User Manual
Quick Start Guide
200-11 Anyang-dong, Manan-gu, Anyang-si,
Gyeonggi-do, South Korea
E-mail : help@myviliv.com
Intel Atom Silverthorne 1.33Ghz
Superfine 4.8" Touch LCD with Virtual Haptic Keyboard
200 hours Standby Time
6 hours continuous movie Playback
Bluray HD Video Playback
HDD 30G/60G, Windows XP
This guide is subject to change for product improvement without prior notice.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Viliv S5
Summary of Contents for Viliv S5
- Page 1 Quick Start Guide 200-11 Anyang-dong, Manan-gu, Anyang-si, Gyeonggi-do, South Korea E-mail : help@myviliv.com Intel Atom Silverthorne 1.33Ghz Superfine 4.8” Touch LCD with Virtual Haptic Keyboard 200 hours Standby Time 6 hours continuous movie Playback Bluray HD Video Playback HDD 30G/60G, Windows XP This guide is subject to change for product improvement without prior notice.
- Page 2 Thank you for purchasing viliv. Please read the Precautions before using the product.
-
Page 3: Table Of Contents
This device is properly registered for home use (Grade B) and is designed for use not only in residential areas but also anywhere else. Registered Trademark viliv is Yukyung Technologies’ registered trademark. Windows 2000, Windows XP and Windows CE are Microsoft Corporation’s registered trademarks. Exemption... -
Page 4: Safety Precautions For Use
Safety Precautions for Use The following precautions are provided to protect you from possible danger and to prevent any damage to property. Please observe them. • Do not touch the power cord with wet hands. Precautions on Power • Be sure to plug the power cord in an outlet with a grounded jack. •... -
Page 5: Names Of Parts
Names of Parts The pictures of the components below may differ from the actual components, and some components may be changed depending on the situation. Basic Components The main body The standard slip-in/out battery Ab AC/DC power adapter A USB cable ULTRA PC PMP www.myviliv.com Names of Parts... -
Page 6: Top View
Names of Parts Top View Emits heat generated by the device. ※ If the heat emission hole is blocked, the device can overheat, Heat emission hole which can be dangerous. Take care not to allow this to be blocked. ※ Take care not to allow water into this hole. Earphone jack Connect the earphone or speakers through this. -
Page 7: Back View
Names of Parts Back View The picture above shows the main body without the battery. (Refer to page 15 for the battery separation/ placement.) Battery recharging contact Battery jack’s contact area. Lift the battery up in the direction indicated in the picture; then the Battery separation/ Hold battery is separated. -
Page 8: Multi-I/O Jack
Installation and Cable Connection Multi-I/O Jack This can be used to connect an LCD monitor or a digital TV. (The icon on the back of a monitor may be different depending on the product.) Yellow Composite (Video) White Composite (Audio) Blue Green Component... -
Page 9: Power Connection (With Rechargeable Adapter For Home)
Installation and Cable Connection Power Connection (with Rechargeable Adapter) Connect the rechargeable adapter to the power adapter jack on the left side of the device. Rechargeable Adapter Notice The recharging status of the battery is as follows: The device’s power indicator: When charging - red, When fully charged - blue. The battery icon: When charging - , When fully charged - ULTRA PC PMP... -
Page 10: Directions To Insert/Remove Usim Card
Battery Separation/Placement Directions to Insert/Remove USIM Card To insert : Place the front part of the USIM card into the USIM card slot, and insert it in the direction of the arrow until it clicks. (When inserting a USIM card, pushing it too hard may damage the card.) To take out : It is one-touch type, so pressing the end of a USIM card lightly will eject it. -
Page 11: Volume Control
Basic Operations Volume Control Volume Control Adjust volume by pressing the VOL button on the upper area of the device. Mute Mute Press the middle of the VOL button on the upper area of the device. The MUTE function is on. Resetting Use the Reset button if the touch screen and/or the buttons on the device do not work. -
Page 12: Virtual Keyboard
] icon on the task bar and select ‘Exit’. ULTRA PC PMP www.myviliv.com The following are Frequently Asked Questions and the answers to them concerning viliv usage. Check them before contacting Customer Service. The power does not come on, and nothing appears on the LCD screen. -
Page 13: Faq
0℃ ~ 60℃ Wireless Specifications Device Name (Model Specified Low Power Wireless Device for Wireless Data Communication Name) System Certificate Number YPK-S5(B) Transmission Frequency 2412~2472MHz / 2402~2480MHz Reception Frequency 2412~2472MHz / 2402~2480MHz Output of Antenna BT = 0.00001W/MHz , WLAN=0.01W/MHz...
