ASRock Industrial iEP-9010 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
iEPF-9000S-EX4
User Manual
iEPF-9002S-EX4
iEP(F)-9010 Series
iEP(F)-9020 Series
Copyright©2022 ASRock Industrial Computer Corp. All rights reserved.
iEP-9000E
iEP-9002E
User Manual
Version 1.0
Published August 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iEP-9010 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASRock Industrial iEP-9010 Series

Summary of Contents for ASRock Industrial iEP-9010 Series

  • Page 1 User Manual iEPF-9002S-EX4 iEP(F)-9010 Series iEP-9000E iEP-9002E iEP(F)-9020 Series User Manual Version 1.0 Published August 2022 Copyright©2022 ASRock Industrial Computer Corp. All rights reserved.
  • Page 2 ASRock Industrial Computer Corp. has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 3 California Legislature. When you discard the Lithium battery in California, USA, please follow the related regulations in advance. “Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/ perchlorate” ASRock Industrial Website: https://www.ASRockInd.com Important Safety Instructions For user safety, please read and follow all instructions, Warnings, Cautions, and Notes marked in this manual and on the associated device before handling/operating the device, to avoid injury or damage.
  • Page 4 IEC 60950-1/ IEC 62368-1 approved) whose output complies with ES1/SELV. To reduce potential safety issues, only the AC adapter provided with the product, a replacement AC adapter provided by ASRock Industrial or an agency, or an AC adapter purchased as an accessory from ASRock Industrial or an agency should be used with the product.
  • Page 5 13.75A. If you need further assistance, contact ASRock Industrial for additional information. 20. The ambient temperature of the iEP-9010E & iEP-9020E series: 70 °C (158°F) max.; the ambient temperature of the iEPF-9010S & iEPF-9020S series: 75 °C (167°F) max. The terminal block is suitable for V+V-, with 3 units each (16~18AWG), totaling 6 units.
  • Page 6 HDMI Licensing LLC in the United States and other countries. Contact Information If you need to contact ASRock Industrial or want to know more about ASRock Industrial, you’re welcome to visit ASRock Industrial’s website at https://www.ASRockInd.com; or you may contact your dealer for further information.

  • Page 7: Table Of Contents

    Contents Chapter 1 Introduction 1.1 Key Features 1.2 Package List 1.3 Order Information 1.4 Optional Items 1.5 Serial Number Label 1.5.1 Serial Number Label Location 1.5.2 Serial Number Label Illustration 1.6 Specifications 1.7 CPU Support List 1.8 Dimensions and Size 1.9 Block Diagram Chapter 2 Product Overview 2.1 System Front Panel...
  • Page 8 2.4.3 Ignition Control 2.5 Other Boards 2.5.1 DSC-SATA001-WT or DSC-SATA002-WT 2.5.1.1 DSC-SATA001-WT Layout and I/O Connectors 2.5.1.2 DSC-SATA002-WT Layout and I/O Connectors 2.5.2 DSC-PSE002-WT Layout and I/O Connectors 2.5.3 DSC-COMDIO002-WT Layout and I/O Connectors 77 2.5.4 DSC-COMDIO003-WT Layout and I/O Connectors (Optional) 2.5.5 DSC-SLOT003-WT Layout and I/O Connectors (9010S/9012S &...
  • Page 9 3.9 How to Install the Riser Card 3.10 How to Install the Mini-PCIe Card 3.11 How to Install the WiFi Module (M.2 Key E Socket (2230)) 3.12 How to Install the 4G / 5G module (M.2 Key B Socket (2280/3042/3052)) 3.13 How to Install the WiFi/4G/5G Antennas and Cables 114 3.13.1 Antennas 3.13.2 SMA Cables...
  • Page 10 4.5 Security Screen 4.6 Boot Screen 4.7 Exit Screen Chapter 5 Appendix Appendix 1 Power Consumption Appendix 2 Link to the API Library Appendix 3 How to Install Power Supply or Power Adapter...

  • Page 11: Chapter 1 Introduction

    In case any modifications of this documentation occur, the updated version will be available on ASRock Industrial’s website without further notice. If you require technical support related to this product, please visit our website for specific information about the model you are using.
  • Page 12 • Powerful Edge AI acceleration enabled by the most flexible mechanical, thermal, and power design, with support for 275mm x 124 mm x 60 mm (L x H x D) max. and up to 300W graphic cards iEP-9010E • Intel® 12th Gen Core™ Processors with R680E Chipset •...
  • Page 13 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E • Powerful Edge AI acceleration enabled by the most flexible mechanical, thermal, and power design, with support for 275mm x 124 mm x 60 mm (L x H x D) max. and up to 300W graphic cards iEP-9020E •...

  • Page 14: Package List

    1.2 Package List Accessories Q'ty Picture Description Protect the device from Rubber Foot damage during a move. 2 M3x8 Screw for To fix the rubber foot. rubber foot To attach the device to Desk Mount any horizontal surface. M3x5 Screw for To fix the desk mount.
  • Page 15 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Accessories Q'ty Picture Description SODIMM To fix the SODIMM Bracket w/ 13G030035000AI Heatsink. mylar (left side) SODIMM To provide better Heatsink (right 13G070640010AI heat dissipation for side) SODIMM.

  • Page 16: Order Information

    1.3 Order Information Model Name Description Intel®12th Gen Core™ Processors with R680E iEP-9010E 90PPG220-20000000 chipset, W/O CPU, RAM, SSD, ADAPTER Intel i7-12700E CPU, Wide Temperature DDR4 3200MHz SODIMM 16GB 260P iEP-9010E 90PPG220-21110000 running on 2933MHz x2, Wide Temperature M.2 2280 PCIE Gen3x4 SSD 256GB x1, W/O Adapter Intel®12th Gen Core™...

  • Page 17: Optional Items

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 1.4 Optional Items Model Name Description ACPWR CORD EU+KR; 14G110001800AK 立訊 /L72AC007-SD-R L=1.8M ( 品頭 ) AC POWER CORD CN 14G110001300AK I-SHENG/Y646B301912180Q L:1.8M ( 品頭 ) US PWR CORD, L:1.5M 14G110001100AK 立訊...

