SERVICE MANUAL
COMPACT VHS CAMCORDER
For disassembling and assembling of MECHANISM ASSEMBLY, refer to the SERVICE MANUAL No.86700 (MECHANISM ASSEMBLY).
Regarding service information other than these sections, refer to the service manual No. 86712 (GR-SXM49EX).
Also, be sure to note important safety precautions provided in the service manual.
SPECIFICATION
(The specifications shown pertain specifically to the model GR-SXM195AS)
Camcorder
General
Format
: S-VHS/VHS PAL standard
Power source
: DC 11 V } (Using AC Adapter)
DC 6 V } (Using battery pack)
Power consumption
Viewfinder on
: 4.2 W
LCD monitor on
: 4.7 W
Signal system
: PAL-type
Video recording system
Luminance
: FM recording
Colour
: Converted sub-carrier direct recording Conforms to VHS
standard
Cassette
:
Tape speed
SP
: 23.39 mm/sec.
LP
: 11.70 mm/sec.
Recording time (max.)
SP
: 60 minutes
LP
: 120 minutes
(with EC-60 cassette)
Operating temperature
: 0°C to 40°C
Operating humidity
: 35% to 80%
Storage temperature
: –20°C to 50°C
Weight
: Approx. 840 g
Dimensions
: 113 mm x 117 mm x 199 mm
(W x H x D)
(with the LCD monitor closed and with the viewfinder fully
tilted downward)
Pickup
: 1/6" format CCD
Lens
: F1.6, f = 2.7 mm to 43.2 mm, 16:1 power zoom lens with
auto iris and macro control, filter diameter 40.5 mm
GR-SXM195A
/
cassette
S
VHS
PAL
625
Viewfinder
: Electronic viewfinder with 0.5" black/white CRT
White balance adjustment : Auto/Manual adjustment
LCD monitor
: 2.5" diagonally measured, LCD panel/TFT active
matrix system
Speaker
: Monaural
Connectors
: 1 V (p-p), 75 Ø unbalanced, analogue output
Video
(via Video output connector)
Audio
: 300 mV (rms), 1 kØ analogue output
(via Audio output connector)
: Y : 1 V (p-p), 75 Ø, analogue output
S-Video
C : 0.30 V (p-p), 75 Ø, analogue output
AC Adapter
Power requirement
: AC 110 V — 240 V `, 50 Hz/60 Hz
Output
: DC 11 V } , 1 A
Optional Accessories
• Battery Packs BN-V12U, BN-V20U, BN-V400U
• Compact S-VHS (
) Cassettes SE-C45/30
• Compact VHS (
) Cassettes EC-60/45/30
• Active Carrying Bag CB-V7U
Some accessories are not available in some areas.
Please consult your nearest JVC dealer for details on accessories
and their availability.
Specifications shown are for SP mode unless otherwise indicated. E & O.E.
Design and specifications subject to change without notice.
GR-SXM195AS M3C622
No. 86769
2003/05
