Hinowa GOLDLIFT 14.70 Manual Use And Maintenance

Self-propelled tracked platform
Hide thumbs
Table of Contents

Advertisement

Quick Links

SELF
-PR
OPELLED TRA
C
KED PL
A
TF
ORM
SELF
-PR
OPELLED TRA
C
KED PL
A
TF
ORM
GOLDLIFT
1
4.70
GOLDLIFT
1
4.70
MANUAL USE AND MAINTENANCE
Valid from serial number G23
MUGL147020409

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GOLDLIFT 14.70 and is the answer not in the manual?

Questions and answers

Related Manuals for Hinowa GOLDLIFT 14.70

Summary of Contents for Hinowa GOLDLIFT 14.70

  • Page 1 SELF OPELLED TRA KED PL SELF OPELLED TRA KED PL GOLDLIFT 4.70 GOLDLIFT 4.70 MANUAL USE AND MAINTENANCE Valid from serial number G23 MUGL147020409...

  • Page 2: Table Of Contents

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA INDEX CHAPTER FOREWORD......................Page 05 CHAPTER OPERATOR’S MANUAL .................Page 05 DESCRIPTION OF THE MACHINE ..............Page 05 2.1.1 MACHINE IDENTIFICATION PLATE............Page 06 2.1.2 OVERALL DIMENSIONS OF THE MACHINE ..........Page 07 2.1.2.1 GOLDLIFT 14.70 DIMENSIONS...............Page 07 2.1.3 TECHNICAL DATA....................Page 08...
  • Page 3 CHAPTER HYDRAULIC SYSTEM ..................Page 82 GOLDLIFT 14.70 HYDRAULIC SYSTEM............Page 82 KEY DIAGRAM GOLDLIFT 14.70 HYDRAULIC SYSTEM......Page 83 GOLDLIFT 14.70 HYDRAULIC SYSTEM WITH 2 SPEED......Page 84 KEY DIAGRAM GOLDLIFT 14.70 HYDRAULIC SYSTEM WITH 2 SPEED..Page 85 CHAPTER ELECTRIC SYSTEM ..................Page 86...

  • Page 4: Chapter 1 Foreword

    DING TO NATIONAL LAWS WHICH MIGHT BE SUPPLEMENTARY TO THE CONTENTS OF THIS MANUAL. If this manual gets damaged or lost, ask directly HINOWA SPA for a replacement copy. Note: all the pictures and drawings in the manual have been added to simplify the com- prehension of the texts.
  • Page 5 When doing ordinary maintenance or repairs, ONLY USE ORIGINAL SPARE PARTS pur- chased from the dealer where the platform has been bought or directly from HINOWA Spa Spare parts Department.

  • Page 6: Chapter 2 Operator's Manual

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 1. INTRODUCTION In this manual, you can see safety-warning signs used to bring the reader’s attention to some warnings of particular importance. The warning signs comes under two main types identified and described below.

  • Page 7: Machine Identification Plate

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA When controlling the translation of the machine from the control car, take the maximum care of elements like cornices, terraces, lintels, branches etc. that could come into contact with the operator. If the machine translation is controlled from the ground (see the a.m. admitted cases),...

  • Page 8: Overall Dimensions Of The Machine

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.1.2 OVERALL DIMENSIONS OF THE MACHINE 2.1.2.1 DIMENSIONS 1470 Maximum length in running conditions......3975 mm Carriage width ..............780-1080 mm Maximum height in running conditions......1980 mm Maximum ramp angle ............18.5° Maximum stabilising angle..........10° Stabiliser base side ............2700 mm...

  • Page 9: Technical Data

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.1.3 TECHNICAL DATA 2.1.3.1 PLATFORM TECHNICAL DATA GOLDLIFT 14.70 200 kg ..120 kg ....................LOAD LOAD PLATFORM HEIGHT (tread level ) ........10,58 m ..11,94 m MAXIMUM WORKING HEIGHT ..........12,63 m ..14,00 m STANDARD CONTROL CAR DIMENSIONS ......1330x694 H1100 mm HORIZONTAL RANGE ............5,16 m ....6,24 m...