  • Page 18: Specifications

    1.6 Specifications iEPF-9010S-EY4 Intel® 12th Gen Core™, Pentium or Celeron Processors Processor Chipset Intel® R680E System Socket LGA 1700 Dual Channel DDR4 2933MHz Technology (ECC memory supported by R680E + Selected CPU) Memory Capacity 128 GB (32 GB per DIMM) Socket 4 x 260-pin SO-DIMM Controller...
  • Page 19 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E DisplayPort HDMI Ethernet 5 x 2.5G LAN 6 x USB 3.2 Gen2x1, 1 x USB 2.0 internal connector w/ Front I/O lock function Audio 1 x Mic-in, 1 x Line-out 4 x RS232/422/485 2 x RS232...
  • Page 20 iEPF-9012S-EY4 Intel® 12th Gen Core™, Pentium or Celeron Processors Processor Chipset Intel® H610 System Socket LGA 1700 Technology Dual Channel DDR4 2933MHz Memory Capacity 64 GB (32 GB per DIMM) Socket 2 x 260-pin SO-DIMM Controller Intel® UHD Graphics DisplayPort 1.4a , DP++ DisplayPort Max resolution up to 4096x2160@60Hz Graphics...
  • Page 21 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Output From Super I/O to drag RESETCON# Watchdog Timer Interval 256 Segments, 0, 1, 2, ...255sec 9V~36V VDC with Ignition control and remote power on/off switch.
  • Page 22 iEP-9010E Intel® 12th Gen Core™, Pentium or Celeron Processors Processor Chipset Intel® R680E System Socket LGA 1700 Dual Channel DDR4 2933MHz Technology (ECC memory supported by R680E + Selected CPU) Memory Capacity 128 GB (32 GB per DIMM) Socket 4 x 260-pin SO-DIMM Controller Intel®...
  • Page 23 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 9V~36V VDC with Ignition control and remote power on/off switch. Power Input PWR 80V Surge Protection, OVP, UVP, OCP and reverse Requirements protection Ignition Power Input w/ 13-mode condition 35W CPU: -40°C~70°C (-40°F~158°F) Operating 46W~65W CPU: -40°C~50°C (-40°F~122°F)
  • Page 24 iEP- 9012E Intel® 12th Gen Core™, Pentium or Celeron Processors Processor Chipset Intel® H610 System Socket LGA 1700 Technology Dual Channel DDR4 2933MHz Memory Capacity 64 GB (32 GB per DIMM) Socket 2 x 260-pin SO-DIMM Controller Intel® UHD Graphics DisplayPort 1.4a , DP++ DisplayPort Max resolution up to 4096x2160@60Hz...
  • Page 25 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 9V~36V VDC with Ignition control and remote power on/off switch. Power Input PWR 80V Surge Protection, OVP, UVP, OCP and reverse Requirements protection Ignition Power Input w/ 13-mode condition 35W CPU: -40°C~70°C (-40°F~158°F) Operating 46W~65W CPU: -40°C~50°C (-40°F~122°F)
  • Page 26 iEPF-9020S-EY4 Intel® 13th Gen Core™ Processors Processor Chipset Intel® R680E System Socket LGA 1700 Dual Channel DDR4 2933MHz Technology (ECC memory supported by R680E + Selected CPU) Memory Capacity 128 GB (32 GB per DIMM) Socket 4 x 260-pin SO-DIMM Controller Intel®...
  • Page 27 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E DisplayPort HDMI Ethernet 5 x 2.5G LAN 6 x USB 3.2 Gen2x1, 1 x USB 2.0 internal connector w/ Front I/O lock function Audio 1 x Mic-in, 1 x Line-out 4 x RS232/422/485 2 x RS232...
  • Page 28 iEPF-9022S-EY4 Intel® 13th Gen Core™ Processors Processor Chipset Intel® H610 System Socket LGA 1700 Technology Dual Channel DDR4 2933MHz Memory Capacity 64 GB (32 GB per DIMM) Socket 2 x 260-pin SO-DIMM Controller Intel® UHD Graphics DisplayPort 1.4a , DP++ DisplayPort Max resolution up to 4096x2160@60Hz Graphics...
  • Page 29 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Output From Super I/O to drag RESETCON# Watchdog Timer Interval 256 Segments, 0, 1, 2, ...255sec 9V~36V VDC with Ignition control and remote power on/off switch.
  • Page 30 iEP-9020E Intel® 13th Gen Core™ Processors Processor Chipset Intel® R680E System Socket LGA 1700 Dual Channel DDR4 2933MHz Technology (ECC memory supported by R680E + Selected CPU) Memory Capacity 128 GB (32 GB per DIMM) Socket 4 x 260-pin SO-DIMM Controller Intel®...
  • Page 31 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 9V~36V VDC with Ignition control and remote power on/off switch. Power Input PWR 80V Surge Protection, OVP, UVP, OCP and reverse Requirements protection Ignition Power Input w/ 13-mode condition 35W CPU: -40°C~70°C (-40°F~158°F) Operating 46W~65W CPU: -40°C~50°C (-40°F~122°F)
  • Page 32 iEP- 9022E Intel® 13th Gen Core™ Processors Processor Chipset Intel® H610 System Socket LGA 1700 Technology Dual Channel DDR4 2933MHz Memory Capacity 64 GB (32 GB per DIMM) Socket 2 x 260-pin SO-DIMM Controller Intel® UHD Graphics DisplayPort 1.4a , DP++ DisplayPort Max resolution up to 4096x2160@60Hz Graphics...
  • Page 33 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 9V~36V VDC with Ignition control and remote power on/off switch. Power Input PWR 80V Surge Protection, OVP, UVP, OCP and reverse Requirements protection Ignition Power Input w/ 13-mode condition 35W CPU: -40°C~70°C (-40°F~158°F) Operating 46W~65W CPU: -40°C~50°C (-40°F~122°F)

