- Page 1 User Manual & (EN) 21-03-2022 Spare Parts Catalogue Irrigator Fasterholt Maskinfabrik A/S Telephone: +45 97 18 80 66 Ejstrupvej 22 Telefax: +45 97 18 80 40 7330 Brande E-mail: mail@fasterholt.dk Denmark Web: www.fasterholt.dk...
-
Page 2: Table Of Contents
Contents EU Declaration of Conformity General Safety Introduction BORDING Type 2-3-4-5TT2 Irrigator Operating instructions Working area Transport Positioning Unwinding the hose Start-up PTO rewind Gun trailer Maintenance Preparation for winter Troubleshooting table Technical data Nelson SR 150 Product labelling Symbols used in this product Spare parts Chassis and turntable Rim, tyre and wheel shaft... -
Page 3: Eu Declaration Of Conformity
EU Declaration of Conformity EEC Declaration of conformity Manufacture (name and Fasterholt Maskinfabrik A/S address): Adresse: Ejstrupvej 22, CVR: 58 83 28 12 Fasterholt TEL: +45 97 18 80 66 Ort: 7330 Brande FAX: +45 97 18 80 40 Country: Denmark E‑Mail:... -
Page 4: General Safety
Fasterholt Maskinfabrik only guarantees new machines sold through an authorised Fasterholt dealer and only after the enclosed start-up list has been reviewed, completed and signed. In the event of any structural change/modification carried out on the irrigator without the written consent of A/S Fasterholt Maskinfabrik, we disclaim all liability and the warranty shall be declared void. - Page 5 General: It is a prerequisite for handling the irrigator that you read this instruction manual carefully before using the machine. Only allow properly trained and qualified persons to operate the machine. Only one person (the operator) must be in the vicinity of the machine during transport, setup, operation and dismantling =”not in operation”.
- Page 6 3-4-5TT Pos 1 ........... . Lever for turntable Pos 2 .
-
Page 7: Operating Instructions
Operating instructions 3-4-5TT Pos 1 ........Sliding bushing Pos 2 . -
Page 9: Working Area
Working area The working area of the machine is the application of water, waste water and other liquids, with a dry matter content not exceeding 15%. Particles in the liquid must not exceed 10 mm, as this would clog the machine turbine. The machine must be supplied with a maximum pump pressure of 12 bar. - Page 10 POS 3 GEAR SPEED M/H 7 - 20 15 - 45 25 - 65 40 - 100...
-
Page 12: Start-Up
At low pressure stop, open the butterfly valve to allow some water through, the pressure will drop and the pump will stop via a pressostat. If high pressure or low pressure is changed, contact your Fasterholt dealer. Stop buffer... -
Page 13: Pto Rewind
Manual stop The machine can be stopped either at the pump or by pressing “STOP” on the computer. If the hose is to be rewound after stopping, see the section PTO rewind. Safety stop The safety bar on the rewind side of the machine ensures that the machine stops when the hose is wound incorrectly. The safety cable ensures that the machine stop will in case of computer failure. -
Page 15: Maintenance
Maintenance Important: After the first 25 operating hours: Retighten the machine. Adjust the chains and V-belts. Adjust the hose guide. After 25 hours of operation, it may be necessary to adjust the hose guide. The hose guide must lay each hose turn tightly up against the previous hose turn (see Fig. -
Page 16: Preparation For Winter
Preparation for winter Before the frost sets in, prepare the machine for winter. Contact your BORDING dealer to request a winter service visit. This avoids unnecessary downtime during the season. Preparation includes the following points: The machine and hose must be drained of water either by compressed air or by unwinding the hose into the field and rewinding it with the PTO rewind. -
Page 17: Troubleshooting Table
Troubleshooting table Error Cause Solution Drum stop Foreign object in turbine Remove front cover from turbine and clean. Never use force to turn the turbine. Clutch lever not engaged Engage lever Computer failure Check computer Three-way valve is stuck Check three-way valve Computer error Battery flat Charge or replace... -
Page 18: Technical Data
Technical data Nelson SR 150 is factory-adjusted to Danish conditions and ready to use after the following three steps: Select and install the nozzle size that best suits your application. Performance data for the different sizes are shown in the table below. Adjust the stop on the part circle to obtain the desired irrigation angle. -
Page 19: Product Labelling
Product labelling Symbols used in this product The following symbols are used in this product and the following documentation. WARNING Indicates a potentially dangerous situation which, if not prevented, could result in death or serious inju- SMØRING LUBRICATION Indicates lubrication is required as per the service description. Str: 100x45 mm HUSK efterspænding... - Page 20 Functions: Pressure sensor Speed regulator Stop sensor Pre- and Post-irrigation Speed sensor 4 different speeds on sections of the lane Motor 1, regulating motor Clock Motor 2, stop motor Setting the start time Slow start of turbine Stop time is shown on the display Slow closing of inlet Length of hose Water volume + spreading width...
- Page 21 Short instructions for use Move machine to a new lane. Display shows start and stop time. Pull hose out to end of the lane. (e.g. 250 m) Display now shows stop after 9h 20m. Press the "+" or "-" key to set the speed.
