- Page 1 5-Port 10/100/1000Mbps Gigabit Ethernet Switch User Guide 5-Port 10/100/1000Mbps Gigabit Ethernet Switch (Desktop) User Guide UG-AGIGA5SW-1105 AirLink+...
-
Page 2: Ce Mark Warning
5-Port 10/100/1000Mbps Gigabit Ethernet Switch User Guide This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: Table Of Contents
5-Port 10/100/1000Mbps Gigabit Ethernet Switch User Guide Table of Contents About this Guide ... 4 Terms ... 4 Overview of This User Guide ... 4 Introduction ... 5 Gigabit Ethernet Technology ... 5 Switching Technology ... 6 Features ... 7 Unpacking &... -
Page 4: About This Guide
5-Port 10/100/1000Mbps Gigabit Ethernet Switch User Guide About This Guide This user's guide tells you how to install your 5-Port 1000BASE-T Gigabit Ethernet Switch, how to connect it to your Gigabit Ethernet network. Terms & Usage For simplicity, this documentation uses the terms "Switch"... -
Page 5: Introduction
5-Port 10/100/1000Mbps Gigabit Ethernet Switch User Guide Introduction This section describes the features of the 5-Port 1000BASE-T Gigabit Ethernet Switch, as well as providing some background information about Gigabit Ethernet and switching technology. Gigabit Ethernet Technology Gigabit Ethernet is an extension of IEEE 802.3 Ethernet... -
Page 6: Switching Technology
5-Port 10/100/1000Mbps Gigabit Ethernet Switch User Guide amount of time. Switching Technology Another key development pushing the limits of Ethernet technology is in the field of switching technology. A switch bridges Ethernet packets at the MAC address level of the Ethernet protocol transmitting among connected Ethernet or fast Ethernet LAN segments. -
Page 7: Features
5-Port 10/100/1000Mbps Gigabit Ethernet Switch User Guide Features The 5-Port 1000BASE-T Gigabit Ethernet Switch was designed for easy installation and high performance in an environment where traffic on the network and the number of users increase continuously. Five 1000BASE-T Gigabit Ethernet ports... -
Page 8: Unpacking & Installation
5-Port 10/100/1000Mbps Gigabit Ethernet Switch User Guide Unpacking & Installation This chapter provides unpacking and setup information for the Switch. Unpacking Open the shipping carton and carefully unpack the contents. The carton contains the following items: One 5-port 10/100/1000Mbps Gigabit Ethernet... -
Page 9: External Components
5-Port 10/100/1000Mbps Gigabit Ethernet Switch User Guide External Components This section identifies all the major external components of the switch. Both the front and rear panel is shown, followed by a description of each panel's feature. Front Panel Figure 1 shows the Switch’s front panel. -
Page 10: Led Indicator Panel
5-Port 10/100/1000Mbps Gigabit Ethernet Switch User Guide LED Indicator Panel The LED indicator panel contains the following indicators: POWER POWER POWER POWER POWER - This indicator lights green when the Switch is receiving power, otherwise, it is off. Link/Act Link/Act - These LED indicators are lighted up when... - Page 11 5-Port 10/100/1000Mbps Gigabit Ethernet Switch User Guide 1000BASE-T Ports Five Gigabit Ethernet ports of 10/100/1000Mbps Auto- Negotiation interface. DC Power Jack Power is supplied through an external AC power adapter. Check the technical specification section for information about the AC power input voltage.
-
Page 12: Technical Specifications
5-Port 10/100/1000Mbps Gigabit Ethernet Switch User Guide Technical Specifications Tables 1 to 3 provide Switch specifications. Table 1. General Specifications Feature IEEE 802.3 10 Base-T ethernet Standards IEEE 802.3a 100 Base-TX fast ethernet IEEE 802.3ab 1000 Base-T gigabit IEEE 802.3x flow control... - Page 13 5-Port 10/100/1000Mbps Gigabit Ethernet Switch User Guide Table 2. Physical & Environmental Specifications Feature DC inputs 7.5 V, 1.5 A Power 8.5 watts (maximum) consumption Temperature Operating: 0˚ to 40˚ C Storage: 10˚ to 70˚ C Humidity 5 to 90% RH, non-condensing...
-
Page 14: Technical Support
5-Port 10/100/1000Mbps Gigabit Ethernet Switch User Guide Table 3. Performance Specifications Feature Transmission Store-and-forward method RAM buffer 256 Kbytes per device Filtering 8K entries per device address table Packet filtering/ Full wire speed forwarding rate MAC address Self-learning, auto-aging learning Technical Support E-mail: support@airlinkplus.com... - Page 15 5-Port 10/100/1000Mbps Gigabit Ethernet Switch User Guide AirLink+...