  • Page 34: Cpu Support List

    1.7 CPU Support List The Performance of CPUs over 80W will be limited due to power design. iEPF-9010S-EY4 Since Socket Family Number Core Frequency Cache Power BIOS Alder 1700 Core i9 i9-12900TE(C0) 1.1GHz 30MB P1.20 Lake-S Alder 1700 Core i9 i9-12900E(C0) 2.3GHz 30MB...
  • Page 35 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E iEPF-9012S-EY4 Since Socket Family Number Core Frequency Cache Power BIOS Alder 1700 Core i9 i9-12900TE(C0) 1.1GHz 30MB P1.20 Lake-S Alder 1700 Core i9 i9-12900E(C0) 2.3GHz 30MB P1.20...
  • Page 36 Since Socket Family Number Core Frequency Cache Power BIOS Pentium Alder 1700 G7400T(H0) 3.1GHz P1.20 Gold Lake-S Pentium Alder 1700 G7400(H0) 3.7GHz P1.20 Gold Lake-S Alder 1700 Celeron G6900TE(H0) 2.4GHz P1.20 Lake-S Alder 1700 Celeron G6900T(H0) 2.8GHz P1.20 Lake-S Alder 1700 Celeron G6900(H0)
  • Page 37 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E iEP-9010E Since Socket Family Number Core Frequency Cache Power BIOS Alder 1700 Core i9 i9-12900TE(C0) 1.1GHz 30MB P1.20 Lake-S Alder 1700 Core i9 i9-12900E(C0) 2.3GHz 30MB P1.20...
  • Page 38 iEP- 9012E Since Socket Family Number Core Frequency Cache Power BIOS Alder 1700 Core i9 i9-12900TE(C0) 1.1GHz 30MB P1.20 Lake-S Alder 1700 Core i9 i9-12900E(C0) 2.3GHz 30MB P1.20 Lake-S Alder 1700 Core i9 i9-12900(C0) 2.4GHz 30MB P1.20 Lake-S Alder 1700 Core i7 i7-12700TE(C0) 1.4GHz 25MB...
  • Page 39 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Since Socket Family Number Core Frequency Cache Power BIOS Pentium Alder 1700 G7400T(H0) 3.1GHz P1.20 Gold Lake-S Pentium Alder 1700 G7400(H0) 3.7GHz P1.20 Gold Lake-S Alder 1700...
  • Page 40 iEPF-9020S-EY4 Since Socket Family Number Core Frequency Cache Power BIOS Raptor 1700 Core i9 i9-13900TE(B0) 1.0GHz 36MB P1.30 Lake-S Raptor 1700 Core i9 i9-13900T(B0) 1.1GHz 36MB P1.30 Lake-S Raptor 1700 Core i9 i9-13900K(B0) 3.0GHz 36MB 125W P1.30 Lake-S Raptor 1700 Core i9 i9-13900E(B0) 1.8GHz...
  • Page 41 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E iEPF-9022S-EY4 Since Socket Family Number Core Frequency Cache Power BIOS Raptor 1700 Core i9 i9-13900TE(B0) 1.0GHz 36MB P1.20 Lake-S Raptor 1700 Core i9 i9-13900T(B0) 1.1GHz 36MB P1.20...
  • Page 42 iEP-9020E Since Socket Family Number Core Frequency Cache Power BIOS Raptor 1700 Core i9 i9-13900TE(B0) 1.0GHz 36MB P1.30 Lake-S Raptor 1700 Core i9 i9-13900T(B0) 1.1GHz 36MB P1.30 Lake-S Raptor 1700 Core i9 i9-13900K(B0) 3.0GHz 36MB 125W P1.30 Lake-S Raptor 1700 Core i9 i9-13900E(B0) 1.8GHz...
  • Page 43 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E iEP- 9022E Since Socket Family Number Core Frequency Cache Power BIOS Raptor 1700 Core i9 i9-13900TE(B0) 1.0GHz 36MB P1.20 Lake-S Raptor 1700 Core i9 i9-13900T(B0) 1.1GHz 36MB...

  • Page 44: Dimensions And Size

    1.8 Dimensions and Size iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEPF-9020S-EY4 / iEPF-9022S- Front View iEPF-9010S-EY4 / iEPF-9020S-EY4 iEPF-9012S-EY4 / iEPF-9022S-EY4...
  • Page 45 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Top View Right-Side View...
  • Page 46 Left-Side View Rear-Side View...
  • Page 47 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Bottom View Desk Mounting Bracket 240mm 200mm...
  • Page 48 iEP-9010E / iEP-9012E / iEP-9020E / iEP-9022E Front View iEP-9010E / iEP-9020E iEP-9012E / iEP-9022E Top View...
  • Page 49 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Right-Side View Left-Side View Rear-Side View...
  • Page 50 Bottom View Desk Mounting Bracket 240mm 200mm...

  • Page 51: Block Diagram

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 1.9 Block Diagram iEP(F)-9010 & 9020 Series DSB-1210-WT SO-DIMM Channel A DDR4 Display port Intel (A1 A2) 2933MHz Connector Alder Lake-S & SO-DIMM Channel B DDR4 Raptor Lake-S &...
  • Page 52 iEP(F)-9012 & 9022 Series DSB-1212-WT SO-DIMM Channel A DDR4 Display port Intel (A1) 2933MHz Connector Alder Lake-S & SO-DIMM Channel B DDR4 Raptor Lake-S & 2933MHz (B1) HDMI Raptor Lake-S refresh PCIe x16 Gen4 PCIe x16 Slot Processor DSC-SLOT003-WT CH7517A- LGA-1700 Connector Intel...

  • Page 53: Chapter 2 Product Overview

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Chapter 2 Product Overview This chapter provides diagrams that display the location of important components of the system. 2.1 System Front Panel 10 11 Item Description 1, 9, 10, 32,...
  • Page 54 Item Description M.2 Slot (Key M) Status If M.2 slot is populated with M.2 module and working, it will show a blinking green. The Mic-in audio connector on the I/O panel supports 5.1 channel HD audio and fully complies Audio Mic-in & Line- 14, 15 with Intel®...

