internal Controls
DIRT
Lets you set the amount of your clean signal from 100% ccw to
0% for overdriven sound only.
Q
Sets the bandwith of the Mid-EQ from wide (ccw) to
wah-wah-like narrow (cw).
Technical Specs
DC-Supply: 9V maximum (center negative, standard barrel)
Current Draw: 30 mA
Input-Impedance: 1 MEG
Output-Impedance: 10 K
Safety instructions
This device is intended to be used for sound processing of
signals from musical instruments. Any other use or use
under other operating conditions is considered to be impro-
per and may result in personal injury or property damage.
No liability will be assumed for damages resulting from
improper use.
Operating conditions
This device has been designed for indoor use only. To prevent
damage, never expose the device to any liquid or moisture.
Avoid direct sunlight, heavy dirt, and strong vibrations.
External power supply
Use only with 9V power supply. Failure to do so could result
in damage to the device and possibly the user. Unplug the
external power supply before electrical storms occur and
when the device is unused for long periods of time to reduce
the risk of electric shock or fire.
Warranty
We offer a 5-year warranty. The warranty expires immedia-
tely if the product is changed, operated incorrectly, intentio-
nally or negligently damaged, or if it is damaged by force
majeure or use beyond the permitted operating conditions.
Handmade in Berlin with love!
INSTRUCTION
AND WARRANTY
l
n
oga
transcend
drive
BUILD TO TRANSCEND
YOUR BOUNDARIES OF OVERDRIVE
