ASRock Industrial iEP-7040E Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
iEP-5000G Series
iEP-7040E Series
iEP-7041E Series
User Manual
Version 1.0
Published April 2022
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iEP-7040E Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASRock Industrial iEP-7040E Series

Summary of Contents for ASRock Industrial iEP-7040E Series

  • Page 1 Series iEP-7040E Series iEP-7041E Series User Manual Version 1.0 Published April 2022 User Manual...

  • Page 2: Copyright Notice

    ASRock Industrial has been advised of the possibility of such damages arising from any defect or error in the documentation or product.

  • Page 3: Important Safety Instructions

    Important Safety Instructions For user safety, please read and follow all instructions, Warnings, Cautions, and Notes marked in this manual and on the associated device before handling/operating the device, to avoid injury or damage. Read these safety instructions carefully. Retain this user manual for future reference. Read the Specifications section of this manual for detailed information on the recommended operating environment.
  • Page 4 °F) min., and the output is rated 19 Vdc 3.42A min., ES1. (For FSP120-ABAN3) / 24 Vdc 13.75A min., ES1 (For FSP330-AAAN). If you need further assistance, contact ASRock Industrial for additional information. The terminal block is suitable for V+& V- for 14~28AWG. The torque value is 0.19Nm.

  • Page 5: Replaceable Batteries

    Replaceable batteries CAUTION : RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS BURN HAZARD Hot surface! Do not touch! Touching this surface could result in bodily injury. To reduce risk, allow the surface to cool before touching.

  • Page 6: Contact Information

    HDMI Licensing LLC in the United States and other countries. Contact Information If you need to contact ASRock Industrial or want to know more about ASRock Industrial, you’re welcome to visit ASRock Industrial’s website at www.asrockind.com; or you may contact your dealer for further information.

  • Page 7: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Order Information Optional Items Product Specifications 1.4.1 System : iEP-7040E-020 1.4.2 System : iEP-7041E-020 1.4.3 System : iEP-7040E-021 1.4.4 System : iEP-7041E-021 1.4.5 System : iEP-7040E-022 1.4.6 System : iEP-7041E-022 1.4.7 System : iEP-7040E-023 1.4.8 System : iEP-7041E-023 1.4.9...
  • Page 8 2.1.2 System : iEP-7040E-021, iEP-7041E-021, iEP-7040E-022, iEP-7041E-022, iEP-7040E-023, iEP-7041E-023, iEP-7040E-024, iEP-7041E-024 System Top Panel 2.2.1 System : iEP-7040E-020, iEP-7041E-020 2.2.2 System : iEP-7040E-021, iEP-7041E-021, iEP-7040E-022, iEP-7041E-022, iEP-7040E-023, iEP-7041E-023 2.2.3 System : iEP-7040E-024, iEP-7041E-024 2.2.4 System : iEP-7040E-025, iEP-7041E-025 Inside View Rear View Right View (System : iEP-7040E-020, iEP-7041E-020, iEP-7040E-025, iEP-7041E-025)
  • Page 9 3.10 How to Install Phoenix Connector and the Adapter (Optional) Chapter 4 Motherboard Motherboard Layout Jumpers Setup Onboard Headers and Connectors Expansion Slots (M.2 Sockets) Chapter 5 UEFI Setup Utility Introduction 5.1.1 Entering BIOS Setup 5.1.2 UEFI Menu Bar 5.1.3 Navigation Keys Main Screen Advanced Screen...
  • Page 10 Security Screen Boot Screen Exit Screen...

  • Page 11: Chapter 1 Introduction

    Series Chapter 1 Introduction Because the hardware specifications might be updated, the content of this documentation will be subject to change without notice. 1.1 Package Contents iEP-7040E-020 Series • 1 x iEP-7040E-020 • 3 x Screws for M.2 Module •...
  • Page 12 iEP-7040E-025 Series • 1 x iEP-7040E-025 • 3 x Screws for M.2 Module • 1 x Phoenix plug connector • 1 x System QIG iEP-7041E-020 Series • 1 x iEP-7041E-020 • 3 x Screws for M.2 Module • 1 x Phoenix plug connector •...
  • Page 13 Series iEP-7041E-025 Series • 1 x iEP-7041E-025 • 3 x Screws for M.2 Module • 1 x Phoenix plug connector • 1 x System QIG If any items are missing or appear damaged, contact your authorized dealer.