  • Page 55: System Front Panel I/O Functions

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 2.1.1 System Front Panel I/O Functions Serial Ports (COM1~COM6) No. 3 : COM1 No. 2 : COM2 No. 5 : COM3 No. 4 : COM4 No.
  • Page 56 Digital Input/Output No. 6 : Digital Input No. 7 : Digital Output (2) System front panel location (3) Icon / Pin definition: Signal Signal DIO0(SIO_GP70) DIO8(SIO_GP80) DIO1(SIO_GP71) DIO9(SIO_GP81) DIO2(SIO_GP72) DIO10(SIO_GP82) DIO3(SIO_GP73) DIO11(SIO_GP83) DIO4(SIO_GP74) DIO12(SIO_GP84) DIO5(SIO_GP75) DIO13(SIO_GP85) DIO6(SIO_GP76) DIO14(SIO_GP86) DIO7(SIO_GP77) DIO15(SIO_GP87)
  • Page 57 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E HDMI2.0b Port No. 12 : HDMI2.0b Port (2) System front panel location (3) Icon / Pin definition: Signal Signal TMDS Data2+ TMDS Clock Shield TMDS Data2 Shield TMDS Clock- TMDS Data2-...
  • Page 58 M.2 Slot (Key M) Status LED No. 13 : M.2 Key-M (2) System front panel location (3) Description: Status Description M.2 Slot (Key M) on the motherboard is populated with a M.2 Blinking Green module. Empty M.2 Slot (Key M)
  • Page 59 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Display Ports 1.4a No. 17 : Display Port (2) System front panel location (3) Icon / Pin definition: Signal Signal ML_Lane 0(p) ML_Lane 3(n) ML_Lane 0(n) ML_Lane 1(p) AUX_CH(p)
  • Page 60 IGN Status LED No. 18 : IGN Status LED (2) System front panel location (3) Description: Status Description Solid Green The IGN connector is connected and working normally. No connection...
  • Page 61 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E USB 3.2 Gen2/USB 2.0 Ports No. 19 : USB 3.2 Gen2x1 Ports (R680E SKU) USB 2.0 Ports (H610 SKU) (2) System front panel location (3) Icon / Pin definition: USB 3.2 Gen2x1 Signal...
  • Page 62 VGA Port No. 20 : VGA Port (2) System front panel location (3) Icon / Pin definition: Signal Signal DATA- DATA+ HSync RED_RTN VSync GREEN_RTN BLUE_RTN...
  • Page 63 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E PoE Ports Status LED No. 21 : PoE1 Port Status LED (PoE1) No. 22 : PoE2 Port Status LED (PoE2) (2) System front panel location (3) Description: PoE Port Status...
  • Page 64 Ethernet Ports LED No. 23 : LAN RJ-45 PoE Port (PoE 2) No. 24 : LAN RJ-45 Port (LAN 3) No. 25 : LAN RJ-45 PoE Port (PoE 1) No. 26 : LAN RJ-45 Port (LAN 2) No. 27 : LAN RJ-45 Port (LAN 1) (2) System front panel location (3) Icon / Pin definition: LAN Port...
  • Page 65 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E USB 3.2 Gen1/Gen2 Ports No. 28 : 4 x USB3.2 Gen2 x1 Ports (R680E SKU) 2 x USB 3.2 Gen2x1 Ports and 2 x USB 3.2 Gen1x1 Ports (H610 SKU) (2) System front panel location (3) Icon / Pin definition: USB 3.2 Gen2x1...

  • Page 66: Hdd Panel

    2.2 HDD Panel iEP(F)-9010 & 9020 Series Description 2.5" HDD/SSD Tray (HDD0) 2.5" HDD/SSD Tray (HDD1) 2.5" HDD/SSD Tray (HDD3) 2.5" HDD/SSD Tray (HDD2) Side Vent (iEPF-9010S & 9020S Series only) 2 x SIM Card Slots (SIM1 is for M.2 B key slot, SIM2 is for Mini PCIe slot) System Heatsink...

  • Page 67: Drive Tray Leds

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 2.3 Drive Tray LEDs Description HDD Power LED HDD Activity LED Status LED Definitions HDD LED Type Status Description Blue HDD powered-on HDD Power LED No power to HDD Solid Green HDD active...

  • Page 68: Motherboard

    2.4 Motherboard 2.4.1 Motherboard Layout for iEP(F)-9010 & 9020 Series Top Side 6 7 8 PWR_BAT1 CLRMOS2 CLRMOS1 SIO_AT1 SMBUS_TEST1 ATX12V1 DC_IN1 BUZZ1 PCIE2 PCIE1 USB 3.2 Gen2 Top: T: USB3_2 LAN1 B: USB3_1 SATA_CON1 CMOS Battery USB 3.2 Gen2 Top: T: USB3_4 LAN2...
  • Page 69 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Bottom Side...
  • Page 70 1 : M.2 Key-B Socket (M2_B1) 4 : SATA Connector (SATA_CON1) 5 : Clear CMOS Headers Signal Name Signal Name +3.3V CLRMOS1 : +3.3V 1-2 : Normal (Default) FuLL_Card_ 2-3 : Clear CMOS Power_off USB_D+ W_DISABLE NOTE: CLRMOS1 allows you to clear WWAN_ the data in CMOS.
  • Page 71 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 6 : M.2 Key-E Socket (M2_E1) 7 : ATX/AT Mode Jumper (SIO_AT1) Signal Name Signal Name Open : ATX Mode (De- fault) +3VSB Short : AT Mode USB_D+ +3VSB USB_D-...
  • Page 72 10 : DC Input Connector (DC_IN1) Signal Name Signal Name MIC2_L 11 : Top : RJ45 LAN Port (LAN1) MIC2_R (Supports vPro) OUT2_R MIC_RET Bottom : USB 3.2 Gen2 Ports J_SENSE (USB3_1_2) OUT2_L OUT_RET 12 : Top : RJ45 LAN Port (LAN2) 20 : SPDIF Header (SPDIF1) Bottom : USB 3.2 Gen2 Ports (USB3_3_4)
  • Page 73 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E PWRBTN (Power Switch): COM5, 6 Ports Pin Definition Connect to the power switch on the RS232 RS422 RS485 chassis front panel. You may configure RTX- the way to turn off your system using the RTX+...
  • Page 74 28 : ESPI Connector (ESPI1) 29 : 4-Pin 12V ATX Power Connector (ATX12V1) Signal Name Signal Name DC Input DC Input...

