Designation
Dimensions
(length x width x height)
Passage width
Weight
Material
Housing colour, standard
1) Optional
Table 4:
3.2

Clearances and line configuration to be maintained

Fig. 3:
1 Minimum distance 50 mm
Value
730 mm x 290 mm x 1050 mm
ä Page 18, Fig. 2.
515 mm
›
Turnstile complete: Approx. 56 kg
›
Base frame FURA102
›
Base frame FURA104
›
Housing: mDure
›
Base frame
›
Base plate
›
Side parts: basalt
›
Frame: anthracite
Dimensions and design – Tripod FMTP-MS
290 515
Clearances and line configuration to be maintained
: 5.5 kg
1)
: 10.0 kg
1)
: Stainless steel
1)
: Stainless steel
1)
1
50
mTripod
Technical data
1
50
Mag00817a
19