  • Page 14: Order Information

    1.2 Order Information Model Name Description iEP-7040E-020 Basic SKU 255H W/O RAM, SSD, Adapter iEP-7040E-021 PoE SKU 255H W/O RAM, SSD, Adapter iEP-7040E-022 5LAN-WIFI 255H W/O RAM, SSD, Adapter iEP-7040E-023 5LAN-5G 255H W/O RAM, SSD, Adapter iEP-7040E-024 5G-WIFI 255H W/O RAM, SSD, Adapter iEP-7040E-025 8DIO SKU...

  • Page 15: Optional Items

    Series 1.3 Optional Items Model Name Description Wall Mount 13G020760000AI Attach the wall mounting brackets to the iEP- Kits 7040E Series. Din Rail Kits 13G020761000AI Attach the Din Rail brackets to the iEP-7040E Series to place the system onto the Din Rail.

  • Page 16: Product Specifications

    1.4 Product Specifications 1.4.1 System : iEP-7040E-020 Intel® Core™ Ultra Processor 255H Frequency 2.0 GHz Processor BIOS AMI EFI 256 Mbit Technology DDR5 5600 MHz Memory Max Capacity 64GB Socket Dual 262-pin SO-DIMM Chipset Intel® Arc™ graphics Graphics 1 x HDMI 2.0b Interface 1 x VGA"...

  • Page 17: System : Iep-7041E-020

    Series 1.4.2 System : iEP-7041E-020 Intel® Core™ Ultra Processor 255H Frequency 1.7 GHz Processor BIOS AMI EFI 256 Mbit Technology DDR5 5600 MHz Memory Max Capacity 64GB Socket Dual 262-pin SO-DIMM Chipset Intel® Arc™ graphics Graphics 1 x HDMI 2.0b...

  • Page 18: System : Iep-7040E-021

    1.4.3 System : iEP-7040E-021 Intel® Core™ Ultra Processor 255H Frequency 2.0 GHz Processor BIOS AMI EFI 256 Mbit Technology DDR5 5600 MHz Memory Max Capacity 64GB Socket Dual 262-pin SO-DIMM Chipset Intel® Arc™ graphics Graphics 1 x HDMI 2.0b Interface 1 x VGA RF&Antenna 5 x Antenna Hole...

  • Page 19: System : Iep-7041E-021

    Series 1.4.4 System : iEP-7041E-021 Intel® Core™ Ultra Processor 255H Frequency 1.7 GHz Processor BIOS AMI EFI 256 Mbit Technology DDR5 5600 MHz Memory Max Capacity 64GB Socket Dual 262-pin SO-DIMM Chipset Intel® Arc™ graphics Graphics 1 x HDMI 2.0b...

  • Page 20: System : Iep-7040E-022

    1.4.5 System : iEP-7040E-022 Intel® Core™ Ultra Processor 255H Frequency 2.0 GHz Processor BIOS AMI EFI 256 Mbit Technology DDR5 5600 MHz Memory Max Capacity 64GB Socket Dual 262-pin SO-DIMM Chipset Intel® Arc™ graphics Graphics 1 x HDMI 2.0b Interface 1 x VGA RF&Antenna 5 x Antenna Hole...

  • Page 21: System : Iep-7041E-022

    Series 1.4.6 System : iEP-7041E-022 Intel® Core™ Ultra Processor 255H Frequency 1.7 GHz Processor BIOS AMI EFI 256 Mbit Technology DDR5 5600 MHz Memory Max Capacity 64GB Socket Dual 262-pin SO-DIMM Chipset Intel® Arc™ graphics Graphics 1 x HDMI 2.0b...

  • Page 22: System : Iep-7040E-023

    1.4.7 System : iEP-7040E-023 Intel® Core™ Ultra Processor 255H Frequency 2.0 GHz Processor BIOS AMI EFI 256 Mbit Technology DDR5 5600 MHz Memory Max Capacity 64GB Socket Dual 262-pin SO-DIMM Chipset Intel® Arc™ graphics Graphics 1 x HDMI 2.0b Interface 1 x VGA RF&Antenna 5 x Antenna Hole...