  • Page 75: Motherboard Layout For Iep(F)-9012 & 9022 Series

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 2.4.2 Motherboard Layout for iEP(F)-9012 & 9022 Series Top Side PO=WR BAT1 CLR OS1 CLR OS2 SIO AT1 SMB S_TEST1 12V1 DC_ N1 BUZ 1 PCI 2 PCI 1 .2 Gen2...
  • Page 76 Bottom Side DDR4_B1 DDR4_A1 SIM1...
  • Page 77 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 1 : M.2 Key-B Socket (M2_B1) 4 : SATA Connector (SATA_CON1) 5 : Clear CMOS Headers Signal Name Signal Name +3.3V CLRMOS1 : +3.3V 1-2 : Normal (Default) FuLL_Card_ 2-3 : Clear CMOS...
  • Page 78 6 : M.2 Key-E Socket (M2_E1) 7 : ATX/AT Mode Jumper (SIO_AT1) Signal Name Signal Name Open : ATX Mode (De- fault) +3VSB Short : AT Mode USB_D+ +3VSB USB_D- 8 : Chassis Intrusion Headers CNV_WGR_ CNV_RF_ CI1 : RESET Open : Normal (Default) CNV_WGR_ Short : Active Case Open...
  • Page 79 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 17 : Audio Jacks 22 : COM Port Headers (COM5, 6) Green - Line Out (RS232/422/485) Pink - Mic In 18 : Front Panel Audio Header (HD_AUDIO2) * This motherboard supports RS232/422/485 on COM5, 6 ports.
  • Page 80 This header accommodates several 25 : 12V PCIe Power Connector (PCIE12V_CON1) system front panel functions. Connect the power switch, reset switch and system status indicator on the chassis to this header according to the pin assignments below. Note the positive and negative pins before connecting the cables.

  • Page 81: Ignition Control

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- CLRMOS1 CLRMOS2 SIO_AT1 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E DC_IN1 2.4.3 Ignition Control How to Disassemble Motherboard PCIE2 USB 3.2 Gen2 Top: T: USB3_2 LAN1 For more information, refer to 3.1. B: USB3_1 CMOS Ignition Control...
  • Page 82 Ignition Control Modes iEP(F)-9010 & 9020 Series provides 13 modes of different power on/off and hard off delay time adjustable with rotary switch. The default switch position is set to 0 in ATX Mode. The modes are listed as follows: Switch Power On Power Off...
  • Page 83 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E The Policy of Ignition Control Power Control The process of the ignition power control module is shown in the diagram below. Mode select DC-IN Ignition work (12) Standby Power...

  • Page 84: Other Boards

    2.5 Other Boards 2.5.1 DSC-SATA001-WT or DSC-SATA002-WT Due to the design of Chassis, the SATA boards will be different, but the functionality is the same. 2.5.1.1 DSC-SATA001-WT Layout and I/O Connectors 1 : SATA3_4 (SATA3 Connector) 2 : SATA3_2 (SATA3 Connector) 3 : ACT LED (Idle: On) 4 : PRSNT LED (Device installed: Blue.

  • Page 85: Dsc-Sata002-Wt Layout And I/O Connectors

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 2.5.1.2 DSC-SATA002-WT Layout and I/O Connectors DSC- SATA002 Industrial SATA3_4 SATA3_3 LED7 LED0 LED5 LED6 SATA3_2 SATA3_1 LED3 LED4 LED1 LED2 1 : LED7 (PRSNT LED. Device installed: Blue. No Device: N/A) LED3 (PRSNT LED.

  • Page 86: Dsc-Pse002-Wt Layout And I/O Connectors

    2.5.2 DSC-PSE002-WT Layout and I/O Connectors 1 : LAN1 (I226IT with PSE function) 2 : LAN2 (I226IT with PSE function) LAN1 3 : CON1 (FPC Connector) 4 : PWRCON1 (Power connector) LAN2 CON1 PWRCON1...

  • Page 87: Dsc-Comdio002-Wt Layout And I/O Connectors

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 2.5.3 DSC-COMDIO002-WT Layout and I/O Connectors 1 : USB2_7 (USB2.0 Port) 2 : PWRBTN1 (Power button) 3 : CLRCMSBTN1 (Clear CMOS button) 4 : JGPIO_SET1 (Digital Input / Output default value setting) 5 : DIO1 (8in 8out digital I/O) JGPIO DIO8...
  • Page 88 7 : COM1_2 (COM port headers, RS232/422/485) RS232 RS422 RS485 RTX- RTX+ DI (SIO GPI) 1. Input Channel: 8 2. Input Voltage: Low: 0.8Vdc max. (0Vdc min.) High: 2Vdc min. (3Vdc max.) 3. Current: 12mA max. per channel DO (SIO GPO) 1.

  • Page 89: Dsc-Comdio003-Wt Layout And I/O Connectors (Optional)

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 2.5.4 DSC-COMDIO003-WT Layout and I/O Connectors (Optional) 1 : Top : COM Port (COM1) (RS232/422/485) Bottom : COM Port (COM2_ISO) (ISO RS232/422/485) 2 : Top : COM Port (COM3) (RS232) Bottom : COM Port (COM4) (RS232) 3 : Top : DO [8:1] Bottom : DI [8:1]...
  • Page 90 Digital I/O: Sink and Source  DI (Sink/Source) 1. Input Channel: 8 2. Input Voltage: Low: 3Vdc max. (0Vdc min) High: 10Vdc min. (30Vdc max.) 3. Current: 1.075mA@10V~3.57mA@30V 4. Isolation Protection: 3000 V DI Sink topology:  DI Source topology: ...
  • Page 91 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E  DO (Sink)(N-MOSFET type) Spec. 1. Output Channel: 8 2. Output Voltage: +5Vdc ~ +30 Vdc 3. Sink Current: 350mA max./per channel 4. Isolation Protection: 3000 V DO Sink topology: ...

