- Page 1 User’s Manual This guide may be changed for product improvement without prior notice.
- Page 2 Thanks for purchasing viliv. Please read the precautions throughly before using the product.
- Page 3 Grade B Device (Broadcast Communication Device for Residential Area) Registered Trademark viliv is the registered trademark of Yukyung Technologies Corp. Windows7, Windows Vista, Windows XP, Windows 2000, Windows CE are the registered trademarks of Microsoft Corporation. Liability Disclaimer...
-
Page 4: Table Of Contents
Contents Safety Precautions for Use ..........4 Names of Parts ..............7 Basic Components ................7 Front View ..................8 Keyboard ...................9 Top View ....................10 Left / Right View ................11 Rear View ..................12 Installation and Cable Connection ........13 Connecting the Earphone & Microphone Combo Port ......13 USB Connection ................14 USB Data Link Connection ..............14 Power Connection (Charging Adaptor) ..........15... -
Page 5: Safety Precautions For Use
Safety Precautions for Use Warning Please observe the instructions below. Failure to do may cause heating, fire, explosion, etc. If the battery can be seen to be swollen, there may Do not allow metal products, such as a necklace, coil, be imminent danger. - Page 6 Safety Precautions for Use The precautions below are provided to prevent bodily injury or property damage by using this product correctly. Please observe the precautions. Precautions on Power Do not touch the power adapter with wet hands. Plug the power cord into an outlet with grounded jack. Be sure the plug goes in all the way and is not loose.
- Page 7 Safety Precautions for Use The device functions vary depending on model. Read the relevant precautions for the provided function before using the device. Precautions for the Bluetooth Do not attempt to operate the Bluetooth while driving. Accidents caused by such improper handling are the sole responsibility of driver.
-
Page 8: Names Of Parts
Names of Parts The appearance of the components below may differ from the actual components and some components are subject to change. Basic Components Main Body Standard Removable Battery AC/DC Power Adapter Stylus Pen (embedded in the main body) USB Cable User’s Manual English... -
Page 9: Front View
Names of Parts Front View WEBCAM Equipped with webcam. TFT LCD/Touch Screen Users can operate the device using the touch screen. Power Indicator Lamp Displays the power ON/OFF status. Operation Status Indicator Power Save Mode Indicator/Disk Device Indicator/ Battery Charging Status Indicator/Wireless LAN Indicator Power Save Mode Indicator This light is turned on while the device is in power savemode. -
Page 10: Keyboard
Names of Parts Keyboard The keyboard may be different for each country. Esc Key It is usually used for terminating or interrupting programs. Function Keys (F1~F12) Usages are different depending on the operating system used and application program PrtSc Key (Print Screen) This key is used for printing the screen or temporarily saving the screen. -
Page 11: Top View
Names of Parts Top View Power Adapter Port For connecting power adapter or charging the battery. D-SUB It is used to connect an external screen such as monitor or projector. English... -
Page 12: Left / Right View
Names of Parts Left / Right View USB Port For connecting to external devices with USB port. Link Port For connecting to a computer. Stylus Pen Stores a stylus pen. Multi I/O Port Used for external video output (component video, composite video, and S-video). Earphone &... -
Page 13: Rear View
Names of Parts Rear View The figure below shows the rear side of the main body without the battery. (Refer to Page 18 for Separating/Attaching battery.) Separating/Attaching Battery Push the battery downward to separate the battery, as shown in the figure above. Battery Charging Port Connection part of battery terminal. -
Page 14: Installation And Cable Connection
Installation and Cable Connection Connecting the Earphone & Microphone Combo Port Connect the accessory devices to the earphone & microphone combo port located on the right side of the device. Pin-outs of the 4-pin headset connector LEFT RIGHT Notice When using an external speaker, connect the speaker with a standard 3.5ø stereo cable to the earphone &... -
Page 15: Usb Connection
Installation and Cable Connection USB Connection This is used for the connection of external devices, such as digital camera, external HDD, etc. USB Data Link Connection Connect the USB cable to the USB LINK port located on the left side of the device. English... -
Page 16: Power Connection (Charging Adaptor)
Installation and Cable Connection Power Connection (Charging Adaptor) Connect the charging adapter to the power supply adapter port located on the back of the device. Notice Battery charging status indicator While charging (using AC adapter) Red: charging / Blue: fully charge English 15... -
Page 17: Inserting · Extracting Usim Card
Installation and Cable Connection Inserting · Extracting USIM Card How to Insert Let the front of a USIM card face the USIM card slot and then push it in the arrow direction until a click sound is heard. (If, however, you push the USIM card using too much force, the card may be damaged.) How to Extract Since this device adopts a one-touch method, you may gently press on... -
Page 18: Rotating Lcd Screen
Installation and Cable Connection Rotating LCD Screen LCD screen can be rotated for the convenience of the user. It can be rotated up to 180 degrees in a clockwise direction. Notice Take care not to use excessive force to rotate the screen more than the allowed 180 degrees, otherwise it may result in a malfunction. -
Page 19: Separating · Attaching Battery
Separating · Attaching Battery Separating Battery Push the battery release/lock button located on the bottom of the device in the direction shown in the picture. Remove the battery. Notice Separate the charger after turning the power of the station off. If not, you may receive an electric shock by a short circuit in the battery power part. -
Page 20: Basic Operation
Basic Operation Turning the Power On/Off Turning the power on Depress the power button for about two seconds to turn on the power. The LCD screen turns on and the main screen is displayed. Turning the power off Use the “Shutdown” menu in the Start Menu to turn off the device while Windows is running. -
Page 21: Running Virtual Keyboard
Activate/Deactivate Virtual Keyboard Double click the vilivSoftkeyboard icon to activate/ deactivate the virtual keyboard. Set Up for villv Manager viliv Manager is executed by double touching vilivManager on the screen. Wireless LAN Power Activate the wireless LAN. Bluetooth Power Activate the Bluetooth function. -
Page 22: Recovery Solution (Ami Rescue) Guide
HDD of user cannot be booted from OS or it has problems. Way to Use Recovery Solution (AMI Rescue) Execution of Recovery Solution (AMI Rescue) If viliv logo appears when booting the system (BIOS POST), press the F10 key 1-2 times. As the logo disappears, Pre-Boot Menu window appears. -
Page 23: General Specifications
Specifications The specifications below may be changed for enhancement of product performance without prior notice. General Specifications Product Name CPU & Chipset Intel® Atom 1.60(Z530)Ghz + SCH US15W 10.1-type WXVGA(1366 x 768) / Multi Touch Panel Storage SSD 32GB IEEE 802.11b/g WWLAN (Optional) HSDPA Bluetooth... - Page 24 Memo English 23...
- Page 25 Memo English...
