JVC GR-FXM373 Instructions Manual

Compact vhs camcorder.
Hide thumbs
Most useful pages: More

Advertisement

COMPACT
VHS CAMCORDER
GR-SXM607
GR-SXM57
GR-SXM47
GR-SX202
GR-SX22
GR-FXM373
GR-FXM37
GR-FX12
VHS
PAL
625
INSTRUCTIONS
S-VHS is compatible with
GR-SXM607/SXM57/SXM47/
SX202/SX22 only.
CONTENTS
Basic Recording .......................... 14
Basic Features ........................... 16
Zooming, 5-Sec. Recording, Picture Stabilizer,
Quick Review, Video Light, Retake
Advanced Features ...................... 18
Snapshot, Night-Scope, Fade/Wipe Effects,
Adjustment, Date/Time Insert, Instant Titles,
Animation, Time-Lapse, Exposure Control,
Focusing, White Balance Adjustment,
Basic Playback ........................... 30
Features .................................. 31
Connections ............................... 32
Playback Zoom .......................... 37
Animation And Time-Lapse ............. 37
Insert Editing ............................. 38
Audio Dubbing ........................... 39
Random Assembly Editing .............. 40
And Indicators ......................... 48
Indications ................................ 50
LYT0671-001C
ENGLISH
2 - 3
4
6 - 13
14 - 29
30 - 34
35 - 43
44 - 45
46 - 47
48 - 51
52 - 54
55
EN

Advertisement

   Related Manuals for JVC GR-FXM373

   Summary of Contents for JVC GR-FXM373

  • Page 1: Table Of Contents

    COMPACT VHS CAMCORDER GR-SXM607 GR-SXM57 GR-SXM47 GR-SX202 GR-SX22 GR-FXM373 GR-FXM37 GR-FX12 INSTRUCTIONS S-VHS is compatible with GR-SXM607/SXM57/SXM47/ SX202/SX22 only. CONTENTS SAFETY PRECAUTIONS AUTOMATIC DEMONSTRATION 4 PROVIDED ACCESSORIES GETTING STARTED RECORDING 14 – 29 Basic Recording ... 14 Basic Features ... 16 Zooming, 5-Sec.
