Vivotek IP7142 Specifications

IP7142
Fixed Network Camera
WDR Outdoor
VIVOTEK's IP7142 network camera features a WDR (Wide
Dynamic Range) CMOS sensor to cope with challenging
lighting conditions. The WDR feature captures both the dark
and bright parts of an image and combines the differences
to generate a highly realistic image representative of the
original scene, enabling it to provide video quality close to
the capabilities of the human eye. This function enables the
IP7142 to be widely applied in high contrast environments
such as lobby entrances, parking lots, ATMs, loading areas,
and much more.
The day and night function and the IP66-rated integrated
housing of the IP7142 enable users to easily build a
cost-effective IP surveillance system without additional
accessories. Incorporating an IR-cut filter that can be
removed automatically at night and built-in IR illuminators
with coverage for up to 15 meters, the IP7142 is an
outstanding 24-hour surveillance solution. Meanwhile, the
IP66-rated integrated housing shields the camera from dust
and water, allowing it to be applied in the harsh weather
conditions of outdoor environments.
Other advanced features of the IP7142 include simultaneous
dual streams, 3GPP mobile surveillance, 802.3af compliant
PoE, two-way audio by SIP protocol, RS-485 interface for
scanners or pan/tilts driver connection, and HTTPS encrypted
data transmission.
Day&Night
Features
>
>
>
>
>
>
>
>
>
>
>
Wide Dynamic Range CMOS Sensor
3.3 ~ 12 mm Vari-focal Lens
Removable IR-cut Filter for Day & Night Function
Built-in IR Illuminators, effective up to 15 Meters
Real-time MPEG-4 and MJPEG Compression
(Dual Codec)
Dual Streams Simultaneously
Weather-proof IP66-rated Housing
Built-in 802.3af Compliant PoE
Two-way Audio via SIP Protocol
Digital I/O for External Sensor and Alarm
RS-485 Interface for Scanners, Pan/Tilts