  • Page 92: Dsc-Slot003-Wt Layout And I/O Connectors (9010S/9012S & 9020S/9022S Only)

    2.5.5 DSC-SLOT003-WT Layout and I/O Connectors (9010S/9012S & 9020S/9022S Only) PCIEX4_1 PCIEX4_2 PCIEX16 PCIEX8 DSC-SLOT003-WT RoHS Industrial 1 : PCIEX4_1 (PCIe Gen4 x4 slot) 2 : PCIEX4_2 (PCIe Gen4 x4 slot, share with MB Key M) 3 : PCIEX16 (PCIe Gen4 x16 slot, switch with x8) Signal Signal +12V...
  • Page 93 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Signal Signal PEG_RXP3 PEG_RXN3 CFG_X8 RESERVED P-12 P+12 PEG_TXP4_R PEG_TXN4_R PEG_RXP4 PEG_RXN4 PEG_TXP5_R PEG_TXN5_R PEG_RXP5 PEG_RXN5 PEG_TXP6_R PEG_TXN6_R PEG_RXP6 PEG_RXN6 PEG_TXP7_R PEG_TXN7_R PEG_RXP7 PEG_RXN7 X8_CLKREQ# USB2_13_14_EN1 PEG_TXP8_R...
  • Page 94 Signal Signal PEG_TXP15_R PEG_TXN15_R PEG_RXP15 PEG_RXN15 +5VSB +5VSB 4 : PCIEX8 (PCIe Gen4 x8 slot) Signal Signal +12V +12V +12V +12V +12V PCH_ECLK_X4_2 SMB_CLK_MAIN PCH_ECLK_X4_2# SMB_DATA_MAIN RESERVED RESERVED SIO_PME# +3VSB BUF_PLT_RST# WAKE# RESERVED PCH_ECLK_X4_1 PCH_PE_TXP2_C PCH_ECLK_X4_1# RESERVED PCH_PE_RXP1 PCH_PE_RXN1 PCH_PE_TXP2_C PCH_PE_TXN2_C RESERVED PCH_PE_RXP2...
  • Page 95 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Signal Signal PCIE_4_RXP23 PCIE_4_TXP24_C PCIE_4_RXN23 PCIE_4_TXN24_C X4_PRSENT#_2 PCIE_4_RXP24 PCIE_4_RXN24 X4_PRSENT#_2...

  • Page 96: Dsc-Slot002-Wt Layout And I/O Connectors (Optional)

    2.5.6 DSC-SLOT002-WT Layout and I/O Connectors (Optional) 1 : PCIEX8 (PCIe Gen3 x8 slot) Signal Signal +12V +12V +12V +12V +12V PCH_ECLK_X4_2 SMB_CLK_MAIN PCH_ECLK_X4_2# SMB_DATA_MAIN RESERVED RESERVED SIO_PME# +3VSB BUF_PLT_RST# WAKE# RESERVED PCH_ECLK_X4_1 PCH_PE_TXP2_C PCH_ECLK_X4_1# RESERVED PCH_PE_RXP1 PCH_PE_RXN1 PCH_PE_TXP2_C PCH_PE_TXN2_C RESERVED PCH_PE_RXP2 PCH_PE_TXP3_C...
  • Page 97 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Signal Signal RESERVED PCIE_4_RXP21 PCIE_4_TXP22_C PCIE_4_RXN21 PCIE_4_TXN22_C PCIE_4_RXP22 PCIE_4_TXP23_C PCIE_4_RXN22 PCIE_4_TXN23_C PCIE_4_RXP23 PCIE_4_TXP24_C PCIE_4_RXN23 PCIE_4_TXN24_C X4_PRSENT#_2 PCIE_4_RXP24 PCIE_4_RXN24 X4_PRSENT#_2 2 : PCIEX16 (PCIe Gen3 x16 slot, switch with x8) Signal Signal +12V...
  • Page 98 Signal Signal PEG_RXN3 CFG_X8 RESERVED P-12 P+12 PEG_TXP4_R PEG_TXN4_R PEG_RXP4 PEG_RXN4 PEG_TXP5_R PEG_TXN5_R PEG_RXP5 PEG_RXN5 PEG_TXP6_R PEG_TXN6_R PEG_RXP6 PEG_RXN6 PEG_TXP7_R PEG_TXN7_R PEG_RXP7 PEG_RXN7 X8_CLKREQ# USB2_13_14_EN1 PEG_TXP8_R PEG_TXN8_R PEG_RXP8 PEG_RXN8 PEG_TXP9_R PEG_TXN9_R PEG_RXP9 PEG_RXN9 PEG_TXP10_R PEG_TXN10_R PEG_RXP10 PEG_RXN10 PEG_TXP11_R PEG_TXN11_R PEG_RXP11 PEG_RXN11 PEG_TXP12_R PEG_TXN12_R...

  • Page 99: Vga-Pwr Layout And I/O Connectors (Optional)

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Signal Signal PEG_TXN15_R PEG_RXP15 PEG_RXN15 +5VSB +5VSB 3 : PCI1 4 : PCI2 2.5.7 VGA-PWR Layout and I/O Connectors (Optional) 1 : 4P_ATX Connector (DC-IN) 2 : PSON# signal header 3 : SATA_PWR Connector 4 : SATA_PWR Connector...

  • Page 100: Chapter 3 Hardware Installation And Maintenance

    Chapter 3 Hardware Installation and Maintenance This chapter helps you disassemble the system and install components. Before You Begin Before you work with the system, pay close attention to the “Important Safety Instructions” at the beginning of this manual. 1. Make sure the system is powered off. Power down the system if it is still running.

  • Page 101: How To Disassemble The System

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 3.1 How to Disassemble the System 1. Remove all screws securing the heatsink. 2. Remove the heatsink. 3. Remove the screws securing the small panel. 4.
  • Page 102 5. Release the screws and remove the middle panel from the I/O side of the system. 6. Remove the screws securing the big panel. 7. Remove the big panel from the I/O side of the system.
  • Page 103 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 8. Remove the screw securing the cover. 9. Push the cover toward the I/O side of the chassis to remove the cover from the locked position.
  • Page 104 11. Remove the screws from the inside of the chassis. 12. Remove the screws from the rear side of the chassis.
  • Page 105 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 13. Pull out the motherboard tray from the system.

