  • Page 1 User Manual Version 1.0 Published June 2022 Copyright©2022 ASRockInd INC. All rights reserved.
  • Page 2 Version 1.0 Published July 2022 Copyright©2022 ASRockInd Inc. All rights reserved. Copyright Notice: No part of this documentation may be reproduced, transcribed, transmitted, or translated in any language, in any form or by any means, except duplication of documentation by the purchaser for backup purpose, without written consent of ASRock Rack Inc.
  • Page 3 Important Safety Instructions For user safety, please read and follow all instructions, Warnings, Cautions, and Notes marked in this manual and on the associated device before handling/ operating the device, to avoid injury or damage. 1. Read these safety instructions carefully. 2.
  • Page 4 AC adapter provided with the product, a replacement AC adapter provided by ASRock Industrial or agency, or an AC adapter purchased as an accessory from ASRock Industrial or agency should be used with the product.
  • Page 5 Replaceable Batteries BURN HAZARD Hot surface! Do not touch! Touching this surface could result in bodily injury. To reduce risk, allow the surface to cool before touching. CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS CAUTION The equipment is equipped with a battery-powered real-time clock circuit.
  • Page 6 States and other countries. Contact Information If you need to contact ASRock Industrial or want to know more about ASRock Industrial, you’re welcome to visit ASRock Industrial’s website at www.asrockind.com ; or you may contact your dealer for further information.

  • Page 7: Table Of Contents

    Contents Chapter 1 Introduction Key Features Package List Specifications Dimensions Block Diagram Chapter 2 System Overview System Front Panel 2.1.1 Control Panel Buttons and LED Indicators 2.1.2 I/O Connectors HDD Panel Drive Tray LEDs Chapter 3 Hardware Installation and Maintenance How to Install the Hard Disk Drive How to Install the SIM Card How to Disassemble the System...
  • Page 8 Advanced Screen 5.3.1 CPU Configuration 5.3.2 Chipset Configuration 5.3.3 Intel(R) Time Coordinated Computing 5.3.4 Storage Configuration 5.3.5 Super IO Configuration 5.3.6 ACPI Configuration 5.3.7 USB Configuration 5.3.8 Trusted Computing Hardware Health Event Monitoring Screen Security Screen Boot Screen Exit Screen...

  • Page 9: Chapter 1 Introduction

    In case any modifications of this documentation occur, the updated version will be available on ASRock Industrial’s website without further notice. If you require technical support related to this product, please visit our website for specific information about the model you are using.
  • Page 10 power design, with support for 275mm x 111.15 mm (L x H) max. and up to 255W graphic cards iEP-9010E • Intel® 12 Gen Core™ Processors with R680E Chipset • 4 x 260-pin DDR4 SO-DIMM up to 128GB (32GB per DIMM) • 1 x M.2 Key M, 1 x M.2 Key B, 1 x M.2 Key E, 2 x Mini PCIe • 6 x USB 3.2 Gen2x1, 6 x COM, 4 x SATA3, 8 x DI, 8 x DO • 5 x Intel 2.5G LAN (2 support PoE, 1 supports vPro)

  • Page 11: Package List

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 1.2 Package List Item Quantity iEPF-9010S Series / iEP-9010E Series Rubber foot M3x8L Round Head Bolts for Rubber foot Desk Mount M3x5L Countersunk Screws for Desk Mount M4x10L Round Head Bolts for Desk Mount M3x4L Round Head Bolts for SODIMM Bracket Terminal Block 1X3P ST 7.62m...
  • Page 12 We recommend that 330W adapter (Certified adapter, Output: 24Vdc,13.75A) is used if there is no PCIe or PCI add-on cards assembled on the iEPF-9010S-EY4. Users may use a DC source instead of the optional 330W adapter (Certified adapter, Output: 24Vdc,13.75A) when power consumption is over 330W in an environment where the...

