (corresponds to 3.6 to 21 mA) Limit_Threshold_High_3, Limit_Threshold_High_4 Limit_Threshold_Low_1, This parameter specifies the current minimum permissible analog input value. 4000 µA Limit_Threshold_Low_2,...
- Page 26 X20(c)SA4430 14.3 Parameters in SafeDESIGNER - Release 1.10 and higher Group: Basic Parameter Description Default value Unit Min required FW Rev This parameter is reserved for future functional expansions. Basic Release Optional This parameter can be used to configure the module as "optional". Optional modules do not have to be present, i.e.
- Page 27 X20(c)SA4430 Group: Safety Response Time Parameter Description Default value Unit Manual Configuration This parameter makes it possible to manually and individually configure the safety response time for the module. The parameters for the safety response time are generally set in the same way for all stations involved in the application.
- Page 28 X20(c)SA4430 Group: SafeCurrentxxyy Parameter Description Default value Unit Limit Threshold High 1, This parameter specifies the current maximum permissible analog input value. 20000 µA Limit Threshold High 2, • Permissible values: 500 to 25,000 µA (corresponds to 0.5 to 25 mA) Limit Threshold High 3, (up to hardware upgrade 1.10.1.0: 3600 to 21,000 µA - corresponds to Limit Threshold High 4...
-
Page 29: Channel List
X20(c)SA4430 14.4 Channel list Channel name Access via Au- Access via Data type Description tomation Studio SafeDESIGNER ModuleOk Read BOOL Indicates if the module is OK SerialNumber Read UDINT Module serial number ModuleID Read UINT Module ID HardwareVariant Read UINT Hardware variant FirmwareVersion Read... - Page 30 X20(c)SA4430 Channel name Access via Au- Access via Data type Description tomation Studio SafeDESIGNER Currentxx Read Read Current channel xx Values Input signal 0 to 20000 Current signal 0 to 20 mA SafeThrSelector_xxyy_Bit1 Write SAFEBOOL **_Bit1 **_Bit2 Parameters cur- SafeThrSelector_xxyy_Bit2 Write SAFEBOOL rently being used...
- Page 31 X20(c)SA4430 15 Safety response time The safety response time is the time between the arrival of the signal on the input channel and the output of the cutoff signal on the output. Total lag time Signal processing in the sensor Signal processing on the safe B&R input module Data transmission time on the bus (Input ->...
- Page 32 X20(c)SA4430 15.2 Data transmission time on the bus The following relationship must be taken into consideration for the data transmission time on the bus: • The time needed to transfer data from the input to the SafeLOGIC controller or to the output depends on the sum of the cycle times and CPU copy times in effect on the transfer line.
- Page 33 X20(c)SA4430 Calculating the maximum data transmission time - Release 1.10 and later: The following parameters are relevant for calculating the data transmission time between the safe input module and safe output module; parameter "Manual Configuration" deserves special attention. • Relevant parameters for "Manual Configuration = No": –...
- Page 34 X20(c)SA4430 Information: For more information about the actual data transmission time, see Automation Help, section Diagnos- tics and service → Diagnostics tools → Network analyzer → Editor → Calculation of safety runtime. The cycle time of the safety application must also be added. 15.3 Signal processing on the safe B&R output module The maximum I/O update time in the "I/O update time"...
-
Page 35: Intended Use
X20(c)SA4430 16 Intended use Danger! Danger from incorrect use of safety-related products/functions Proper functionality is only ensured if the products/functions are used in accordance with their intend- ed use by qualified personnel and the provided safety information is taken into account. The afore- mentioned conditions must be observed or covered by supplementary measures on your own respon- sibility in order to ensure the specified protective functions. - Page 36 X20(c)SA4430 16.3 Security concept B&R products communicate via a network interface and were developed for integration into a secure network. The network and B&R products are affected by the following hazards (not a complete list): • Unauthorized access • Digital intrusion •...
- Page 37 X20(c)SA4430 16.4 Safety technology disclaimer The proper use of all B&R products must be guaranteed by the customer through the implementation of suitable training, instruction and documentation measures. The guidelines set forth in system user's manuals must be taken into consideration here as well. B&R has no obligation to provide verification or warnings with regard to the customer's purpose of using the delivered product.
- Page 38 X20(c)SA4430 16.6 Installation notes for X20 modules Products must be protected against impermissible dirt and contaminants. Products are protected from dirt and contaminants up to pollution degree II as specified in the IEC 60664 standard. Pollution degree II can usually be achieved in an enclosure with IP54 protection, but uncoated modules are NOT permitted to be operated in condensing relative humidity and temperatures under 0°C.
-
Page 39: Release Information
X20(c)SA4430 17 Release information A manual version always describes the respective range of functions for a given product set release. The following table shows the relationship between manual versions and releases. Manual version Valid for V1.141 V1.140 Version Starting with Up to V1.131 Product set... -
Page 40: Version History
X20(c)SA4430 18 Version history Version Date Comment 1.141 April 2019 • Chapter 4 "Technical data": Updated standards. • Updated chapter 16.3 "Security concept". • Updated chapter 16.6 "Installation notes for X20 modules". 1.140 February 2019 • Chapter 4 "Technical data": –... - Page 41 X20(c)SA4430 Version Date Comment 1.90 October 2014 • Chapter 4 "Technical data": – "Short description": "I/O module": Adapted text to order data. – "System requirements" updated – Added "Safety-related characteristic values" and deleted chapter "Safety-related characteristic val- ues". – "Analog inputs": "Load": Extended range. •...
-
Page 42: Ec Declaration Of Conformity
X20(c)SA4430 19 EC declaration of conformity This document was originally written in the German language. The German edition therefore represents the original documentation in accordance with the 2006/42/EC Machinery Directive. Documents in other languages are to be interpreted as translations of the original documentation. Product manufacturer: B&R Industrial Automation GmbH B&R Strasse 1...