  • Page 106: How To Install The Cpu

    3.2 How to Install the CPU 1. Before you insert the 1700-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 107 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 3. Then lift the load plate to its fully open position. 4. By aligning the triangle marks on both CPU and socket (marked in the below illustration), install the CPU onto the socket.
  • Page 108 5. Close the load plate. 6. Then close the socket lever and slide it left to lock it into place.
  • Page 109 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 7. Remove the protective cover. Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 110: How To Install The Hard Disk Drive

    3.3 How to Install the Hard Disk Drive Installing a Hard Disk Drive into 2.5" Hard Drive Tray The system supports hot-swappable 2.5” hard drives. Removing 2.5” Hard Drive Trays from the Chassis 1. Press the locking lever latch on the drive tray to unlock the retention lever. 2.
  • Page 111 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Installing a 2.5” Hard Drive to the Hard Drive Tray 1. Place a 2.5" HDD into the tray with the printed circuit board side facing down. Carefully align the mounting holes in the hard drive and the tray.

  • Page 112: How To Install The Sim Card

    3.4 How to Install the SIM Card Installing a SIM Card into a SIM Card Slot 1. Remove the screw securing the SIM card slot cover. 2. Remove the SIM card slot cover.
  • Page 113 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 3. Insert a SIM card to the SIM car slot. SIM1 (Upper Slot): When inserting the SIM Card to the upper slot, make sure the notch on the SIM card is oriented with the gold contacts face down.

  • Page 114: How To Install The Desk Mount Bracket

    3.5 How to Install the Desk Mount Bracket 1. Attach the two desk mount brackets to the iEPF-9010S & 9020S Series or iEP-9010E & 9020E Series. Then secure them with eight screws. iEPF-9010S & 9020S Series iEP-9010E & 9020E Series 2.

  • Page 115: How To Install The Rubber Foot

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 3.6 How to Install the Rubber Foot 1. Attach four rubber foots to the iEPF-9010S & 9020S Series or iEP-9010E & 9020E Series. Then secure them with four screws. iEPF-9010S &...

  • Page 116: How To Install The Memory Module With Heatsink

    3.7 How to Install the Memory Module with Heatsink 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR4 SO-DIMM pairs. 2. If one DDR4 SO-DIMM is to be installed, it is recommended to install in slot A2. The SO-DIMM only fits in one correct orientation.

  • Page 117: How To Install The M.2 Ssd With Heatsink

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 3.8 How to Install the M.2 SSD with Heatsink 1. Gently insert the M.2 module, along the guiding tabs, into the heatsink bracket. 2. Remove the membrane from the heatsink. Then align the heatsink to the edge of the bracket and attach the heatsink onto the M.2 module.

  • Page 118: How To Install The Riser Card

    3.9 How to Install the Riser Card There are four PCI Express slots on the board. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and ensure necessary hardware settings for the card before you start the installation.
  • Page 119 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 2. With the default card holder assembled in the system for enhanced reliability, the dimensions of the expansion card is limited to 275 x 111.15 x 42 mm. If the card holder is removed, the dimensions of the expansion card are limited to 275 x 124 x 60 mm.
  • Page 120 1. In the case of graphic cards exceeding 300W, the system fan must operate at full speed. 2. Dimensions should not exceed 275mm x 124mm x 60mm (L x H x D), which means the total length of the graphic card and power cable should not exceed 275mm. 3.

  • Page 121: How To Install The Mini-Pcie Card

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 3.10 How to Install the Mini-PCIe Card The Mini-PCIe slot which supports SIM card is close to the SATA connector. 1. Locate the Mini-PCIe card slot on the motherboard. 2.

  • Page 122: How To Install The Wifi Module (M.2 Key E Socket (2230))

    3.11 How to Install the WiFi Module (M.2 Key E Socket (2230)) 1. Locate the WiFi Module slot on the motherboard. 2. Carefully insert the WiFi Module into the slot at a 30-degree angle. 3. Tighten the screw to secure the WiFi Module to the motherboard.

  • Page 123: How To Install The 4G / 5G Module (M.2 Key B Socket (2280/3042/3052))

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 3.12 How to Install the 4G / 5G module (M.2 Key B Socket (2280/3042/3052)) 1. Locate the 4G / 5G module slot on the motherboard. 2.

  • Page 124: How To Install The Wifi/4G/5G Antennas And Cables

    3.13 How to Install the WiFi/4G/5G Antennas and Cables 3.13.1 Antennas 1. Prepare the WiFi or 4G/5G antennas. WiFi antennas 4G/5G antennas 2. Connect the WiFi or 4G/5G antennas to the antenna connectors. Then turn the antennas clockwise until they are properly tightened. You may need to adjust the direction of the antennas for a stronger signal.

  • Page 125: Sma Cables

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 3.13.2 SMA Cables 1. Assemble the washer and nut into the antenna connector hole of the chassis as shown in the following illustration. When installing the SMA cable, ensure that the flat surface of the cable and the antenna hole are properly aligned.
  • Page 126 2. Turn the nut clockwise to tighten.

  • Page 127: Chapter 4 Uefi Setup Utility

    Chapter 4 UEFI Setup Utility 4.1 Introduction ASRock Industrial UEFI (Unified Extensible Firmware Interface) is a BIOS utility which offers tweak-friendly options in an advanced viewing interface. The UEFI system works with a USB mouse and offers users a faster and sleeker experience.

  • Page 128: Uefi Menu Bar

    4.1.2 UEFI Menu Bar The top of the screen has a menu bar with the following selections: Main For setting system time/date information Advanced For advanced system configurations H/W Monitor Displays current hardware status Security For security settings Boot For configuring boot settings and boot priority Exit Exit the current screen or the UEFI Setup Utility Because the UEFI software is constantly being updated, the following UEFI setup...

  • Page 129: Navigation Keys

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 4.1.3 Navigation Keys Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter> to get into the sub screen.

  • Page 130: Main Screen

    4.2 Main Screen When you enter the UEFI SETUP UTILITY, the main screen will appear and display the system overview. iEP-9010E iEP-9020E...
  • Page 131 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Because the UEFI software is constantly being updated, the following UEFI setup screens and descriptions are for reference purpose only, and they may not exactly match what you see on your screen.

