Base frames FURA102 and FURA104

FURA102
220
20
81.5
FURA104
220
20
Fig. 12:
1 Base frame FURA102 for mTripod-FMTP-ML
2 Base frame FURA104 for mTripod-FMTP-MS
3 Feedthrough for empty conduits
4 Relevant boreholes M 8 for screws (FMTP-ML: 8 x and FMTP-MS: 6 x)
5 Passage side, side of the blocking arms
1153
3
1
411.5
5
650
2
75 325
5
Base frames FURA102 and FURA104 (dimensions in mm)
4
A
741.5 1071.5
3 4
A
575
mTripod
Installation and mounting
148
A
50
148
A
50
