Quick Start Guide
Thank you for purchasing this ABY Pedal. We hope you get many years of
pleasure and use from this device and if this is your first product from our
brand, welcome!
This simple connecting guide should help start you on your journey to
sonic creativity. However, if you wish to know more of the pedal's hidden
secrets, you can find more info on the product page at:
kmamachines.com/aby
KMA's ABY pedal features a fully passive design for the best signal integrity,
along with our True Bypass active silent relay-based soft switching.
That might well be a very wordy mouthful, but here's what it means
practically - the audio signal itself is entirely untouched and without any
colouration. However, the actual switching is taken care of by our reliable
and sturdy soft switching mechanism, with our separate active relay-
based circuit. By employing this switching technology, any mechanical
and phyisical noise from those annoying loud clicks and pops, that you
can get from many regular passive AB/Y pedals, is greatly reduced.
Also, because of its passive signal nature, our ABY can be used as a Dual
Input device, as well as a Dual Output box in either direction. This allows
you to switch instruments, amps or any kind of signal really quickly, easily
and without unplugging and or re-plugging them.
This can lead to some very creative yet simple scenarios with effects.
Here are a couple of examples to get you going:
1. Easily switch between a delay, then a fuzz or even combine them
together.
2. The pedal can send your rig into a totally different direction when
performing or looping etc.; play a riff with a guitar connected to A
through a fuzz pedal and then switch the AB/Y to B and perform a bassline
seamlessly, through exactly the same pedal or chain.

ABY Main Specifications

Passive AB/Y pedal with Active switching
Sends an input to two separate outputs or two inputs to one source,
separately or combined
Active silent relay-based soft switching, heavily reduces mechanical
noise and pops
Omnidirectional for 2 into 1 or 1 into 2 operation
Distinct LED colours, to indicate your selected signal path at a glance
Compact enclosure with top-mounted jacks - will fit into any setup
Made in Berlin

Power requirements:

9 V DC, centre -, 2.1 mm, 40 mA max. current draw
Made in Berlin, Germany since 2013
@kmamachines
Please follow us on social:
E-mail: hello@kma-machines.com | Website: www.kmamachines.com
© 2023 KMA Audio Machines UG & Co.KG
Ab/Y QSG V1.02