  • Page 13: Specifications

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 1.3 Specifications iEPF-9010S-EY4 Processor System Intel Gen Core™, Pentium or Celeron Processors ® Chipset Intel R680E ® Socket LGA 1700 Memory Technology Dual Channel DDR4 2933MHz (ECC memory supported by R680E + Selected CPU)
  • Page 14 Storage 1 x M.2 (Key M, 2280) with Gen4/Gen3 x4 for NVMe SSD SATA 4 x SATA3 (6Gb/s), support RAID 0/1/5/10 4 x 2.5" HDD/SSD Tray CFast (Option) 1 x Type II socket (Shared with SATA3) Front I/O DisplayPort HDMI Ethernet 5 x 2.5G LAN 6 x USB 3.2 Gen2x1, 1 x USB2.0 internal connector w/ lock function...
  • Page 15 / iEPF-9012S-EY4 iEP-9010E / iEP-9012E iEPF-9012S-EY4 Processor System Intel Gen Core™, Pentium or Celeron Processors ® Chipset Intel H610 ® Socket LGA 1700 Memory Technology Dual Channel DDR4 2933MHz Capacity 64 GB (32 GB per DIMM) Socket 2 x 260-pin SO-DIMM...
  • Page 16 Rear I/O DisplayPort HDMI Ethernet 4 x 2.5G LAN 2 x USB 3.2 Gen2x1, 2 x USB 3.2 Gen1x1, 2 x USB 2.0, 1 x USB2.0 internal connector w/ lock function Audio 1 x Mic-in, 1 x Line-out 4 x RS232/422/485 2 x RS232 8DIs/8DOs Watchdog Timer...
  • Page 17 / iEPF-9012S-EY4 iEP-9010E / iEP-9012E iEP-9010E Processor System Intel Gen Core™, Pentium or Celeron Processors ® Chipset Intel R680E ® Socket LGA 1700 Memory Technology Dual Channel DDR4 2933MHz (ECC memory supported by R680E + Selected CPU) Capacity 128 GB (32 GB per DIMM)
  • Page 18 Rear I/O DisplayPort HDMI Ethernet 5 x 2.5G LAN 6 x USB 3.2 Gen2x1, 1 x USB2.0 internal connector w/ lock function Audio 1 x Mic-in, 1 x Line-out 4 x RS232/422/485 2 x RS232 8DIs/8DOs Watchdog Timer Output From Super I/O to drag RESETCON# Interval 256 Segments, 0, 1, 2, ...255sec Power Requirements...
  • Page 19 / iEPF-9012S-EY4 iEP-9010E / iEP-9012E iEP-9012E Processor System Intel Gen Core™, Pentium or Celeron Processors ® Chipset Intel H610 ® Socket LGA 1700 Memory Technology Dual Channel DDR4 2933MHz Capacity 64 GB (32 GB per DIMM) Socket 2 x 260-pin SO-DIMM...
  • Page 20 Rear I/O DisplayPort HDMI Ethernet 4 x 2.5G LAN 2 x USB 3.2 Gen2x1, 2 x USB 3.2 Gen1x1, 2 x USB 2.0, 1 x USB2.0 internal connector w/ lock function Audio 1 x Mic-in, 1 x Line-out 4 x RS232/422/485 2 x RS232 8DIs/8DOs Watchdog Timer...

  • Page 21: Dimensions

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 1.4 Dimensions iEPF-9010S-EY4 / iEPF-9012S-EY4 Front View - iEPF-9010S-EY4 Front View - iEPF-9012S-EY4...
  • Page 22 Top View Left-Side View...
  • Page 23 / iEPF-9012S-EY4 iEP-9010E / iEP-9012E Right-Side View Rear Side View...
  • Page 24 Bottom View...
  • Page 25 / iEPF-9012S-EY4 iEP-9010E / iEP-9012E iEP-9010E / iEP-9012E Front View - iEP-9010E Front View - iEP-9012E...
  • Page 26 Top View Left-Side View...
  • Page 27 / iEPF-9012S-EY4 iEP-9010E / iEP-9012E Right-Side View Rear Side View...
  • Page 28 Bottom View...

  • Page 29: Block Diagram

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 1.5 Block Diagram iEP(F)-9010E/S Series DSB-1210-WT DDR4 So-DIMM x 2 DDR4-CHA DDR4 So-DIMM x 2 DDIB DDR4-CHB Intel ADL-S Processor Gen4 --PCIe x16 slot HDMI DDID LGA-1700 Pin socket PCIe Gen4 bus or PCIe x8/x8 M.2 KEY M...
  • Page 30 iEP(F)-9012E/S Series iEP(F)-9012E/S Series DSB-1212-WT DDR4 So-DIMM x 1 DDR4-CHA DDR4 So-DIMM x 1 DDIB DDR4-CHB Intel ADL-S Processor HDMI Gen4 --PCIe x16 DDID LGA-1700 Pin socket PCIe Gen4 bus DDIE CH7517A-BFI USB2 connector 2 x Rear I/O(USB2.0) USB2#,7~8 SATA3 Port1~4 B to B card3 (PCIe#17~20) LAN1 I226IT PCIe#4...

