SPECIFICATIONS
| Driver: | --- |
| Noise Canceling: | DSP ENC |
| Talk Time: | Up to 26 Hours |
| Charging Time: | Up to 2 Hours |
| Stand-by Time: | Up to 200 Hours |
| Speaker Sensitivity: | 119±5dB |
| Wireless: | V5.0 |
| Operation Range: | 30 Ft |
| Battery: | 250mAh |
| Charging Interface: | Type-C |
PRODUCT DESCRIPTION
PAIRING TO ONE DEVICE
- While headset is off, press and hold "MFB" for 4-6 seconds to enter pairing mode. The LED will alternate flashing blue and red.
- In your phone's or your PC's BT pairing screen, click DELTON30X to connect to the headset. The LED will slow flash blue when the headset is connected.
PAIRING TO TWO DEVICES
- Follow BT PAIRING INSTRUCTIONS with first phone or PC then turn off BT function of first phone or PC. The headset will enter pairing mode automatically and LED will alternate flashing blue and red.
- Turn on the BT function of second phone or PC to search and connect to DELTON30X. The LED will slow flash blue when the headset is connected.
- Turn on BT function of first phone or PC, click to reconnect "DELTON30X"on BT lists. Headset is connected with two devices now.
GENERAL FUNCTIONS
Power & Pairing Mode
MFB Function
Microphone Mute
Tips: Please mind that it only can be used when connect with mobile phone.
CALL FUNCTIONS
Answer Call: Short press "MFB" to answer an incoming call
End Call: Short press "MFB" to hang up the call
Reject Call: Long press "MFB" for 1 second to reject incoming calls
Mute Mic: Short press the Microphone Mute Button
Mic On (Unmute): Short press the Microphone Mute Button
Redial Last Number: Double click "MFB" to redial the last dialed phone number (when phone is in standby or playback mode).
Three-Party Call: Double click "MFB" to hold the current call and connect to the new call. Double click "MFB" again to switch between the reserved call and the current call (short pressing will end the call)
POWER SAVING FUNCTIONS
Automatic Shutdown: Automatically shuts down when there is no connection for more than 10 minutes.
LED INDICATOR
| Mode | Indicator |
| Power ON | Blue LED flash 2 times |
| Power OFF | Red LED flash 2 times |
| Pairing Mode | Blue and Red LED flashing alternately |
| Clear Record | Blue and RED LED flash 1 time |
| Connected Standby Mode | Blue LED flash every 10 seconds |
| Playing Music | Blue LED flash every 10 seconds |
| Dialing/Talking | Blue LED flash every 10 seconds |
| Low Battery | Red LED flash |
| Charging | Red LED is steady on |
| Full Charged | Red LED will turn off |
| Mic Mute | Red LED flashes 1 time every 6 seconds |
INSTRUCTIONS FOR THE DOCK
Set up: Plug the included USB Dongle into PC/laptop. Connect your headset.
NOTE: LED indicator is on the USB dongle.
CHARGING
WARRANTY
To view our warranty policy or to submit a claim, please visit overtimebrands.com/pages/warranty-information.
Register your product at WARRANTY overtimebrands.com