  • Page 10: Petrol Engine Technical Data

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA DANGER It is absolutely forbidden to translate and/or manoeuvre on transversal slopes with the craw- ler not extended as the machine could turn over and cause serious damages to the operator. 2.1.3.2 PETROL ENGINE TECHNICAL DATA Make/ModelHONDA GX270 Fuel/coolant ................PETROL/AIR...

  • Page 11: Electric System Technical Data

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.1.3.5 ELECTRIC SYSTEM TECHNICAL DATA Battery ................35 Ah - 125 A - 12V Alternator: - petrol engine..........10 A (3000rpm) - diesel engine ..........14 A (3000rpm) Electric engine: - electrical connection......220 V - frequency ..........50 Hz - power ..........1.5 kW...

  • Page 12: Gold Lift 14.70 Key

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.1.4.1 GOLD LIFT 14.70 KEY Extensible rubber crawler Fifth wheel + rotation engine Revolving turret Overhead part emergency controls Base + electric components box + oil tank Triple gear pump Diesel/petrol engine Electric engine...

  • Page 13: General Safety Rules

    • It is absolutely forbidden to do any alterations to the machine without any prior written authorisation from HINOWA SPA as this could damage its functioning and its safety. HINOWA SPA declines any responsibility for injury or damage caused by such beha- viour.
  • Page 14 Safety valves Never alter and/or tamper with the safety valves and the controls in the main hydraulic system. HINOWA SPA declines any responsibility for damages to people, things or the machine when the hydraulic valve standard gauging has been tampered with.

  • Page 15: Safety Advice

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.3 SAFETY ADVICE 2.3.1 GENERAL ADVICE To avoid accidents, before starting work and before doing any operations of maintenance, read, understand and follow all the warnings and instructions given in this manual. The machine operator/user cannot be held responsible if they have not read this manual and learnt how to manoeuvre the machi- ne under the supervision of a qualified operator.
  • Page 16 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA Description: WARNING! DANGER OF CRUSHING LOWER LIMBS. Location on the machine: - on the stabilisers - on the crawler. Description: WARNING! OBJECTS FALLING. Location on the machine: - on the basket. Description: MACHINE FIXING POINTS FOR TRANSPORT.
  • Page 17 Location on the machine: - on the basket. 14) Description: WARNING! 230V. Location on the machine: - on the electric differential switch box. 15) Description: GOLDLIFT 14.70 MAX. LOADS AND ARM RANGES WITH SINGLE-SEATER BASKET Location on the machine: - on the basket.
  • Page 18 DISTRIBUTOR GROUND CONTROL FUNCTIONS OF THE OVERHEAD PART. Location on the machine: - near the ground platform con- trols. 20) Description: DISTRIBUTOR CONTROL FUNCTIONS OVERHEAD PART ON BASKET GOLDLIFT 14.70. Location on the machine: - near the overhead part controls on the basket.
  • Page 19 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 21) Description: OVERHEAD PART GROUND CONTROL SWITCH FROM BASKET. Location on the machine: - near the overhead part ground control switch from basket . 22) Description: HAND PUMP SWITCH. Location on the machine: - near hand pump switch.
  • Page 20 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 26) Description: RESPECT THE GREASING INTERVARS OF THE INDICATED PARTS (see page 67-78). Position on the machine: - on the thermic engine protection in correspondence with the grease cup of the slew ring. 27) Description:...
  • Page 21 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 30) Description: IT IS FORBIDDEN TO LIFT THE MACHINE FROM THIS POSITION Location on the machine: - fastening points area. 31) Description: Position of the emergency controls from the ground Location on the machine: - Near the hand pump.
  • Page 22 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA...
  • Page 23 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA...