  • Page 132: Advanced Screen

    4.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, Intel(R) Time Coordinated Computing, Storage Configuration, Super IO Configuration, ACPI Configuration, USB Configuration and Trusted Computing. Setting wrong values in this section may cause the system to malfunction. Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM.

  • Page 133: Cpu Configuration

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 4.3.1 CPU Configuration Intel Hyper Threading Technology Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performace on threaded software is improved. Active Processor P-Cores Select the number of cores to enable in each processor package.
  • Page 134 Intel SpeedStep Technology Intel SpeedStep technology is Intel’s new power saving technology. Processors can switch between multiple frequencies and voltage points to enable power saving. The default value is [Enabled]. Configuration options: [Enabled] and [Disabled]. ® If you install Windows OS and want to enable this function, please set this item to [Enabled].

  • Page 135: Chipset Configuration

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 4.3.2 Chipset Configuration Primary Graphics Adapter Select a primary VGA. Above 4G Decoding Enable or disable 64bit capable Devices to be decoded in Above 4G Address Space (only if the system supports 64 bit PCI decoding).
  • Page 136 Share Memory Configure the size of memory that is allocated to the integrated graphics processor when the system boots up. IGPU Multi-Monitor This allows you to enable or disable IGPU Multi-Monitor. The default value is [Disabled]. Render Standby Power down the render unit when the GPU is idle for lower power consumption. Onboard LAN1 This allows you to enable or disable the Onboard LAN1 feature.

  • Page 137: Intel(R) Time Coordinated Computing

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 4.3.3 Intel(R) Time Coordinated Computing #AC Split Lock Enable or Disable Alignment Check Exception (#AC). When enabled, this will assert an #AC when any atomic operation has an operand that crisses two cache lines. #GP Split Lock Enable or Disable GP Fault Exception (GP#).
  • Page 138 Intel(R) TCC Mode Enable or Disable Intel(R) TCC Mode. When enabled, this will modify system settings to improve real-time performance. The full list of settings and their current state are dis- played below when Intel(R) TCC mode is enabled. IO Fabric Low Latency Enable or Disable IO Fabric Low Latency.

  • Page 139: Storage Configuration

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 4.3.4 Storage Configuration SATA Controller(s) The option allows you to enable or disable the SATA controllers. Configuration options: [Enabled] [Disabled] SATA Mode Selection AHCI supports new features that improve performance. Configuration option: [AHCI] AHCI (Advanced Host Controller Interface) supports NCQ and other new features that will improve SATA disk performance.

  • Page 140: Super Io Configuration

    4.3.5 Super IO Configuration COM1 Use this to set parameters of COM1. Type Select Use this to select COM1 port type: [RS232], [RS422] or [RS485]. COM2 Use this to set parameters of COM2. Type Select Use this to select COM2 port type: [RS232], [RS422] or [RS485]. COM3 Use this to set parameters of COM3.
  • Page 141 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E COM6 Use this to set parameters of COM6. Type Select Use this to select COM6 port type: [RS232], [RS422] or [RS485]. WDT Timeout Reset Use this to set the Watch Dog Timer.
  • Page 142 DID13 Type Select Use this to set DIO Type: [Output Low] or [Output High]. DID14 Type Select Use this to set DIO Type: [Output Low] or [Output High]. DID15 Type Select Use this to set DIO Type: [Output Low] or [Output High]. Pin Location and Corresponding Signal Function DIO0...

  • Page 143: Acpi Configuration

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 4.3.6 ACPI Configuration Suspend to RAM Suspend to RAM allows you to select [Disabled] for ACPI suspend type S1. It is recom- mended to select [Auto] for ACPI S3 power saving. Configuration options: [Auto] [Disabled] PCIE Devices Power On Use this item to enable or disable PCIE devices to turn on the system from the power-...

  • Page 144: Usb Configuration

    4.3.7 USB Configuration USB Power Control Use this option to control USB power. M.2 Key_B USB Function Use this option to enable or disable M.2 Key_B USB Function.

  • Page 145: Trusted Computing

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 4.3.8 Trusted Computing Security Device Support Security Device Support allows you to enable or disable BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available.
  • Page 146 Endorsement Hierarchy This item allows you to enable or disable Endorsement Hierarchy. Configuration options: [Enabled] [Disabled] Physical Presence Spec Version Select this item to tell OS to support PPI spec version 1.2 or 1.3. Please note that some HCK tests might not support version 1.3. Configuration options: [1.2] [1.3] TPM 2.0 InterfaceType This item allows you to view the Communication Interface to TPM 2.0 Device: CRB or...

  • Page 147: Hardware Health Event Monitoring Screen

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 4.4 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage.

  • Page 148: Security Screen

    4.5 Security Screen Supervisor Password Set or change the password for the administrator account. Only the administrator has au- thority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password. User Password Set or change the password for the user account.

  • Page 149: Boot Screen

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E 4.6 Boot Screen In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. Boot Option #1 The item allows you to set the system boot order.

  • Page 150: Exit Screen

    4.7 Exit Screen Save Changes and Exit When you select this option, the following message “Save configuration changes and exit setup?” will pop out. Select [Yes] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, the following message “Discard changes and exit setup?”...

  • Page 151: Chapter 5 Appendix

    iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E Chapter 5 Appendix Appendix 1 Power Consumption The power consumption (W)= voltage (V) x current (A) The system’s full loading means it is populated with such as DRAM, M.2 Module, Mini PCIe, and so on.

  • Page 152: Appendix 2 Link To The Api Library

    Appendix 2 Link to the API Library If you need the link to the API library, feel free to contact us at IPC_TSD@asrockind.com Appendix 3 How to Install Power Supply or Power Adapter The V+ and V- pins provide DC power input and the chassis ground pin allows connection of the chassis to ground for better EMC compatibility.
  • Page 153 iEPF-9010S-EY4 / iEPF-9012S-EY4 / iEP- 9010E / iEP-9012E / iEPF-9020S-EY4 / iEPF-9022S-EY4 / iEP-9020E / iEP-9022E DC Power Side:  3.2 330W Power Adapter (FSP330-AAAN3)
