ELD V2 – EARTH LEAKAGE PROTECTION RELAY
User Manual
Part Number: 121581
Revision: 9 – March 2014
Designed and manufactured in Australia by Ampcontrol Electronics Pty Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELD V2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ampcontrol ELD V2

  • Page 1 ELD V2 – EARTH LEAKAGE PROTECTION RELAY User Manual Part Number: 121581 Revision: 9 – March 2014 Designed and manufactured in Australia by Ampcontrol Electronics Pty Ltd...
  • Page 2 Ampcontrol Electronics ELDB006R9 ELD V2 USER MANUAL Rev 9 – 03/14, ECN: 10573 WARNING! This safety alert symbol identifies important safety messages in this manual and indicates a potential risk of injury or even death to personnel. When you see this symbol, be alert, your safety is involved, carefully read the message that follows, and inform other operators.
  • Page 3 Before You Begin We would like to take a moment to thank you for purchasing the Ampcontrol ELD V2 Earth Leakage Relay. WARNING!
  • Page 4: Table Of Contents

    4.4 Earth Leakage Toroids ................11 5 COMMISSIONING AND CALIBRATION ............13 5.1 Earth Leakage Test ................. 13 6 ELD V2 OPERATION AND TESTING ............. 14 6.1 Methods of Earth Leakage Protection ............14 6.2 Mechanical Arrangement ................. 15 6.3 Electrical Connections ................16 7 OPERATION SUMMARY ................
  • Page 5: Safety And Other Warnings

    1.1.5 Operation As safety depends on the ELD V2 relay functioning correctly it is highly recommended that all safety functions of the relay be periodically tested to ensure correct operation.
  • Page 6: Receiving And Storage

    Equipment that is found to be damaged or has been modified away from its published specification must not be used. Please contact Ampcontrol if the equipment is suspected to be different than that ordered or if it does not match the published specifications.
  • Page 7: Installation

    These instructions have been designed to assist users of the ELD V2 relay with installation. Before the ELD V2 relay can be installed, there are a number of things that need to be considered and understood to prevent incorrect or unsafe operation of the relay or the system into which it is installed.
  • Page 8 Ampcontrol Electronics ELDB006R9 ELD V2 USER MANUAL Rev 9 – 03/14, ECN: 10573  Modifications must not be made to any part of the relay. As supplied, the unit is built to, and complies with the relevant standards. Modifications to its construction will render the unit non- compliant.
  • Page 9: Overview Of Earth Leakage Protection

    The protective device, such as an Ampcontrol ELD earth leakage relay, would then isolate the cable and contain the sparking within the cable before a heavy short circuit current due to a phase to phase fault occurs.
  • Page 10: Earth Leakage Systems

    Ampcontrol Electronics ELDB006R9 ELD V2 USER MANUAL Rev 9 – 03/14, ECN: 10573 A definite time operating characteristic is provided with adjustable trip sensitivity and time delay. Time delay between protective units is introduced to allow the unit close to the fault to isolate the faulty circuit without causing the healthy part of the system to be de-energised.
  • Page 11: Earth Leakage Toroids

    Select the smallest internal diameter toroid, which will allow the cables to fit through. Avoid very large toroids (200mm) or toroids with square apertures. Only use approved toroids specified by Ampcontrol as these have been designed to minimise the problem.
  • Page 12 Ampcontrol Electronics ELDB006R9 ELD V2 USER MANUAL Rev 9 – 03/14, ECN: 10573 exists for the shield to become an earth loop, having finite resistance and injecting noise into the toroid leads. vii. To reduce the possibility of noise pickup, install twisted pair cable between the ELD relay and the toroid.
  • Page 13: Commissioning And Calibration

    Ampcontrol Electronics ELDB006R9 ELD V2 USER MANUAL Rev 9 – 03/14, ECN: 10573 5 COMMISSIONING AND CALIBRATION Prior to being put into service, the electrical protection system must be correctly commissioned. This manual does not cover system commissioning; the full scope of commissioning tests should be determined during the risk assessment or FMEA covering the design of the electrical protection system.
  • Page 14: Eld V2 Operation And Testing

    ‘Har.Trip’ LED (Harmonic Trip) will be illuminated. The ELD V2 Earth Leakage Relay is housed in a stainless steel case and can be either ‘DIN Rail’ or ‘Panel’ mounted through a 69 x 39mm cut out. When panel mounted the front of the ELD relay is designed to provide IP56 ingress protection.
  • Page 15: Mechanical Arrangement

    6.2.2 Front Panel The front fascia of the ELD V2 relay consists of a two switches for selection of the Trip Level and Delay Time, five (5) indication LEDs for diagnostics support and a ten-segment LED bar graph to display the level of Earth Leakage current being measured.
  • Page 16: Electrical Connections

    Figure 3 shows a typical wiring diagram for the application of the ELD relay. Figure 3: ELD Typical Electrical Application 6.3.1 Supply The ELD V2 relay is able to operate across both AC and DC voltages ranges. The supply voltage can be 32-110VAC +/- 20% at 50Hz, or 20-185VDC. 6.3.2 Reset...
  • Page 17: Operation Summary

    Ampcontrol Electronics ELDB006R9 ELD V2 USER MANUAL Rev 9 – 03/14, ECN: 10573 7 OPERATION SUMMARY 7.1 Rotary Switches Configuration 7.1.1 Trip Level selection The trip level can be selected via one of the rotary switches at the front of the unit. The trip level represents the threshold of current measured by the earth leakage toroid, above which a trip condition occurs.
  • Page 18: Service, Maintenance & Disposal

    This type of inspection may involve opening cabinets to gain access to the ELD V2 relay and other equipment. This level of inspection may also include cleaning display windows that have become obscured by dirt.
  • Page 19: Disposal

    Ampcontrol Electronics ELDB006R9 ELD V2 USER MANUAL Rev 9 – 03/14, ECN: 10573 8.3 Disposal The electronic equipment discussed in this manual must not be treated as general waste. By ensuring that this product is disposed of correctly you will be helping to prevent potentially negative consequences for the environment and human health which could otherwise be caused by incorrect waste handling of this product.
  • Page 20: Specifications

    Ampcontrol Electronics ELDB006R9 ELD V2 USER MANUAL Rev 9 – 03/14, ECN: 10573 9 SPECIFICATIONS Supply Voltage Voltage 32-110VAC +/- 20%, 50Hz 20-185VDC Power Consumption < 3W Relay Contacts Contacts 1 x NO / 1 x CO Ratings 1.6A, 400VA <...
  • Page 21: Equipment List

    Ampcontrol Electronics ELDB006R9 ELD V2 USER MANUAL Rev 9 – 03/14, ECN: 10573 10 EQUIPMENT LIST Part Number Description 115161 ELD V2 Earth Leakage Relay 101399 ELD DIN Rail Mounting Kit 120255 ELD-ELC/F Adapter Kit Toroid – 25mm ID 115437 Toroid –...
  • Page 22 APPENDIX A - DRAWINGS...
  • Page 23 Ampcontrol Electronics ELDB006R9 ELD V2 USER MANUAL Rev 9 – 03/14, ECN: 10573 Page 2 of 3 ELDB006R9 15/07/2015 17:44...
  • Page 24 Ampcontrol Electronics ELDB006R9 ELD V2 USER MANUAL Rev 9 – 03/14, ECN: 10573 Page 3 of 3 ELDB006R9 15/07/2015 17:44...