  • Page 23: System : Iep-7041E-023

    Series 1.4.8 System : iEP-7041E-023 Intel® Core™ Ultra Processor 255H Frequency 1.7 GHz Processor BIOS AMI EFI 256 Mbit Technology DDR5 5600 MHz Memory Max Capacity 64GB Socket Dual 262-pin SO-DIMM Chipset Intel® Arc™ graphics Graphics 1 x HDMI 2.0b...

  • Page 24: System : Iep-7040E-024

    1.4.9 System : iEP-7040E-024 Intel® Core™ Ultra Processor 255H Frequency 2.0 GHz Processor BIOS AMI EFI 256 Mbit Technology DDR5 5600 MHz Memory Max Capacity 64GB Socket Dual 262-pin SO-DIMM Chipset Intel® Arc™ graphics Graphics 1 x HDMI 2.0b Interface 1 x VGA RF&Antenna 7 x Antenna Hole...

  • Page 25: System : Iep-7041E-024

    Series 1.4.10 System : iEP-7041E-024 Intel® Core™ Ultra Processor 255H Frequency 1.7 GHz Processor BIOS AMI EFI 256 Mbit Technology DDR5 5600 MHz Memory Max Capacity 64GB Socket Dual 262-pin SO-DIMM Chipset Intel® Arc™ graphics Graphics 1 x HDMI 2.0b...

  • Page 26: System : Iep-7040E-025

    1.4.11 System : iEP-7040E-025 Intel® Core™ Ultra Processor 255H Frequency 2.0 GHz Processor BIOS AMI EFI 256 Mbit Technology DDR5 5600 MHz Memory Max Capacity 64GB Socket Dual 262-pin SO-DIMM Chipset Intel® Arc™ graphics Graphics 1 x HDMI 2.0b Interface 1 x VGA RF&Antenna 5 x Antenna Hole...

  • Page 27: System : Iep-7041E-025

    Series 1.4.12 System : iEP-7041E-025 Intel® Core™ Ultra Processor 255H Frequency 1.7 GHz Processor BIOS AMI EFI 256 Mbit Technology DDR5 5600 MHz Memory Max Capacity 64GB Socket Dual 262-pin SO-DIMM Chipset Intel® Arc™ graphics Graphics 1 x HDMI 2.0b...

  • Page 28: Block Diagram

    1.5 Block Diagram DSB-1140-WT HDMI TCP0 Channel A DDR5 6400MHZ SO-DIMM Connector Chrontel Channel B DDR5 6400MHZ DDIA SO-DIMM CH7517A- Connector RJ45 Intel PCIex1 2.5G Connector I226IT RJ45 Intel PCIe x1/SATA PCIex1 2.5G Connector I226IT USB 3.2 Gen2 SIM Card M.2 Key B USB 2.0 RJ45...

  • Page 29: Chapter 2 Product Overview

    Ground : The functional earth ground provides you with a grounding point. Power Button : The power button allows you to turn the iEP-7040E Series on or off. You can use the power button to put your iEP-7040E Series into sleep mode or System : iEP-7030E-021, iEP-7031E-021, press it for four seconds to shut down you system.
  • Page 30 Audio (Mic-In) : The Mic-in audio connector on the I/O panel supports 5.1 channel HD audio and fully complies with Intel® High Definition Audio specifications. HDMI : The HDMI port supports a Full-HD device to allow viewing on a larger external display.
  • Page 31 Power Button : The power button allows you to turn the iEP-7040E Series on or off. You can use the power button to put your iEP-7040E Series into sleep mode or press it for four seconds to shut down you system.
  • Page 32 Audio (Mic-In) : The Mic-in audio connector on the I/O panel supports 5.1 channel HD audio and fully complies with Intel® High Definition Audio specifications. HDMI : The HDMI port supports a Full-HD device to allow viewing on a larger external display.
  • Page 33 Series ** Please refer to the table below for the Diagnostic LED indications. Item LED1 LED2 BIOS Status Code Description White White 0x15 PEI_CAR_NB_INIT White Blue 0x32 PEI_CPU_INIT White Yellow 0x68 DXE_NB_HB_INIT White 0x19 PEI_CAR_SB_INIT Blue White 0x4F PEI_DXE_IPL_STARTED...