  • Page 31: Chapter 2 System Overview

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E Chapter 2 System Overview This chapter provides diagrams showing the location of important components of the system system. 2.1 System Front Panel 10 11 Description Antenna Port 1 Serial Port (COM 2) Serial Port (COM 1)
  • Page 32 Remote Power On/Off Switch (IGN) 2 x USB 3.2 Gen2x1 Ports (R680E sku) 2 x USB 2.0 Ports (H610 sku) VGA Port PoE1 Port Status LED (PoE 1) PoE2 Port Status LED (PoE 2) LAN RJ-45 PoE Port (PoE 2) LAN RJ-45 Port (LAN 3) (R680E sku) LAN RJ-45 PoE Port (PoE 1) LAN RJ-45 Port (LAN 2)

  • Page 33: Control Panel Buttons And Led Indicators

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 2.1.1 Control Panel Buttons and LED Indicators Power Switch Press the power switch button to toggle the system power-on and power-off modes. To remove all power from the system completely, disconnect the power cord from the system.
  • Page 34 M.2 Slot (Key M) Status LED Status Description Blinking Green M.2 Slot (Key M) on the motherboard is populated with a M.2 module. Empty M.2 Slot (Key M) IGN Status LED Status Description Solid Green The IGN connector is connected and working normally. No connection...

  • Page 35: I/O Connectors

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 2.1.2 I/O Connectors Connector Description Antenna Port Connect the antenna cable to this connector. This system provides six COM ports through Serial Port (COM) D-sub 9-pin connectors. This system provides non-isolation digital Digital Ouput input circuits for customer's device.

  • Page 36: Hdd Panel

    2.2 HDD Panel iEPF-9010S Series / iEP-9010E Series Description 2.5" HDD/SSD Tray (HDD0) 2.5" HDD/SSD Tray (HDD1) 2.5" HDD/SSD Tray (HDD3) 2.5" HDD/SSD Tray (HDD2) Side Vent 2 x SIM Card Slots (SIM1 is for M.2 B key slot) System Heatsink...

  • Page 37: Drive Tray Leds

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 2.3 Drive Tray LEDs Description HDD Power LED HDD Activity LED Status LED Definitions HDD Power LED Status Description Blue HDD powered-on No power to HDD HDD Activity LED Status Description Solid Green HDD active...

  • Page 38: Chapter 3 Hardware Installation And Maintenance

    Chapter 3 Hardware Installation and Maintenance This chapter helps you disassemble the system and install components. Before You Begin Before you work with the system, pay close attention to the “Important Safety Instructions” at the beginning of this manual. 1. Make sure the system is powered off. Power down the system if it is still running.

  • Page 39: How To Install The Hard Disk Drive

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 3.1 How to Install the Hard Disk Drive Installing a Hard Disk Drive into 2.5" Hard Drive Tray The system supports hot-swappable 2.5" hard drives. Removing 2.5” Hard Drive Trays from the Chassis 1. Press the locking lever latch on the drive tray to unlock the retention lever.
  • Page 40 Installing a 2.5” Hard Drive to the Hard Drive Tray 1. Place a 2.5" HDD into the tray with the printed circuit board side facing down. Carefully align the mounting holes in the hard drive and the tray. 2. Secure the hard drive using four screws. 3.

  • Page 41: How To Install The Sim Card

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 3.2 How to Install the SIM Card Installing a SIM Card into a SIM Card Slot 1. Release the screw and remove the SIM card slot cover.
  • Page 42 2. Insert a SIM card to the SIM car slot. SIM1 (Upper Slot): When inserting the SIM Card to the upper slot, make sure the notch on the SIM card is oriented with the gold contacts face down. SIM2 (Lower Slot): When inserting the SIM Card to the lower slot, make sure the notch on the SIM card is oriented with the gold contacts face up.