  • Page 24: Noise And Vibrations

    HINOWA 2.3.3 NOISE AND VIBRATIONS HINOWA platforms both in GOLDLIFT 14.70 versions with thermic engine have been field- tested according to the parameters of the European Regulations 2000/14 CE and have regi- stered a guaranteed 97dB (A) acoustic pressure level.
  • Page 25 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA ESCRIPTIONS ICTOGRAMS NEAR THE CONTROL Starter pushbutton Engine starting pushbutton It allows a selected start of the engine by means of selector 4 directly from the control place on the control car. Work selector For GOLD LIFT 14.70, you can select two working...
  • Page 26 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA ESCRIPTIONS ICTOGRAMS NEAR THE CONTROL Load cell pilot light. This red light indicates that the maximum admitted load on the platform control car has been exceeded. On the GOLD LIFT 14.70 the light comes on when: - you exceed 120 kg on the control car and the jib method has been selected with selector 4.

  • Page 27: Basket Hydraulic Controls For Model

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.4.1.2 BASKET HYDRAULIC CONTROLS ESCRIPTION PERATION ICTOGRAM NEAR THE MOVEMENT CONTROL 1 Basket levelling control Lever forward: This lever allows acting on the levelling basket rotating cylinder of the control car to adjust any...
  • Page 28 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA ESCRIPTION PERATION ICTOGRAM NEAR THE MOVEMENT CONTROL 5 Withdrawal control lever lever forward: This lever allows the operator to extract re-entry withdrawal toward the machine. and insert back the arm. lever backward: withdrawal towards...

  • Page 29: Crawler Hydraulic Controls

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.4.1.4 CRAWLER HYDRAULIC CONTROLS The controls for translating and stabilising the machine have been designed to be operated from the basket. This way the operator is protected from any risks caused by contact with the rubber tracks and the stabilisers and they are able to see clearly the levelling indicator for stabilising the control car.
  • Page 30 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA ESCRIPTION PERATION ICTOGRAM NEAR THE MOVEMENT CONTROL 1 Track widening lever lever forward: This lever allows the operator to track widening increase the width of the rubber crawler to increase the stability of lever backward:...
  • Page 31 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA ESCRIPTION PERATION ICTOGRAM NEAR THE MOVEMENT CONTROL 5 Lever controlling right track movement lever forward: moving right track This lever allows the operator to move the forward right track forward or backward. lever backward:...

  • Page 32: Ground Emergency Controls Situated On The Revolving Turret

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.4.1.5 GROUND EMERGENCY CONTROLS SITUATED ON THE REVOLVING TURRET These controls have been designed to manoeuvre the overhead part of the control car from the ground only in case of emergency after putting on the proper switch.
  • Page 33 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA ESCRIPTION PERATION ICTOGRAM NEAR THE MOVEMENT CONTROL 3 Lever controlling third arm movement lever forward: raising third arm This lever allows the operator to raise or lower the platform third arm. lever backward: lowering third arm...

  • Page 34: Safety Devices

    If a safety device does not work, either due to a breakdown or tampering, this could cause serious damage to the machine and could jeopardise the operator’s life. HINOWA S.p.A. has designed the machine and the safety devices to guarantee the maximum to its customers.

  • Page 35: Battery Cutout

    All the distributors on the platform are equipped with an overpressure valve that limits the pressure reached inside the system to the calibration pressure of the valve itself. These valves are calibrated inside HINOWA by qualified people, when testing the platform and they must never be tampered with.

  • Page 36: Cylinder Stop Valves

    Qualified people calibrate these valves when testing the platform inside HINOWA S.p.A and they must never be tampered with.

  • Page 37: Enabling Device Of The Frame Overhead Part

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.5.5 ENABLING DEVICE OF THE STRUCTURE OVERHEAD PART When all the stabilisers are properly placed on the ground, the stabiliser cylinder goes towards the end of course releasing the micro-switches situated at the end of the rods. The micro-switches send a signal to a solenoid valve that sends oil coming from the carry-over device to the controls for the movement of the overhead part of the structure.

  • Page 38: Control Guards

    • Another alarm is triggered off, obstucting any aerial movement, in case, for any reason, the basket is lifted by the loading sensor. HINOWA S.p.A recommends the maximum care in the proper keep of the entire safety com- ponents and in particular the system of the load sensor on the control car. Always check its proper working if the basket should hit objects when doing jobs as this could cause problems to the system (e.g.