  • Page 34: System Top Panel

    2.2 System Top Panel 2.2.1 System : iEP-7040E-020, iEP-7041E-020 1E-020 Description User Define LED : User define LED indicator behaviors are based on the ASRI API library you use. 1E-021, GPIO : The 9-pin Digital Input / Output connector allows you to program it for input or output use.
  • Page 35 Series Serial (COM3) Port* : The 9-pin RS232/422/485 serial connector allows you to connect devices that have serial ports. * This motherboard supports RS232/422/485 on COM3 port. Please refer to table below for the pin definition. In addition, COM3 port (RS232/422/485) can be adjusted in BIOS setup utility > Ad- vanced Screen >...

  • Page 36: System : Iep-7040E-021, Iep-7041E-021, Iep-7040E-022, Iep-7041E-022, Iep-7040E-023, Iep-7041E-023

    2.2.2 System : iEP-7040E-021, iEP-7041E-021, iEP-7040E-022, iEP-7041E-022, iEP-7040E-023, iEP-7041E-023 E-021, Description User Define LED : User define LED indicator behaviors are based on the ASRI API library you use. GPIO : The 9-pin Digital Input / Output connector allows you to program it for input or output use.
  • Page 37 Series Serial (COM3) Port* : The 9-pin RS232/422/485 serial connector allows you to connect devices that have serial ports. * This motherboard supports RS232/422/485 on COM3 port. Please refer to table below for the pin definition. In addition, COM3 port (RS232/422/485) can be adjusted in BIOS setup utility > Ad- vanced Screen >...

  • Page 38: System : Iep-7040E-024, Iep-7041E-024

    2.2.3 System : iEP-7040E-024, iEP-7041E-024 1E-024 Description User Define LED : User define LED indicator behaviors are based on the ASRI API library you use. GPIO : The 9-pin Digital Input / Output connector allows you to program it for input or output use.
  • Page 39 Series Serial (COM3) Port* : The 9-pin RS232/422/485 serial connector allows you to connect devices that have serial ports. * This motherboard supports RS232/422/485 on COM3 port. Please refer to table below for the pin definition. In addition, COM3 port (RS232/422/485) can be adjusted in BIOS setup utility > Ad- vanced Screen >...

  • Page 40: System : Iep-7040E-025, Iep-7041E-025

    2.2.4 System : iEP-7040E-025, iEP-7041E-025 1E-025 Description User Define LED : User define LED indicator behaviors are based on the ASRI API library you use. GPIO : The 9-pin Digital Input / Output connector allows you to program it for input or output use.
  • Page 41 Series Serial (COM3) Port* : The 9-pin RS232/422/485 serial connector allows you to connect devices that have serial ports. * This motherboard supports RS232/422/485 on COM3 port. Please refer to table below for the pin definition. In addition, COM3 port (RS232/422/485) can be adjusted in BIOS setup utility > Ad- vanced Screen >...

  • Page 42: Inside View

    2.3 Inside View Description M.2 Slot (B Key) : The M.2 slot allows you to install 3042/3052 4G LTE/5G module. M.2 Slot (E Key) : The M.2 slot allows you to install 2230 Wi-Fi/BT module and 2230/2260 2-LAN Port module. M.2 Slot (M Key) : The M.2 slot allows you to install 2280 M.2 devices.

  • Page 43: Rear View

    Series 2.4 Rear View • For Basic/8DIO SKU • For PoE/5LAN/5G SKU Description Mounting Holes : The holes support Wall Mount and DIN Rail brackets for system in vertical position. Micro SD Slot : The slot supports Micro SD card.

  • Page 44: Right View (System : Iep-7040E-020, Iep-7041E-020, Iep-7040E-025, Iep-7041E-025)

    2.5 Right View (System : iEP-7040E-020, iEP-7041E-020, iEP- 7040E-025, iEP-7041E-025) Description Mounting Holes : The holes support Wall Mount brackets for system in 1, 4, 6, 9 vertical position. 2, 8 VESA Holes : The holes support VESA bracket to attach the iEP-703XE-020 and iEP-703XE-025 to the rear of a compatible display.

