AMB-5 /
*
IQ Mixer/Multiplexers with Automatic Signal Processing
© 1999 by Crown International, Inc., P.O. Box 1000, Elkhart, Indiana 46515-1000 U.S.A. Telephone:
219-294-8000. The IQ–AMB-5 and IQ–SMX-6 are produced by Crown International, Inc. Trademark Notice:
IQ2
™
is a trademark and Crown
International, Inc. Other trademarks are the property of their respective owners.
Printed on
recycled paper.
*
®
, IQ System
®
, Com-Tech
®,
and PZM
SMX-6
DATA
ENABLE
DATA
ENABLE
®
are registered trademarks of Crown
126869-1
8/99
Advertisement
Table of Contents
Related Manuals for Crown IQSMX-6
Summary of Contents for Crown IQSMX-6
- Page 1 AMB-5 / IQ Mixer/Multiplexers with Automatic Signal Processing © 1999 by Crown International, Inc., P.O. Box 1000, Elkhart, Indiana 46515-1000 U.S.A. Telephone: 219-294-8000. The IQ–AMB-5 and IQ–SMX-6 are produced by Crown International, Inc. Trademark Notice: ™ is a trademark and Crown International, Inc.
- Page 2 Warranty. ITEMS EXCLUDED FROM THIS CROWN WARRANTY This Crown Warranty is in effect only for failure of a new Crown product which occurred within the Warranty Period. It does not cover any product which has been damaged because of any intentional misuse, accident, negligence, or loss which is covered under any of your insurance contracts.
-
Page 3: Important Safety Instructions
AMB-5 / SMX-6 IQ Mixer/Multiplexer 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 4: Fcc Class A Compliance
If you need special assistance beyond the scope of this manual, please contact our Technical Support Group. Crown Audio Technical Support Group Plant 2 SW, 1718 W. Mishawaka Rd., Elkhart, Indiana 46517 U.S.A. Phone: 800-342-6939 (North America, Puerto Rico and Virgin Islands) or 219-294-8200 Fax: 219-294-8301 Fax Back (North America only): 800-294-4094 or 219-293-9200 Fax Back (International): 219-294-8100 Internet: http://www.crownintl.com email: iqsupport@crownintl.com... -
Page 5: Quick Install Procedure
AMB-5 / SMX-6 IQ Mixer/Multiplexer This procedure is provided for those who are already familiar with Crown’s IQ System ® and who would like to install the mixer/multiplexer in the shortest time possible. Less experienced installers or those wishing a full explanation of the installation procedure are encouraged to go to Section 3 where the full installation procedure is described. -
Page 6: Table Of Contents
Connecting to a Host Computer ... 10 Connecting to the Crown Bus ... 11 3.2.1 Set the IQ Address Switch ... 11 3.2.2 Connect to the IQ System via the Crown Bus ... 12 Connect the Audio Wiring ... 14 Connect Auxiliary Devices ... 14 4 Operation ... - Page 7 Crown Bus Wiring for 4-pin DIN Output ... 13 Figure 3.9 Crown Bus Wiring for RJ-45 Output ... 13 Figure 3.10 Crown Bus Wiring “Loop” from Output to Input ... 14 Figure 5.1 IQ–AMB-5 Block Diagram ... 21 Figure 5.2 IQ–SMX-6 Block Diagram ...
-
Page 8: Welcome
IQ mixer/multiplexers are intelligent mixers with special signal routing capabilities. Their intelligence stems from a powerful onboard microprocessor which enables them to be controlled by a Crown IQ System Each input and output can be individually controlled and, with their distributed intelligence tinue to operate even when an IQ System is not con- nected. -
Page 9: Controls, Connectors & Indicators
AMB-5 / SMX-6 IQ Mixer/Multiplexer 2 Controls, Connectors & Indicators Figure 2.1 IQ Mixer / Multiplexer Controls, Connectors & Indicators IQ–AMB-5 / IQ–SMX-6 Reference Manual Page 9... -
Page 10: Hardware Installation
If the unit will be connected to the Crown Bus it will not need to be connected directly to a host computer. The following circumstances require connection to a host computer: •... -
Page 11: Connecting To The Crown Bus
This flexibility is a great strength, en- abling a Crown Bus loop to be wired with either fiber optic cabling or with inexpensive twisted-pair wire, whichever the installation requires. A single IQ System can have more than one Crown Bus loop. -
Page 12: Connect To The Iq System Via The Crown Bus
Crown Bus loops, 1 and 2, and an IQ–SMX-6 is to be installed into loop 1 and given an address of 114. No other IQ–SMX-6 can be given the same address in loop 1. However, an IQ–SMX-6 in loop 2 can have the same address. -
Page 13: Figure 3.4 Four-Terminal Removable Barrier Block Plug
Cable connectors are numbered as they appear from the front. Input (–) Input (+) Output (–) Output (+) Figure 3.6 Crown Bus Wiring for 5-pin DIN Input IQ–AMB-5 / IQ–SMX-6 Reference Manual 3 /16 in (0.48 cm) Figure 3.7 Crown Bus Wiring for RJ-45 Input... -
Page 14: Connect The Audio Wiring
See Section 5.1 for information on the operation of the mixer/multiplexer inputs and outputs. Figure 3.10 Crown Bus Wiring “Loop”from Output to Input of Each IQ Component Page 14 3.4 Connect Auxiliary Devices (Step 4) -
Page 15: Operation
It must also be set prop- erly if an IQ–SMX-6 is to be used in a Crown Local Net. Two or more IQ components should NEVER have the same address on the same Crown Bus loop. -
Page 16: Crown Bus Connector