- Page 22 General instructions for use Standard display Standard display, ZONE irrigation is selected. Press the MENU key 1 time to display menu 2 Press the MENU key 2 times to display menu 3 Press the MENU key 3 times to display menu 4 Press the MENU key 4 times to display menu 5 Press the MENU key 5 times to display menu 6 (Only if GSM is selected)
- Page 23 Standard menu: Standard display Speed. Can be changed at any time during irrigation using the "+" and "-" keys. SPEED ZONE Current zone 1...4, with corresponding speed. The speed cannot be changed. (Zone active) The dose is calculated from the speed and constants and shows the current number of mm for irrigation. As DOSE SPEED increases, DOSE decreases.
- Page 24 MENU 3 PRESSURE SENSOR Shows that the pressure is high when block is lit. The machine can only move when the pressure is high. If no pressure sensor is fitted (machine data 14 = 0), the machine will operate regardless of pressure status. The machine can be fitted with analogue pressure sensors.
- Page 25 MENU 4 CURR. SPEED Shows the current speed. That is, the speed at which the machine is moving now. This can be used to find how fast the machine can move. The current speed may differ slightly from the set speed, especially at the start. This does not matter, as regulation ensures that the average speed within 10 metres is correct.
- Page 26 MENU 6 SIGNAL GSM signal strength. NETWORK GSM network. First number on "SMS" list. Second number on "SMS" list. See GSM chapter for details. START: The turbine can only start if the magnet is aligned with the end stop sensor (or end stop sensors). See menu 3 for control of the STOP SENSOR. Press the START key to turn on the water.
- Page 27 PRE-IRRIGATION: If pre-irrigation is required, press the PRE- key. The pre-irrigation time is calculated as 8 x the time to move 1 m at the current speed. The constant can be changed individually for pre- and post-irrigation. (See constants). If pre-irrigation is selected, the machine will move forward approx. ½ m, after which the machine will stop and stand still for as long as pre-irrigation is performed.
- Page 28 STATUS Status line in display **IRRIGATING** The machine has not started, but speed signals are being received and it is attempting to maintain the selected speed. IRRIGATING: The machine is irrigating and functions as intended. LOW PRESSURE: Water pressure is low. Individual action according to constants and machine data. STARTING: User has pressed the START key and start sequence is being performed.
- Page 29 There are a variety of constants that can be modified by the user. These constants will be stored for many years, even if the battery is removed. Programming procedure: Adjust the speed to 11.1 m/h to access the constants. Press the PROG key 3 times in quick succession to access and change the constants. Press the PROG key again to count forward to the constant you wish to change.
- Page 30 MACHINE DATA Machine data Possible setting Factory number setting Flashing digit 0 - 1,000m Not used Hose length 40 - 200 mm Hose diameter 500 - 3000 mm Not used Hose drum int. Diameter 5.00 - 30.00 Number of hose turns per layer 50 - 1000 Not used Large gear on hose drum...
- Page 31 MACHINE DATA...
- Page 32 Program Rain can be set to 2 different types of sensors. See machine data no. 16 Sensor One is a round sensor with 4 built-in sensors and can only be used for rollers with 1 magnet. When the battery is connected, the display shows the following for 2 seconds: VERSION n.n0.
- Page 33 Troubleshooting: The turbine does not start when the START key is pressed. Answer: The magnet at the stop sensor is not in position or the sensor or sensor cable is damaged. Stop sensor: The mark must be on when the magnet is in position and off when the magnet is removed. See Menu 3. A damaged cable can be assembled in an epoxy moulded assembly or with shrinkable tubing and glue.
- Page 34 Combining the various constants: The machine will always be able to run with the factory-set constants. However, there will be different conditions from farm to farm and from machine to machine. Many requests can be met by changing the constants. Slow start-up of turbine.
- Page 35 GSM-2G Modem Functions • Dual band 850/900/1800/1900 MHz • GPRS multi slot class 12/10 Easy installation on PR10-12 • GPRS mobile station class B Low power consumption • Compliant to GSM phase 2/2+ Total 10 mA consumption, PR10-12 and GSM-2G Class 4 (2 W @850/900MHz) Visible status LED Class 1 (1 W @1800/1900MHz)
- Page 36 GSM-2G is a GSM modem made for PR10-12. The machine can be started, stopped or queried about status by sending an SMS. Commands Start Starts the machine. Stop Stops the machine Speed ### Set the desired speed 3 to 400 m/h Status Returns the current machine status.
- Page 37 How to start the system: Disconnect the battery from the electronics. Insert the SIM card in a regular mobile phone and change the pin code to 1111. Try sending and receiving an SMS to see whether the SIM and account work as intended. MUST Note that SIM card support...
- Page 38 Modem has LED to indicate status. Green Switched off - Searching the network Flashes quickly - No SIM card in modem - Incorrect PIN code - No GSM network available STANDBY (Registered on network) Flashes slowly Connection (TALKING) When an SMS is received, the display shows: Receiving an SMS, sender's phone number and 40 characters of message.
-
Page 40: Spare Parts
Spare parts... - Page 84 A/S FASTERHOLT MASKINFABRIK EJSTRUPVEJ 22, DK-7330 BRANDE DENMARK TEL.: +45 97 18 80 66 FAX: +45 97 18 80 40 E-MAIL: MAIL@FASTERHOLT.DK www.fasterholt.dk...