  • Page 45: Position

    Series 2.6 Position The system should be placed in vertical or horizontal position. • Positions of the iEP-7040E-020, iEP-7041E-020, iEP-7040-025 and iEP-7041E-025: vertical & horizontal • Positions of the iEP-7040E-021, iEP-7041E-021, iEP-7040E-022, iEP-7041E-022, iEP-7040E-023, iEP-7041E-023, iEP-7040E-024 and iEP-7041E-024: only vertical...

  • Page 46: Chapter 3 Hardware Installation

    Chapter 3 Hardware Installation This chapter helps you install or remove important components. 3.1 How to Install the Wi-Fi Module (2230) to the M.2 Key E Slot (Optional) 1. Locate the WiFi Module slot on the motherboard. 2. Carefully insert the WiFi Module into the slot at a 30-degree angle. 3.
  • Page 47 Series 5. Remove the antenna rubber on the box cover. 6. Attach the SMA cable and washer to both sides of the cover, and secure them with the nut. 7. Install the Wifi antenna onto the SMA cable.
  • Page 48 3.2 How to Install the 4G LTE/5G Module (3042/3052) to the M.2 Key B Slot (Optional) 1. Locate the 4G LTE/5G Module slot on the motherboard. 2. Carefully insert the 4G LTE/5G Module into the slot at a 30-degree angle. 3.
  • Page 49 Series 5. Remove the antenna rubber on the box cover. 6. Attach the SMA cable and washer to both sides of the cover, and secure them with the nut. 7. Install the 4G LTE/5G antenna onto the SMA cable.

  • Page 50: How To Install The M.2 Ssd (2280) To The M.2 Key M Socket

    3.3 How to Install the M.2 SSD (2280) to the M.2 Key M Socket 1. Locate the M.2 slot on the motherboard. 2. Carefully insert the M.2 SSD (Type 2280) into the slot at a 30-degree angle. 3. Tighten the screw to secure the M.2 SSD (Type 2280) to the motherboard.

  • Page 51: How To Install The Memory Modules

    Series 3.4 How to Install the Memory Modules The iEP-7040E Series requires DDR5 SO-DIMM (1.1V). For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR5 SO-DIMM pairs The SO-DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.

  • Page 52: How To Install A Nano Sim Dard And Micro Sd Card

    3.5 How to Install a Nano SIM Dard and Micro SD Card 1. Release the screws on the iEP-7040E Series and remove the SIM/Micro SD Card slot cover. 2. With the gold contacts facing front, carefully insert the SIM Card or the SD Card into the designated slot until it clicks.
  • Page 53 Series 3. Place the cover back and secure it to the iEP-7040E Series with screws.

  • Page 54: How To Install The Wall Mounting Bracket (Optional)

    3.6 How to Install the Wall Mounting Bracket (Optional) • Wall mounting: vertical 1. Attach the wall mounting brackets to the iEP-7040E Series and secure it with two screws. Then you can attach the iEP-7040E Series to the wall with four screws.
  • Page 55 Series Dimension of the iEP-7040E Series with Wall Mounting Bracket Installed • Wall mounting: horizontal 100 mm 100 mm 1. Attach the wall mounting brackets to the iEP-7040E-020, iEP-7041E-020, iEP- 86 mm 86 mm 7040E-025, iEP-7041E-025 and secure it with screws.

  • Page 56: How To Install Vesa Bracket (Optional) (For Basic/8Dio Sku)

    Dimension of the iEP-7040 iEP-7040E-025, i with Wall Mounting 3.7 How to Install VESA Bracket (Optional) (for Basic/8DIO SKU) 1. Attach the two screws to the base of the iEP-7040E-020, iEP-7041E-020, iEP- 7040E-025, iEP-7041E-025. Dimension of the iEP-7040E-020, iEP-7041E-020, iEP-7040E-025, iEP-7041E-025 with Wall Mounting Bracket Installed 200.6 mm 188.6 mm...

