Page 1: Ethernet Switch
32-Port 10/100Mbps Ethernet Switch User Guide 32-Port 10/100Mbps Ethernet Switch User Guide UG-ASW232-1103 AirLink+... -
Page 2: Ce Mark Warning
Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer's maximum rated ambient temperature (t • Reduced Air Flow⎯Installation of the equipment in a rack should be such that the amount of air flow AirLink+... - Page 3 • Reliable Earthing⎯Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g., use of power strips). AirLink+ 32-Port 10/100Mbps Ethernet Switch User Guide...
- Page 4 32-Port 10/100Mbps Ethernet Switch User Guide AirLink+...
-
Page 5: Table Of Contents
Rack Mounting ... 14 Connecting Network Cable ... 15 Power On ... 15 External Components ... 15 Front Panel ... 15 Twisted Pair Ports ... 17 Rear Panel ... 17 LED Indicators ... 18 AirLink+ 32-Port 10/100Mbps Ethernet Switch User Guide... - Page 6 32-Port 10/100Mbps Ethernet Switch User Guide Connecting the Switch... 18 Connecting a PC to the Switch ... 18 Connecting a Hub or Switch to the Switch ... 19 Port Speed & Duplex Mode ... 19 Technical Specifications ... 20 Technical Support ... 22 AirLink+...
-
Page 7: About This Guide
Switch’s front panel, rear panel, and LED indicators. T T T T T echnical Specifications echnical Specifications echnical Specifications echnical Specifications⎯Lists the Switch’s technical echnical Specifications (general, physical and environmental, and performance) specifications. AirLink+ 32-Port 10/100Mbps Ethernet Switch User Guide... -
Page 8: Introduction
10Mbps Ethernet environments, it provides a straightforward upgrade and takes advantage of the existing investment in hardware, software, and personnel training. Switching Technology Another approach to pushing beyond the limits of Ethernet technology is the development of switching technology. A AirLink+... - Page 9 Routers have also been used to segment LANs, but the cost of a router, the setup and maintenance required make routers relatively impractical. Today switches are an ideal solution to most kinds of LAN congestion problems. AirLink+...
-
Page 10: Features
The Switch combine dynamic memory allocation with store- and-forward switching to ensure that the buffer is effectively allocated for each port, while controlling the data flow between the transmit and receive nodes to guarantee against all possible packet loss. AirLink+... -
Page 11: Unpacking & Installation
100Mbps speed. • 4K active MAC address entry table with self-learning and table ageing. • 1,024-KBytes RAM of buffer per device. Unpacking & Installation This chapter provides unpacking and setup information for the Switch. AirLink+ 32-Port 10/100Mbps Ethernet Switch User Guide... -
Page 12: Unpacking
Leave at least 10 cm of space at the front and rear of the hub for ventilation. • Install the Switch on a sturdy, level surface that can support its weight, or in an EIA standard-size equipment rack. For information on rack installation, see the next section, Rack Mounting. AirLink+... -
Page 13: 100 Base-Fx Module Installation
Using a screwdriver, replace the two screws and tighten until snug. AirLink+ recommends that you retain the dust cover in case you need to remove the module for an extended period sometime in the future. -
Page 14: Rack Mounting
(one on each side), and secure them with the provided screws (see Figure 1). Figure 1. Attach Brackets to Switch Then, use screws provided with the equipment rack to mount each switch in the rack (see Figure 2). Figure 2. Attach Switch to Rack AirLink+... -
Page 15: Connecting Network Cable
This section identifies all the major external components of the switch. Both the front and rear panel is shown, followed by a description of each panel feature. The indicator panel is described in detail in the next chapter. Front Panel Figure 3 shows the Switch’s front panel. AirLink+... - Page 16 32-Port 10/100Mbps Ethernet Switch User Guide AirLink+...
-
Page 17: Twisted Pair Ports
Figure 4. Rear Panel Rear of Switch Module Slot AC Power Connector Module Slots The module slots are used to install module options for 100 BASE-FX connection. AC Power Connector Plug the power cord into the AC power connector. AirLink+... -
Page 18: Led Indicators
A PC can be connected to the Switch via a two-pair Category 3, 4, 5 UTP/STP cables. Connect the PC (equipped with a RJ-45 10/100Mbps phone jack) to any of the 32 ports (1 to 32) een/amber) een/amber)⎯This indicator lights een/amber) een/amber) een) een) een)⎯This een) AirLink+... -
Page 19: Connecting A Hub Or Switch To The Switch
If the attached device does not support auto-negotiation or has auto-negotiation disabled, an auto-sensing process is initiated to select the speed and set the duplex mode to half- duplex. AirLink+ 32-Port 10/100Mbps Ethernet Switch User Guide... -
Page 20: Technical Specifications
10 Base-T: Two-pair UTP Cat. 3, 4, 5; EIA/TIA-568 cables 100-Ω STP 100 Base-TX: Two-pair UTP Cat. 5; EIA/TIA-568 100-Ω STP 100 Base-FX: 62.5/125 µm multimode fiber optic 32 × 10/100Mbps auto-MDI/MDI-X ports Number of ports Expansion One expansion slot for 100 Base-FX slot Description AirLink+... - Page 21 Storage: −10˚ to 70˚ C Humidity Operating: 10 to 90% Storage: 5 to 90% 440 × 200 × 44 mm (W × H × D) Dimensions FCC Class A, CE Mark Class A, VCCI Class A AirLink+ 32-Port 10/100Mbps Ethernet Switch User Guide Specification...
-
Page 22: Technical Support
RAM buffer 1,024 Kbytes per device Filtering 4K entries per device address table Packet filtering/ 10Mbps ethernet: 14,880/pps forwarding rate 100Mbps fast ethernet: 148,800/pps MAC address Automatic update learning Technical Support E-mail: support@airlinkplus.com Toll Free: 1-888-746-3238 Web Site: www.airlinkplus.com Specification AirLink+... - Page 23 32-Port 10/100Mbps Ethernet Switch User Guide AirLink+...
- Page 24 AirLink+. All other product or service names are the property of their respective holders. AirLink+ products are protected under numerous U.S. and foreign patents and pending applications, maskwork rights, and copyrights.