  • Page 43: How To Disassemble The System

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 3.3 How to Disassemble the System 1. Release all screws on the heasink side 2. Remove the heatsink.. 3. Release the screws. 4. Remove the small panel from the I/O side of the system.
  • Page 44 5. Release the screws and remove the middle panel from the I/O side of the system. 6. Release the screws. 7. Remove the big panel from the I/O side of the system.
  • Page 45 / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 8. Release the screw. 9. Push the cover toward the I/O side of the chassis to remove the cover from the locked position. Remove the cover. 10. Release the two screws from the inside of the chassis.
  • Page 46 11. Remove the screws from the inside of the chassis. 12. Remove the screws from the rear side of the chassis.
  • Page 47 / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 13. Pull out the motherboard tray from the system.

  • Page 48: How To Install The Desk Mount Bracket

    3.4 How to Install the Desk Mount Bracket 1. Attach the two desk mount brackets to the iEPF-9010S Series or iEP-9010E Series and secure them with eight screws. iEPF-9010S Series iEP-9010E Series 2. Then you can attach the iEPF-9010S Series or iEP-9010E Series to any horizontal surface.

  • Page 49: How To Install The Rubber Foot

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 3.5 How to Install the Rubber Foot 1. Attach four rubber foots to the iEPF-9010S Series or iEP-9010E Series and secure them with four screws. iEPF-9010S Series iEP-9010E Series 2. Then you can put the iEPF-9010S Series or iEP-9010E Series to any horizontal surface.

  • Page 50: Chapter 4 Motherboard

    Chapter 4 Motherboard 4.1 Motherboard Layout Top Side...
  • Page 51 / iEPF-9012S-EY4 iEP-9010E / iEP-9012E Rear Side...
  • Page 52 1 : M.2 Key-B Socket (M2_B1) 2 : SMBUS_TEST1 Signal Signal PIN Signal Name PIN PIN Signal Name PIN Name Name SMBUS_ SMB_CLK SMB_DATA TEST 3 : PWR_BAT1 Open : Normal Short : Charge Battery 4 : SATA Connector (SATA_CON1) 5 : Clear CMOS Headers CLRMOS1 : 1-2 : Normal...
  • Page 53 / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 6 : M.2 Key-E Socket (M2_E1) CNV_WR_D1- CNV_WR_D1+ CNV_WR_D0- CNV_WR_D0+ CNV_WR_CLK- CNV_WR_CLK+ 7 : ATX/AT Mode Jumper (SIO_AT1) Open : ATX Mode Short : AT Mode 8 : Chassis Intrusion Headers (CI1, CI2) CI1 :...
  • Page 54 9 : M.2 Key-M Socket (M2_M1) PERn0 PERp0 PETn0 PETp0 10 : DC Input Connector (DC_IN1) 11 : Top : RJ45 LAN Port (LAN1)(Supports vPRO) Bottom : USB3.2 Gen2 Ports (USB3_1_2) 12 : Top : RJ45 LAN Port (LAN2) Bottom : USB3.2 Gen2 Ports (USB3_3_4) 13 : Top : RJ45 LAN Port (LAN3) Bottom : USB3.2 Gen2 Ports (USB_7_8) 14 : POE Connector (POE_CON1)
  • Page 55 / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 17 : Top : DislpayPort (DP1) Bottom : HDMI Port (HDMI1) 18 : Audio Jacks Green - Line Out Pink - Mic In 19 : Front Panel Audio Header MIC2_L MIC2_R OUT2_R MIC_RET J_SENS E...
  • Page 56 * This motherboard supports RS232/422/485 on COM5, 6 ports. Please refer to below table for the pin definition. In addition, COM5, 6 port (RS232/422/485) can be adjusted in BIOS setup utility > Advanced Screen > Super IO Configuration. You may refer to our user manual for details.
  • Page 57 / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 27 : ESPI Connector (ESPI1) 28 : 4-Pin 12V ATX Power Connector 1-2 : GND 3-4 : DC Input...

  • Page 58: Chapter 5 Uefi Setup Utility

    Chapter 5 UEFI Setup Utility 5.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer. Please press <F2>...

  • Page 59: Main Screen

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 5.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items...

  • Page 60: Advanced Screen

    5.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Con- figuration, Chipset Configuration, Intel(R) Time Coordinated Computing, Storage Configuration, Super IO Configuration, ACPI Configuration, USB Configuration and Trusted Computing. Setting wrong values in this section may cause the system to malfunction.