  • Page 57: How To Install The Din Rail (Optional)

    188.6 mm 188.6 mm iEP-7040E Series 3.8 How to Install the Din Rail (Optional) 1. Attach the Din Rail Bracket to the iEP-7040E Series and secure it with screws. iEP-7040E-021, iEP-7041E-021, iEP-7040E-020, iEP-7041E-020, iEP-7040E-022, iEP-7041E-022, iEP-7040E-025, iEP-7041E-025 iEP-7040E-023, iEP-7041E-023, iEP-7040E-024, iEP-7041E-024,...

  • Page 58: How To Remove The Membranes

    white (+) 3.9 How to Remove the Membranes Please note to remove the membranes from the heatsinks before reinstall the bottom case.

  • Page 59: How To Install Phoenix Connector And The Adapter (Optional)

    Series 3.10 How to Install Phoenix Connector and the Adapter (Op- tional) 1. Insert white (+) cable of the adapter into the left port of the phoenix connector, and insert the black (-) cable into the middle port. Ensure the cables are inserted to the end.

  • Page 60: Chapter 4 Motherboard

    Chapter 4 Motherboard 4.1 Motherboard Layout Top Side : VGA1 COM3 JGPIO1 PANEL1 DSB-11 0-WT BAT1 Industrial Bottom: Top: LAN1 LAN2 Bottom: Middle: Top: USB 3.2 Gen2 USB 2.0 LAN3 USB3_3 USB3_4 Bottom: Top: COM5 COM1 BIOS USB 3.2 Gen2 Bottom: M2_M1 Top: USB3T_2...

  • Page 61: Rear Side

    Series Rear Side : FAN1 SIM1...
  • Page 62 1 : Top: HDD LED Bottom: User Define LED 2 : Digital Input/Output Connector (JGPIO1) 3 : COM Port (COM3) (RS232/422/485)* 4 : D-Sub Port (VGA1) 5 : Chassis Intrusion Headers (CI1) 6 : System Panel Header (PANEL1) 7 : DACC Jumper (DACC1) 8 : Digital Input/Output Default Value Setting (JGPIO_SET1) 9 : ATTEST1 10 : Digital Input/Output Connector (GPIO1)

  • Page 63: Jumpers Setup

    Series 4.2 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on pins, the jumper is “Short.” If no jumper cap is placed on pins, the jumper is “Open. ” The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”...
  • Page 64 ASRI internal G3 aging jumper Description G3_AT_GPIO# (2-pin JP_G3_AT1) (see p. 50, No. 11) Clear CMOS Jumpers Setting Description Normal (Default) (3-pin CLRMOS1) Clear CMOS (see p. 50, No. 12) Note: CLRMOS1 allows you to clear the data in CMOS. To clear and reset the system pa- rameters to default setup, please turn off the computer and unplug the power cord from the power supply.

  • Page 65: Onboard Headers And Connectors

    Series 4.3 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard! System Panel Header...
  • Page 66 Digital Input/Output Connector Signal Name Signal Name (20-pin GPIO1) MCU_SPI0_ GPP_E7 (see p. 50, No. 10) MOSI MCU_SPI0_ GPP_E5 MISO 7 MCU_SPI0_CLK GPP_E4 MCU_SPI0_SS GPP_D3 11 DSC_DIO_GP2 GPP_C23 13 DSC_DIO_GP1 GPP_C22 ICE_CLK GPP_B23 ICE_DAT GPP_B20 ESPI Header Signal Name (20-pin ESPI1) C_ESPI_CLK (see p.
  • Page 67 Series PCIE Connectors Signal Name +12V (20-pin PCIE1) +12V (see p. 50, No. 19) PLT_RST# CLKP (20-pin PCIE2) CLKN (see p. 50, No. 20) PCIE_TXP PCIE_TXN PCIE_RXP PCIE_RXN CLKREQ# +12V +12V +12V +12V +12V Power Connectors (12V/GND) Signal Name...

  • Page 68: Expansion Slots (M.2 Sockets)

    4.4 Expansion Slots (M.2 Sockets) There are three M.2 sockets on the motherboard. Signal Name Signal Name M.2 Key-M Socket (M2_M1) +3.3V +3.3V PERn3 (see p. 50, No. 16) PERp3 SATA_LED PETn3 +3.3V PETp3 +3.3V M.2 Key M Socket (2280)(PCIe Gen4) +3.3V PERn2 +3.3V...

