- Page 1 OWNER’S MANUAL FREEZER Please read this owner's manual thoroughly before operating and keep it handy for reference at all times. F-2004SQ GR-224SQ GR-204SQ www.lg.com P/No. : EBAX00097B...
-
Page 3: Table Of Contents
Table of Contents Introduction Important safety Instruction Disposal of the old appliance & packing of new appliance Identification of Parts Installation Location Electrical Connection Operation Starting Storing food Suggestion on food storage Making Ice Care and Defrosting Maintenance Cleaning General Information Tips for saving Energy Trouble Shooting Trouble Shooting... -
Page 4: Introduction
Introduction The appliance is suitable for storing the frozen goods. It is restricted for household use. If it is used for industrial or commercial purpose, observe the related regulations firmly. If using other purpose or misuse, the manufacturer is not responsible for the damages of occasion. - Page 5 Introduction Important Safety Instruction Accessibility of The supply plug of the refrigerator-freezer should be Supply Plug placed in easy accessible position for quick disconnection in emergency. Supply Cord If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified Replacement person in order to avoid a hazard.
-
Page 6: Disposal Of The Old Appliance & Packing Of New Appliance
Introduction Disposal of the old appliance & packing of new appliance Disposal of the old The old appliance whose life has expired should be destroyed in order to make it safe prior to disposal. Take appliance out power plugs, separate connection wires and remove or destroy all springs, latches or bolting, to prevent children from being trapped during play. -
Page 7: Identification Of Parts
Introduction Identification of Parts Temperature Ice Tray Display Ice scraper Magnetic Freezer Drawer Gasket Leveling Screws Note This is a basic model.The shape of refrigerator is subject to change. -
Page 8: Installation
Installation Location This appliance is suitable for using at ambient temperature between +16°C and +38°C. If the ambient temperature drops below +16°C, it is possible that the freezing foods in the freezer compartment are thawed because the temperature of the freezer gets warm. We recommend that the refrigerator be installed at a dry and well ventilated place. -
Page 9: Operation
Operation Starting Before switching it on, leave the appliance standing for at least 2 hours, so that the circulation of the refrigerant stabilizes and no operating problems occur. Function of ° C electronic control When the appliance powers on, the initial state displayed on LED is "-18°C". -
Page 10: Suggestion On Food Storage
Suggestions on food storage Storing food Opening the door often or keeping the door opened a long time, increases the inside temperature. This causes the storage life and flavor of the foods to reduce, and increases the energy consumption. Note Do not touch deep-frozen foods with wet hands. -
Page 11: Care And Maintenance
Care and Maintenance Defrosting Defrosting the fridge compartment When the freezer is working, frost is formed at the rear wall of the fridge compartment and melts automatically when the compressor stops. Defrosting the freezer compartment Humidity forms frost or ice in the freezer compartment while the appliance is working or when the freezer door is opened. -
Page 12: Cleaning
Care and Maintenance Cleaning Always remove plugs or Switch off supply before w w Warning cleaning. Do not use sharp objects (such as knife, screwdriver) which could break refrigerant circuit resulting in environmental and health risks. Never use steam cleaner or steam pressure cleaner since hot steam may damage refrigerator surface and electrical devices. -
Page 13: General Information
Care and Maintenance General Information Going away When you plan to be away for an extended period, remove all food, disconnect the power cord, clean the interior thoroughly, and leave the door OPEN to prevent odor formation. Most power failures are corrected in an hour or two and Power failure will not affect your refrigerator temperatures. -
Page 14: Tips For Saving Energy
Care and Maintenance Tips for saving Energy - After moving the appliance, allow 2 hours to turn on again. - Do not place the appliance near radiator, stove, and heat sources. If ambient temperature is high, the compressor will run longer. - Place the appliance on a cool and well ventilated room. -
Page 15: Trouble Shooting
Trouble Shooting Before calling for service, check this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Possible Causes Problem • Power plug may be unplugged from the electric Fridge-Freezer outlet. - Page 16 Trouble Shooting Possible Causes Problem • Foods with strong odors should be tightly covered Fridge has odor or wrapped • Check for spoiled food • Interior needs cleaning • Refer to "Cleaning Section" • This phenomenon is likely to occur in a wet space. Moisture forms on Wipe it with a dry towel cabinet surface...
