Endless Pools R200 Pre-Delivery Instructions page 8

ELECTRICAL REQUIREMENTS
230 VAC, 48A, 60Hz,
(FIELD WIRING)
230 VAC, 60 Amp
2-POLE
CIRCUIT BREAKER
(NON GFCI)
L1
#6 AWG WHITE, NEUTRAL
L2
#6 AWG GREEN, GROUND
GRD
#6 AWG BLUE, L1
60A
#6 AWG RED, L2
MAIN SERVICE
ELECTRICAL
PANEL
LESS THAN 100 FT.
230 VAC, 48A, 60Hz,
(FIELD WIRING)
230 VAC, 60 Amp
2-POLE
CIRCUIT BREAKER
(NON GFCI)
L1
#6 AWG WHITE, NEUTRAL
L2
#6 AWG GREEN, GROUND
GRD
#6 AWG BLUE, L1
60A
#6 AWG RED, L2
MAIN SERVICE
ELECTRICAL
PANEL
LESS THAN 100 FT.
E500 / E700
N
L2, HOT, #10 AWG RED
30A L1, HOT, #10 AWG BLUE
1
L2, HOT, #10 AWG RED
L1, HOT, #10 AWG BLUE
30A
2 N, NEUTRAL, #10 AWG WHITE
GROUND, #10 AWG GREEN
SUB-PANEL
MORE THAN 5 FEET
WITH GFCI
THE SUB-PANEL MUST BE
BREAKERS
WITHIN SIGHT OF THE SPA
P/N 304130
DO NOT EXCEED 50 FEET
X2000
E550 / E2000
N
L2, HOT, #10 AWG RED
30A L1, HOT, #10 AWG BLUE
1
N, NEUTRAL, #10 AWG WHITE
L2, HOT, #10 AWG RED
30A L1, HOT, #10 AWG BLUE
2 N, NEUTRAL, #10 AWG WHITE
GROUND, #10 AWG GREEN
SUB-PANEL
MORE THAN 5 FEET
WITH GFCI
THE SUB-PANEL MUST BE
BREAKERS
WITHIN SIGHT OF THE SPA
P/N 304130
DO NOT EXCEED 50 FEET
Page 8
GRN
MAIN INPUT
CIRCUIT 1
CIRCUIT 2
FITNESS SYSTEM JUNCTION BOX
GRN
MAIN INPUT
CIRCUIT 1
CIRCUIT 2
FITNESS SYSTEM JUNCTION BOX