  • Page 69: Chapter 5 Uefi Setup Utility

    Chapter 5 UEFI Setup Utility 5.1 Introduction ASRock Industrial UEFI (Unified Extensible Firmware Interface) is a BIOS utility which offers tweak-friendly options in an advanced viewing interface. The UEFI system works with a USB mouse and offers users a faster, sleeker experience.

  • Page 70: Uefi Menu Bar

    5.1.2 UEFI Menu Bar The top of the screen has a menu bar with the following selections: For setting system time/date information Main Advanced For advanced system configurations H/W Monitor Displays current hardware status Security For security settings Boot For configuring boot settings and boot priority Exit Exit the current screen or the UEFI Setup Utility Because the UEFI software is constantly being updated, the following UEFI setup...

  • Page 71: Navigation Keys

    Series 5.1.3 Navigation Keys Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter>...

  • Page 72: Main Screen

    5.2 Main Screen When you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. Because the UEFI software is constantly being updated, the following UEFI setup screens and descriptions are for reference purpose only, and they may not exactly match what you see on your screen.

  • Page 73: Advanced Screen

    Series 5.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, Intel(R) Time Coordinated Computing, Storage Configuration, Su- per IO Configuration, AMT Configuration, ACPI Configuration, USB Configuration, and Trusted Computing.

  • Page 74: Cpu Configuration

    5.3.1 CPU Configuration Intel Hyper Threading Technology Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performance on threaded software is improved. Configuration options: [Enabled] [Disabled] Active Processor P-Cores This allows you to select the number of cores to enable in each processor package. Active Processor E-Cores This allows you to select the number of E-Cores to enable in each processor package.

  • Page 75: Intel Virtualization Technology

    Series Package C State Support The option allows you to enable CPU, PCIe, Memory, Graphics C State Support for power saving. CFG Lock The option allows you to enable or disable the CFG Lock. Configuration options: [Enabled] [Disabled] Intel Virtualization Technology When this option is set to [Enabled], a VMM (Virtual Machine Architecture) can utilize the additional hardware capabilities provided by Vanderpool Technology.

  • Page 76: Cpu Thermal Throttling

    CPU Thermal Throttling CPU Thermal Throttling allows you to enable CPU internal thermal control mechanisms to keep the CPU from overheating. Configuration options: [Enabled] [Disabled] Intel Trusted Execution Technology This item allows you to enable or disable the Intel Trusted Execution Technology function.

  • Page 77: Chipset Configuration

    Series 5.3.2 Chipset Configuration VT-d Intel® Virtualization Technology for Directed I/O helps your virtual machine monitor bet- ter utilize hardware by improving application compatibility and reliability, and providing additional levels of manageability, security, isolation, and I/O performance. Configuration options: [Enabled] [Disabled]...

  • Page 78: Power Button Control

    Onboard HD Audio Select [Auto], [Enabled] or [Disabled] for the onboard HD Audio feature. If you select [Auto], the onboard HD Audio will be disabled when PCI Sound Card is plugged. Power Button Control The item enables or disables Power Button Function. Restore on AC/Power Loss Select the power state after a power failure.

  • Page 79: Intel(R) Time Coordinated Computing

    Series 5.3.3 Intel(R) Time Coordinated Computing #AC Split Lock Enable or Disable Alignment Check Exception (#AC). When enabled, this will assert an #AC when any atomic operation has an operand that crisses two cache lines. #GP Fault UC Lock Enable or Disable GP Fault Exception (GP#).
  • Page 80 Interl (R) TCC Mode The item enables or disables Intel(R) TCC Mode. When enabled, this will modify system settings to improve real-time performance. The full list of settings and their current state are displayed below when Intel(R) TCC mode is enabled. L2 QOS Enumeration Enable or Disable L2 QOS Enumerate.

