Vivotek IP7130 Specifications page 2

．CPU: Mozart 120 SoC
System
．Flash: 8MB
．RAM: 64MB + 64MB
．Embedded OS: Linux 2.6
Lens ．CS-mount, f = 4.0 mm, F1.6, Fixed
Angle of View ．48.5° (horizontal)
Shutter Time ．1/5 sec. to 1/15,000 sec.
Image Sensor ．1/4" CMOS sensor in VGA resolution
Minimum Illumination ．0.1 Lux / F1.6
．Compression: MJPEG & MPEG-4
Video
．Streaming:
Simultaneous dual streams
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 multicast streaming
MJPEG streaming over HTTP or HTTPS
．Supports 3GPP mobile surveillance
．Frame rates:
MPEG-4: Up to 30/25 fps at 640x480
MJPEG: Up to 30/25 fps at 640x480
．Adjustable image size, quality and bit rate
Image Settings
．Time stamp and text caption overlay
．Flip & mirror
．Configurable brightness, contrast, saturation,
sharpness, white balance and exposure
．AGC, AWB, AES
．BLC (Backlight Compensation)
．Supports privacy masks
．Compression:
Audio
GSM-AMR speech encoding, bit rate:
4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate:
16 kbps to 128 kbps
．Interface:
Built-in microphone
External microphone input
Audio output
External/Internal microphone switch
．Supports two-way audio via SIP protocol
．Supports audio mute
．10/100 Mbps Ethernet, RJ-45
Networking
．Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS,
UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP,
DHCP, NTP, DNS, DDNS and PPPoE
Alarm and ．Triple-window video motion detection
．Tamper detection
Event Management
．One D/I and one D/O for external sensor and alarm
．Event notification using HTTP, SMTP or FTP
．Local recording of MP4 file
．Multi-level user access with password protection
Security
．IP address filtering
．HTTPS encrypted data transmission
Users ．Live viewing for up to 10 clients
．154 mm (D) x 72 mm (W) x 62 mm (H)
Dimension
．623 g
Weight
．System power and status indicator
LED Indicator
．System activity and network link indicator
．12V DC
Power
．Power consumption: Max. 6 W
．802.3af compliant Power-over-Ethernet
Approvals ．CE, LVD, FCC, VCCI, C-Tick
Operating
．Temperature: 0 ~ 50 °C (32 ~ 122 °F )
．Humidity: 90% RH
Environments
Distributed by:
Specifications
Viewing System
Requirements
Installation, Management,
and Maintenance
Applications
Warranty
External
Microphone
Speaker
IP7130
Recording Software
Status LED
Microphone In
Ethernet 10/100
RJ45 Socket
Recessed Reset
Button
Enclosure
All specifications are subject to change without notice. Copyright
6F, No.192, Lien-Cheng Rd., Chung-Ho, Taipei County, Taiwan
Tel: +886 2 8245 5282
VIVOTEK USA, INC.
470 Lakeside Drive Suite C, Sunnyvale, CA 94085 USA
Tel: 408-773-8686 | Fax: 408-773-8298 | E-mail: salesusa@vivotek.com
．OS: Microsoft Windows 7/Vista/XP/2000
．Browser: Mozilla Firefox, Internet Explorer
6.x or above
．Cell phone: 3GPP player
．Real Player: 10.5 or above
．Quick Time: 6.5 or above
．Installation Wizard 2
．32-CH ST7501 recording software
．Supports firmware upgrade
．SDK available for application development
and system integration
．12 months
System Overview
Router
PC with
External View
Audio Out
External/Internal
MIC Switch
Accessories
PoE Injector
2009 VIVOTEK INC. All rights reserved.
| |
Fax: +886 2 8245 5532 E-mail: sales@vivotek.com
3G Cell Phone
Notebook with
Web Browser
Power Cord
Socket
General I/O
Terminal Block
Mounting Kit