4.1.11 Crown Bus Ground Connector This chassis ground stud is provided to connect an optional shield for the Crown Bus cable. Only the shield of the input cable should be connected. Shielded wire will reduce the total distance a Crown... -
Page 17: Duck Priority
AMB-5 / SMX-6 IQ Mixer/Multiplexer +25 dB in -dB steps. • • • • • Gate Threshold: the input level above which the gate will “open” and below which the gate will “close.” Control range is from –100 to +25 dB in -dB steps. -
Page 18: Output Compressor
Channel 1 while the ambient sense in- put level is dropping. Control range is from 0.2 to 30 seconds. • Expansion Ratio: determines how much the gain of output Channel 1 will increase for every AMB-5 / SMX-6 IQ Mixer/Multiplexer IQ–AMB-5 / IQ–SMX-6 Reference Manual... -
Page 19: Crown Local Net
0 to +40 dB in 4.3 Crown Local Net (IQ–SMX-6 only) The Crown Local Net (CLN) allows multiple IQ–SMX- 6 units to be linked so that their Duck Priority and Gate Count functions work together. For example, a duck priority 1 in one unit will override a priority 2 in another unit. -
Page 20: Output Section
5.2.2 RS232 Interface Depending on selected options, the DB9 connector can be used to communicate directly with the host computer for setup or control of a Crown Bus loop, or (IQ–SMX-6 only) for connection to an RS232 Crown Local Net. -
Page 21: Figure 5.1 Iq-Amb-5 Block Diagram
AMB-5 / SMX-6 IQ Mixer/Multiplexer Figure 5.1 IQ–AMB-5 Block Diagram IQ–AMB-5 / IQ–SMX-6 Reference Manual Page 21... -
Page 22: Figure 5.2 Iq-Smx-6 Block Diagram
AMB-5 / SMX-6 IQ Mixer/Multiplexer Figure 5.2 IQ–SMX-6 Block Diagram Page 22 IQ–AMB-5 / IQ–SMX-6 Reference Manual... -
Page 23: Iq Audio In Depth
AMB-5 / SMX-6 IQ Mixer/Multiplexer 6 IQ Audio In Depth This section provides additional information about Crown’s IQ System with special guides to aid in the installation and use of the IQ–AMB-5/IQ–SMX-6. For more information about any of these topics, contact the Crown Technical Support Group. -
Page 24: Iq-Amb-5 Ambient Sensing Input
– The most common use of the sensing input is to con- nect a microphone (such as a Crown PZM – cate the microphone so that it can accurately receive the ambient sound level. Great care must be taken in... -
Page 25: Stack Inputs
For example, two 6x2 IQ–SMX-6s can be stacked to create a 12x2 mixer. This is described in Section 6.1.4 The bus outputs are turned on or off by relays and func- tion like the AUX “send”... -
Page 26: Paralleling Inputs
(P), select it only at the first input. Switch all other parallel inputs to mic (M).* * When mixer inputs are paralleled, the total input impedance will drop by 1/ N where N is the number of inputs to be connected. Depending on the signal source, this may place a limit on the number of possible outputs. -
Page 27: Using The Aux Port
To do this the AUX connector might be used to close a relay. The relay would then turn the fans on or off. This is shown in Figure 6.14. The solid state relay shown (Crown part number D 7308-7) can be ordered from the Crown Parts Depart- ment. -
Page 28: The Mixer/Multiplexer As Iq Interface
* Because Loop IQ Interface and CLN use the same DB9 connector, they cannot be used at the same time. This means that IQ–SMX-6s to be used in a CLN will need to be connected to a Crown Bus via an external IQ interface for setup. -
Page 29: A Closer Look At Crown Bus Wiring
However, there are extreme situations when fiber optic wiring is recommended. For example, locating a Crown Bus loop next to an AM radio trans- mission line may require fiber optic cabling. An ex- tremely long Crown Bus loop distance may also require fiber optic cabling. -
Page 30: Iq Address Tables
Address Figure 7.1 IQ Address Switch Settings from 0 to 125 Page 30 which are connected to the same Crown Bus loop can have the same address. To use the IQ address tables, simply find the address you want and set the IQ address switch of the mixer/ multiplexer as described in Section 3.2.1. -
Page 31: Figure 7.2 Iq Address Switch Settings From 126 To 250
AMB-5 / SMX-6 IQ Mixer/Multiplexer IQ Address Switch Address Figure 7.2 IQ Address Switch Settings from 126 to 250 IQ–AMB-5 / IQ–SMX-6 Reference Manual IQ Address Switch Address IQ Address Switch Address Page 31... -
Page 32: Factory Service
Please contact us if other arrangements are re- quired. Factory Service Shipping Instructions: 1. When sending a Crown product to the factory for service, be sure to fill out the service information form that follows and enclose it inside your unit’s shipping pack. - Page 33 AMB-5 / SMX-6 IQ Mixer/Multiplexer Crown Factory Service Information Shipping Address: Crown International, Inc., Factory Service, Plant 2 SW, 1718 W. Mishawaka Rd., Elkhart, IN 46517 Phone: 1-800-342-6939 or 1-219-294-8200 Fax: 1-219-294-8124 Owner’s Name: _________________________________________________________________________ Shipping Address: ______________________________________________________________________ Phone Number: _____________________________ Model: ________________________ Serial Number: ______________ Purchase Date: ___________ (Be sure to describe the conditions that existed when the problem occurred and what attempts were made to correct it.)