  • Page 61: Cpu Configuration

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 5.3.1 CPU Configuration Intel Hyper Threading Technology Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performace on threaded software is improved. Active Processor P-Cores Select the number of cores to enable in each processor package.
  • Page 62 Intel Turbo Boost Technology Intel Turbo Boost Technology enables the processor to run above its base operating frequency when the operating system requests the highest per- formance state. CPU Thermal Throttling You may select [Enabled] to enable CPU internal thermal control mechanism to keep the CPU from overheating.

  • Page 63: Chipset Configuration

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 5.3.2 Chipset Configuration Primary Graphics Adapter Select a primary VGA. Above 4G Decoding Enable or disable 64bit capable Devices to be decoded in Above 4G Ad- dress Space (only if the system supports 64 bit PCI decoding).
  • Page 64 Deep Sleep Configure deep sleep mode for power saving when the computer is shut down. Restore on AC/Power Loss Select the power state after a power failure. If [Power Off] is selected, the power will remain off when the power recovers. If [Power On] is selected, the system will start to boot up when the power recovers.

  • Page 65: Intel(R) Time Coordinated Computing

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 5.3.3 Intel(R) Time Coordinated Computing #AC Split Lock Enable or Disable Alignment Check Exception (#AC). When enabled, this will assert an #AC when any atomic operation has an operand that crisses two cache lines.
  • Page 66 Intel(R) TCC Mode Enable or Disable Intel(R) TCC Mode. When enabled, this will modify system settings to improve real-time performance. The full list of settings and their current state are displayed below when Intel(R) TCC mode is en- abled. L2 QOS Enumeration Enable or Disable L2 QOS Enumerate.When Enable CPUID Enumeration for L2 QOS gets enabled.

  • Page 67: Storage Configuration

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 5.3.4 Storage Configuration SATA Controller(s) Use this item to enable or disable the SATA Controller feature. SATA Mode Selection Use this to select SATA mode. The default value is [AHCI Mode]. AHCI (Advanced Host Controller Interface) supports NCQ and other new features that will improve SATA disk perfor- mance but IDE mode does not have these advantages.

  • Page 68: Super Io Configuration

    5.3.5 Super IO Configuration COM1 Configuration Use this to set parameters of COM1. Type Select Use this to select COM1 port type: [RS232], [RS422] or [RS485]. COM2 Configuration Use this to set parameters of COM2. Type Select Use this to select COM2 port type: [RS232], [RS422] or [RS485]. COM3 Configuration Use this to set parameters of COM3.
  • Page 69 / iEPF-9012S-EY4 iEP-9010E / iEP-9012E DID3 Type Select Use this to set DIO Type: [Input]. DID4 Type Select Use this to set DIO Type: [Input]. DID5 Type Select Use this to set DIO Type: [Input]. DID6 Type Select Use this to set DIO Type: [Input].

  • Page 70: Acpi Configuration

    5.3.6 ACPI Configuration Suspend to RAM Use this item to select whether to auto-detect or disable the Suspend-to- RAM feature. Select [Auto] will enable this feature if the OS supports it. PCIE Devices Power On Allow the system to be waked up by a PCIE device and enable wake on LAN.

  • Page 71: Usb Configuration

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 5.3.7 USB Configuration USB Power Control Use this option to control USB power. M.2 Key_B USB Function Use this option to enable or disable M.2 Key_B USB Function.

  • Page 72: Trusted Computing

    5.3.8 Trusted Computing Security Device Support Enable or disable BIOS support for security device. SHA256 PCR Bank Use this item to enable or disable SHA256 PCR Bank. Pending Operation Schedule an Operation for the Security Device. Platform Hierarchy Use this item to enable or disable Platform Hierarchy Storage Hierarchy Use this item to enable or disable Storage Hierarchy.

  • Page 73: Hardware Health Event Monitoring Screen

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 5.4 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage.

  • Page 74: Security Screen

    5.5 Security Screen In this section, you may set, change or clear the supervisor/user password for the system. Supervisor Password Set or change the password for the administrator account. Only the ad- ministrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 75: Boot Screen

    / iEPF-9012S-EY4 iEP-9010E / iEP-9012E 5.6 Boot Screen In this section, it will display the available devices on your system for you to config- ure the boot settings and the boot priority. Boot Option1 Use this item to set the system boot order.

  • Page 76: Exit Screen

    5.7 Exit Screen Save Changes and Exit When you select this option, it will pop-out the following message, “Save configuration changes and exit setup?” Select [OK] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, it will pop-out the following message, “Discard changes and exit setup?”...
