- Page 1 Pasta Cookers Models CE-CN-0011-NG, 0022-NG Items 47714, 48000 Instruction Manual Revised - 02/01/2024 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model CE-CN-0011-NG / Model CE-CN-0022-NG Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 6 Technical Specifications -------------------------------------------------------------------------- 6 Installation --------------------------------------------------------------------------------------- 6 - 8 Operation ----------------------------------------------------------------------------------------- 8 - 9 Maintenance --------------------------------------------------------------------------------------- 10... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 1 YEAR PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally. Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not improper use.
-
Page 6: Technical Specifications
Safety and Warranty DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT! Technical Specifications Model CE-CN-0011-NG CE-CN-0022-NG Capacity 41.6 L / 11 Gal 83.3 L / 22 Gal Number of Baskets Temperature Range 50 - 125°C / 122 - 257°F... -
Page 7: Installation
Installation cooker front, sides, and rear must be kept clear and unobstructed. Cooker must be installed in an area with an adequate air supply and adequate ventilation. Adequate distances must be maintained from the flue outlet of the cooker to the lower edge of the ventilation filter bank. NATIONAL CODE REQUIREMENTS The type of gas for which the cooker is equipped is marked on the data plate attached to the inside of the cooker door. -
Page 8: Operation
Installation and to the building gas line. NOTE: some noodle cookers are configured for a rigid connection to the gas supply line. These units are connected directly to the gas supply line. When using thread compound, use very small amounts on male threads only. Use a pipe thread compound that is not affected by the chemical action of LP gases (Loctite™... - Page 9 Operation FILLING WITH WATER Turn on faucet to fill the water tank with water. Do not exceed the max water-level. THERMOSTAT OPERATION Note: the boiling point of water might vary for different altitudes. The thermostat is connected to a graduated knob located inside the cooker door. Rotating the knob clockwise to the desired cooking temperature (set point) directly adjusts the thermostat to that temperature.
-
Page 10: Maintenance
Maintenance DAILY CHECKS AND SERVICES INSPECT COOKER AND ACCESSORIES FOR DAMAGE Look for loose wires, leaks, foreign material in water tank or inside cabinet, and any other indications that the noodle cooker and accessories are not ready and safe for operation. Inspect the burner deflectors to verify that each is positioned directly above its orifice, and that the flame ignites approximately 2½”... -
Page 11: Troubleshooting
Troubleshooting OPERATOR TROUBLESHOOTING The tables that follow provide operators with a list of possible malfunctions, the probable causes of the malfunctions, and the corrective actions to take to correct the problem. In some cases the operator may not be able to correct the problem, but will at least be able to accurately diagnose the problem, and that will assist a qualified service technician in restoring the equipment to full operation in the shortest possible time. - Page 12 Troubleshooting Pilot repeatedly goes out. Clogged pilot orifice. Use a small wire to clear obstruction from pilot orifice. Pilot flame blowing away from Eliminate draft in kitchen. pilot generator (excessive draft in kitchen). Pilot generator not inserted fully Reinsert pilot generator into pilot into pilot burner.
-
Page 13: Parts Breakdown
Parts Breakdown Model CE-CN-0011-NG 47714... - Page 14 Parts Breakdown Model CE-CN-0011-NG 47714 Item No. Description Position Item No. Description Position Item No. Description Position AP112 Tank Assembly for 47714 AP129 1/2 to 3/4 Street Elbow for 47714 AP142 Faucet Nut for 47714 AP113 Flue Cover for 47714...
- Page 15 Parts Breakdown Model CE-CN-0022-NG 48000...
- Page 16 Parts Breakdown Model CE-CN-0022-NG 48000 Item No. Description Position Item No. Description Position Item No. Description Position AP492 Tank Assembly for 48000 AN718 Elbow for 48000 AP141 Brass Olive for 48000 AP493 Flue Cover for 48000 AN717 Combination Valve NG for 48000 26.1 AP142 Faucet Nut for 48000...
-
Page 17: Notes
Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________... - Page 18 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
-
Page 19: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 20 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
