14 Spare Parts List Morticing Attachment HC 320/410
Pos. Description
1 Carrier frame
2 Funnel housing
3 Table support
4 Clamping table
5 Guide rod 330
6 Guide rod 424
7 Shaft
8 Threaded rod
13 Operating level
14 Carrier
15 Threaded bolt-welded ass'y
16 Threaded rod 440
17 Joint ball
18 Joint cap
19 Conical gear wheel-rise and fall
21 Suction connector
22 Auxiliary fence plate
23 Shim plate
24 Clamping arm support
25 Clamping arm
26 Threaded bolt
27 Clamp head
28 Dowel pin
29 Adapter-drill chuck
30 Drill chuck cover
31 Cover bracket-right
32 Cover bracket-left
501 Hexagon head bolt
502 Hex. socket head cap screw
503 Hex. socket head cap screw
504 Hexagon head screw
505 Hexagon head screw
506 Hexagon nut
507 Hexagon nut, self-locking
508 Cap nut
509 Knurled nut, thin type
510 Disk spring
512 Woodruff key
513 Washer
514 Crank handle
515 Clamping ring
516 Permaglide bearing
517 ELESA mushroom head handle
518 Bearing bushing
519 Thrust washer
520 Axial needle bearing
521 Hex. socket countersunk head screw
522 Hexagon nut, self-locking
523 Washer
526 Washer
527 Starknob screw
528 Drill chuck
529 Ratched lever
530 Washer
531 Hexagon nut, self-locking
532 Washer
533 Ratchet lever
534 Countersunk screw
535 Cheese head screw
536 Hexagon nut, self-locking
537 Raised countersunk head screw
Dimensions DIN
Ø 20x330
Ø 20x424
Ø 16x355
Ø 16x218
Ø 17x750
M 8x250 galv.
M 8x440 galv.
Ø 30x22
Bl 2x177.3x228 1203
Bl 2x43.5x129 1203
Bl 2x43.5x129 1203
M 8x25 galv. 933
M 6x20 galv. 912
M 6x25 galv. 912
M 6x12 galv. 933
M 6x20 galv. 933
M 8 galv. 934
M 10 galv. 985
M 8 galv. 1587
M 8 galv. 467
16x8.2x0.6 2093
5x6.5 6888
B 8.4 9021
160 - K 14
Ø 16
PAP 2020 P 10
GN 718-45-B 10-5
16/20/24x16
INA AS 1226
INA AXK 1226
M 8x25 galv. 7991
M 8 galv. 985
A 8.4 galv. 125
A 10.5 galv. 125
M 8x48 galv.
2.5-16
M 8x20
B 6.4 galv.
M 6 galv.
A 6.4 galv.
M 6
M 6x20 galv. 963
M 5x12 galv. 7985
M 5 galv. 985
St 4.8x13 -C-H galv. 7981
Stock-no.
138 022 0080
138 022 0098
138 022 0101
138 022 0110
148 522 0123
148 522 0131
148 522 0140
148 522 0158
148 522 0204
148 222 0211
663 114 3448
663 122 0230
148 522 0247
148 222 0254
138 021 8565
138 105 3489
148 222 0289
148 222 0300
139 502 9009
138 022 0322
148 522 0336
138 121 6434
148 540 3732
148 521 9893
138 222 0435
138 222 0443
138 222 0451
610 300 1194
612 100 0758
612 100 0766
610 300 1127
610 300 1135
620 000 2235
620 200 2313
620 100 2131
624 100 5982
705 301 6795
672 000 8538
630 500 2486
700 316 7709
641 101 7636
715 117 9988
700 817 9993
715 121 8576
710 416 7670
710 416 7661
613 215 8523
620 200 2305
630 001 6322
630 001 6349
700 111 4667
943 118 0062
700 604 3407
630 500 2087
620 200 2291
630 001 6365
700 607 2385
613 001 9585
612 300 2049
620 200 2283
617 201 5687
