EARTH LEAKAGE PROTECTION RELAY
User Manual
Version: 7, JULY 2023
Designed and manufactured in Australia by Ampcontrol Pty Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAG-153 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ampcontrol MAG-153

  • Page 1 EARTH LEAKAGE PROTECTION RELAY User Manual Version: 7, JULY 2023 Designed and manufactured in Australia by Ampcontrol Pty Ltd...
  • Page 2 The note symbol highlights key information. Please share these notes with other operators. ENVIRO The enviro (environmental) symbol highlights areas which may have an impact on the surrounding fauna and/or flora. Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 2 of 40...
  • Page 3 MAG-153 Version 7 – JULY 2023 Copyright Notice The Ampcontrol ELV Relay described in this document is the property of AMPCONTROL PTY LTD. It is furnished under a license agreement and is to be used only in accordance with the terms of the agreement.
  • Page 4: Table Of Contents

    9 SETTINGS QUICK REFERENCE GUIDE ..................27 10 EQUIPMENT LIST .......................... 27 10.1 Relay ............................27 10.2 Toroids ............................. 27 10.3 Accessories ..........................28 APPENDIX A: EARTH LEAKAGE PROTECTION REQUIREMENTS ..........29 Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 4 of 40...
  • Page 5 Figure 6.3: Trip Level and Trip Time Settings ..................21 Figure 6.4: ELV Relay Fascia Operators ....................22 Figure 6.5: Functionality of ELV Relay Indicator LEDs ................22 Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 5 of 40...
  • Page 6: Safety And Other Warnings

    As safety depends on the ELV Relay functioning correctly it is highly recommended that all safety functions of the ELV Relay be periodically tested to ensure correct operation. Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 6 of 40...
  • Page 7: Receiving And Storage

    Equipment that is found to be damaged or has been modified away from its published specification must not be used. Please contact Ampcontrol if the equipment is suspected to be different than that ordered or if it does not match the published specifications.
  • Page 8: Product Overview

    3 PRODUCT OVERVIEW 3.1 ELV Earth Leakage Relay The Ampcontrol ELV Earth Leakage Relay is electronic in design and is based on microprocessor technology. It is designed to AS/NZS 2081:2011 Section 6. The ELV Relay uses patented technology (AU2011264414) to characterise earth leakage currents giving superior fault discrimination, particularly in applications involving switching power electronics and variable speed drives.
  • Page 9: Figure 3.2: Core Balance And Series Neutral Installation Types

    (refer to AS/NZS 3190). The ELV Earth Leakage Relay continually monitors the toroid and if the connection is lost the relay will trip and flash the ‘CT Fault’ LED. Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 9 of 40...
  • Page 10: Accessories

    The ELV Relay is designed to be panel mounted, however a DIN rail mounting kit can be separately purchased. Figure 3.4: DIN Rail Mounting Kit (Suit ELM / ELD / ELV) Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 10 of 40...
  • Page 11: Figure 3.5: Lockable Cover (Suit Elm / Eld / Elv Relay)

    Figure 3.5: Lockable Cover (Suit ELM / ELD / ELV Relay) 3.2.4 ELCF Adaptor (Part Number 120255) This accessory allows users of the obsolete ELCF Earth Leakage Relay to upgrade to Ampcontrol’s next generation of earth leakage relays. The ELCF Adaptor seals the larger hole left by the ELCF Relay and provides a mounting point for the ELV Relay.
  • Page 12: Figure 3.7: Elf Adaptor (Suit Elm / Eld / Elv Relay)

    3.2.6 BRAMCO ELF Adaptor (Part Number 175279) This adaptor kit allows users of the BRAMCO ELF and ELF2 Relays to transfer to Ampcontrol’s next generation of earth leakage relays. The ELF Adaptor seals the larger hole (90 x 90 mm) left by the ELF Relay and provides a mounting point for the ELV Relay.
  • Page 13: Installation

    It is extremely important that the limitations and functionality of the ELV Relay are understood to prevent incorrect installation and use from creating a potentially dangerous risk. If in doubt as to the nature of the limitations or their implication, consult a competent authority such as a supervisor or Ampcontrol technical representative.
  • Page 14: Elv Relay Mechanical Installation Information

    4.3.2 DIN Rail Mounting A separately purchasable mounting kit is available for mounting the ELV Relay onto a DIN rail. See the equipment list in Section 10. Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 14 of 40...
  • Page 15: Toroid Mechanical Installation Information

    Only the later EL500 toroid is suitable. This is denoted by the "N" designator at the end of the core type. For this toroid is it W-20N. Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 15 of 40...
  • Page 16: Figure 4.4: El500S/60 Toroid (101658) Dimensions

    Figure 4.4: EL500S/60 Toroid (101658) Dimensions 4.4.4 EL500S/112 (Part Number 101656) The EL500S/112 toroid has a 112 mm window and is panel mounted. Figure 4.5: EL500S/112 Toroid (101656) Dimensions Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 16 of 40...
  • Page 17: Electrical Installation Information

    These terminals are for the connection of the ELV’s earth leakage toroid. The ELV Earth Leakage Relay is designed for use with Ampcontrol EL500S series 100:1 Toroids. They are available with window sizes 25, 60, & 112 mm. These allow trip settings from 30 mA to 2.5 A.
  • Page 18 20 mA represents an earth leakage current of 120 % of the trip level. The 4-20 mA output should be wired as per Figure 4.6. NOTE Ampcontrol does not recommend using the 4-20 mA output as the main tripping signal. All tripping should be carried out by the provided output relays.
  • Page 19: Commissioning And Calibration