  • Page 81: Storage Configuration

    Series 5.3.4 Storage Configuration VMD Configuration This item allows you to enable or disable the Intel VMD support function. SATA Controller(s) The option allows you to enable or disable the SATA controllers. Configuration options: [Enabled] [Disabled] SATA Mode Selection AHCI supports new features that improve performance.
  • Page 82 Hard Disk S.M.A.R.T. S.M.A.R.T stands for Self-Monitoring, Analysis, and Reporting Technology. It is a monitoring system for computer hard disk drives to detect and report on various indicators of reliability. Configuration options: [Enabled] [Disabled]...

  • Page 83: Super Io Configuration

    Series 5.3.5 Super IO Configuration COM1 Use this to set parameters of COM1. Type Select Use this to select COM1 port type: [RS232], [RS422] or [RS485]. COM3 Use this to set parameters of COM3. Type Select Use this to select COM3 port type: [RS232], [RS422] or [RS485].
  • Page 84 WDT Timeout Reset Use this to set the Watch Dog Timer. JGPIO Power Control Use this to select JGPIO Power: [OFF], [+3V] or [+5V] DID0 Type Select Use this to set DIO Type: [Input]. DID1 Type Select Use this to set DIO Type: [Input]. DID2 Type Select Use this to set DIO Type: [Input].
  • Page 85 Series Pin Location and Corresponding Signal Function DIO0 SIO GPIO70 DIO1 SIO GPIO71 DIO2 SIO GPIO72 DIO3 SIO GPIO73 DIO4 SIO GPIO74 DIO5 SIO GPIO75 DIO6 SIO GPIO76 DIO7 SIO GPIO77...

  • Page 86: Amt Configuration

    5.3.6 AMT Configuration USB Provisioning of AMT Use this to enable or disable AMT USB Provisioning. The default is [Disabled]. MAC Pass Through The option enables or disables MAC Pass Through function. Dynamic Lan Switch This allows switching AMT support from Integrated LAN to Discrete LAN. Activate Remote Assistance Process Trigger CIRA boot.
  • Page 87 Series Remote Platform Erase Configuration Remote Platform Erase configuration menu. MEBx This Formset contains forms for configuring MEBx.

  • Page 88: Acpi Configuration

    5.3.7 ACPI Configuration Suspend to RAM Suspend to R A M a l lows you to select [Disabled] for ACPI suspend t y pe S1. It is recommended to select [Auto] for ACPI S3 power saving. Configuration options: [Auto] [Disabled] Onboard LAN Power On Use this item to enable or disable onboard LAN to turn on the system from the power-soft- off mode.

  • Page 89: Usb Configuration

    Series 5.3.8 USB Configuration USB Power Control Use this option to control USB power. M.2 Key_B Function The item enables or disables M.2 Key_B USB function.

  • Page 90: Trusted Computing

    5.3.9 Trusted Computing Security Device Support Security Device Support allows you to enable or disable BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. Configuration options: [Enabled] [Disabled] Active PCR banks This item displays active PCR Banks.

  • Page 91: Device Select

    Series Storage Hierarchy This item allows you to enable or disable Storage Hierarchy. Configuration options: [Enabled] [Disabled] Endorsement Hierarchy This item allows you to enable or disable Endorsement Hierarchy. Configuration options: [Enabled] [Disabled] Physical Presence Spec Version Select this item to tell OS to support PPI spec version 1.2 or 1.3. Please note that some HCK tests might not support version 1.3.

  • Page 92: Hardware Health Event Monitoring Screen

    5.4 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, fan speed, and the criti- cal voltage. FAN1 Setting This allows you to set FAN1’s speed.

  • Page 93: Security Screen

    Series 5.5 Security Screen In this section, you may set, change or clear the supervisor/user password for the system. Supervisor Password Set or change the password for the administrator account. Only the administrator has the authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 94: Boot Screen

    5.6 Boot Screen In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. Boot From Onboard LAN The item allows the system to be woke up by the onboard LAN. Configuration options: [Enabled] [Disabled] Setup Prompt Timeout The item allows you to configure the number of seconds to wait for the UEFI setup utility.

  • Page 95: Exit Screen

    Series 5.7 Exit Screen Save Changes and Exit When you select this option, the following message “Save configuration changes and exit setup?” will pop out. Select [Yes] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, the following message “Discard changes and exit setup?”...