    EARTH LINK-3 Main EL Test Contactor CT-COM LINK-2 Circuit CT-SIG LINK-1 Toroidal Current Transformer Loop Resistance < 1Ω To Load Figure 5.1: Earth Leakage Test Circuit Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 19 of 40...
  • Page 20: Product Operation

    This is the default mode and can be activated by bridging links 1 and 3. If no links are bridged the ELV Relay will default to this mode. Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 20 of 40...
  • Page 21: Configuration Of Trip Level And Trip Time

    Trip Level (mA) Time Delay (ms) Switch Position Switch Position ±10 % +0 ms, -20 ms 1000 1500 2000 2500 Figure 6.3: Trip Level and Trip Time Settings Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 21 of 40...
  • Page 22: Resetting The Elv Relay

    This is displayed as a slow flashing on the bar graph for 2s after the reset button is pressed. 6.4 ELV Relay Indicators Figure 6.5: Functionality of ELV Relay Indicator LEDs Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 22 of 40...
  • Page 23: Ct Fault Protection

    (the non-fail safe link is disabled), where the output relay drops out on fault or loss of power. NOTE Power to the relay must be from the line side of the isolating device or from an independent supply. Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 23 of 40...
  • Page 24: Service, Maintenance & Disposal

    • Verify all electrical connections are secure with no loose screw terminals or DIN rail terminals not fitted to rails etc Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 24 of 40...
  • Page 25: Equipment Maintenance

    WARNING! All repairs must be carried out by Ampcontrol only. If a fault develops, return the ELV Relay to Ampcontrol for repair. It is essential that no attempt be made to repair the ELV Relay as any attempt to dismantle or repair the ELV Relay can seriously compromise the safety of the unit and voids product warranty.
  • Page 26: Specifications

    77 w x 47 h x 116 d (mm) Cut Out Size 69 w x 39 h (mm) Weight 500 g IP Rating IP56 (when panel mounted) Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 26 of 40...
  • Page 27: Settings Quick Reference Guide

    One toroid is required per installation. Order based upon required window size. Part Number Description Toroid – 25 mm ID 115437 Toroid – 60 mm ID (Alternative Item 101658) 101649 Toroid – 112 mm ID 101656 Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 27 of 40...
  • Page 28: Accessories

    Adaptor BRAMCO to ELD / ELV / ELM 121023 Clip ELD Panel Mount Retaining (1x) 174378 Clip ELD DIN Rail Mount Retaining (1x) 101108 40 mm M5 Screw 171010 Support Bracket Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 28 of 40...
  • Page 29: Appendix A: Earth Leakage Protection Requirements

    Operating regions to the right of the designated curves are assumed to represent an ‘unacceptable’ risk of fibrillation, even though they may be as low as reasonably achievable in some instances. Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 29 of 40...
  • Page 30: A2 Overview Of Protection Problems

    20-30 mA, with instantaneous operation. (Refer AS/NZS 3190). Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 30 of 40...
  • Page 31: A3 Earth Leakage Systems

    The protective device, such as an Ampcontrol ELV Earth Leakage Relay, would then isolate the cable and contain the sparking within the cable before a heavy short circuit current due to a phase-to-phase fault occurs.
  • Page 32: A4 Earth Leakage Protection And Variable Speed Drives

    50 Hz currents, not DC or high frequency currents so that the relays may not trip, or if they do trip, they may take longer than expected. Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 32 of 40...
  • Page 33 Standards AS/NZS 60479.1 and AS/NZS 60479.2 should be referenced in relation to the effects upon the human body of other supply frequencies. Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 33 of 40...
  • Page 34: A5 Methods Of Earth Leakage Protection

    The effect of this is that a small output may be obtained from the toroid where none would arise if the device were ideal. Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 34 of 40...
  • Page 35 Select the smallest internal diameter toroid, which will allow the cables to fit through. Avoid very large toroids (200 mm) or toroids with square apertures. The ELV Relay has been designed for use with the Ampcontrol EL500S series of toroids. For ordering part numbers, refer to the Equipment List in Section 10.
  • Page 36: Appendix B: The Requirement Of Weighted Wideband Mode

    B2 are not immediately applicable. In such instances individual calculation to determine requirements at the frequency or frequencies in question will be required. Figure B1: Source – AS/NZS 2081:2011 Appendix B Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 36 of 40...
  • Page 37: B2 Wideband Earth Leakage Protection

    Australian mining operations is 5 A, and the requirement for a 10:1 tripping ratio indicates the earth leakage trip level should be no more than 500 mA. Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 37 of 40...
  • Page 38: B3 Weighted Wideband Earth Leakage Protection

    It is impractical for the user to utilise these curve sets directly in touch potential calculations. Both Ampcontrol VSDguard and ELV Relays are capable of weighting the wideband E/L current as a function of frequency according to the curve sets in AS/NZS 60479. This weighting accounts for the differing effects of frequency on fibrillation risk automatically, and while the actual current measurement is wideband, the weighting produces a ’50 Hz equivalent risk’...
  • Page 39 Ampcontrol holds an international patent (PCT/AU2011/000705) in regard to the use of frequency discrimination as applied to earth fault protection. Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version...
  • Page 40: Appendix C: Sil Certificate Of Conformity

    Ampcontrol Pty Ltd – ABN 28 000 915 542 ELV USER MANUAL MAG-153 Version 7 – JULY 2023 APPENDIX C: SIL CERTIFICATE OF CONFORMITY Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version Page 40 of 40...