  • Page 39: Locking Pin Screws And Nuts

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.5.9 LOCKING PIN SCREWS AND NUTS All the pins used in the GOLD LIFT platform have been treated against wear and are provi- ded with welded flanges (1) to prevent them from rotating inside their seat.

  • Page 40: Emergency Stop Pushbutton

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.6.1 EMERGENCY STOP PUSHBUTTON It allows the complete stop of any function of the machine in case of emergency. There are two devices on the machine for emergency stop. The first one is situated on the platform crawler near the controls just above the fifth wheel (1), the second one is situated on the basket and is directly fixed on the electric control panel of the control car (2).

  • Page 41: Hand Pump

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA To avoid this danger there is a lever locking system by means of a padlock. You are remin- ded that the ground staff must always have a padlock key to intervene when needed. 2.6.3 HAND PUMP The hand pump (2) serves to send the oil under pressure to do the manoeuvres in case of emergency due to breakdowns of the main hydraulic system.

  • Page 42: Solenoid Valves For Emergency Descent

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA To control the overhead part of the structure without electric current, always remove the nip- ple (3) of the electric valve (4 ) (the outer lead seal automatically breaks by unscrewing and taking off the cap) and arm it manually pushing and turning the knob (5) underneath, il the inner lead-covered cable automatically breaks by reinforcing the electrovalve.

  • Page 43: Safety Regulations To Observe Before Using The Platform

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.7 SAFETY REGULATIONS TO OBSERVE BEFORE USING THE PLATFORM 2.7.1 DANGER OF ELECTRIC FULMINATION If the operator uses the machine near electrical lines, they must keep a clear distance. In the chart below are the relative values for keeping a minimum distance from the electrical lines according to their voltage.

  • Page 44: Danger Due To Bad Weather Conditions

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.7.2 DANGER DUE TO BAD WEATHER CONDITIONS NEVER OPERATE IN BAD WEATHER Never operate when there are storms, snow, fog and wind exceeding 12m/s. Never start the machine when the ambient temperature is below –20°C and over +40°C.

  • Page 45: Procedures For A Proper Use

    HINOWA 2.8 PROCEDURES FOR A PROPER USE You will find below the using procedures of HINOWA platforms. Any use different from what is specified here, unless previously authorised by HINOWA, is absolutely forbidden. 2.8.1 OPERATOR’S RECAPITULATORY TABLE OF SAFETY REGULATIONS You will find below the recapitulatory table with the general safety regulations that the ope- rator must follow carefully before starting operating the platform.

  • Page 46: Gold Lift 14.70 Working Area

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA • Always manoeuvre the controls slowly and regularly without inverting sharply the movements. 2.8.2 GOLD LIFT 14.70 WORKING AREA 120kg MAX. LOAD (1 x80kg person + 40kg 200kg MAX. LOAD tool box) (2x80kg people + 40kg...

  • Page 47: Use Of The Overhead Platform

    IMPORTANT HINOWA overhead platforms are suitable for doing overhead jobs operating from inside the control car. The platform must only be used by trained staff who knows the place and the function of all the controls, tools, indicators, pilot lights and the meaning of the stickers and indications on the machine.

  • Page 48: Preliminary Checks Before Starting Operating

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA Before starting operating at low temperature, turn on the engine for a few minutes to cir- culate the hydraulic oil so that it reaches at least 5°C. Before doing any manoeuvre and when climbing onto the control car, fasten immedia- tely the seat belts to their fixing points.

  • Page 49: Start Of The Petrol/Diesel (Optional) Engine

    Then act on the green push- button on the control electric panel in the control car (part 2 in Hinowa fig.3). To control the starter, press the yellow pushbutton on the control electric panel on the control car (re: part 1 in Hinowa fig.3).

  • Page 50: Start Of The Electric Engine

    Before starting the engine, make sure that the selector on the control electric panel on the control car (re: part.4 in Hinowa fig.3) is positioned on the electric engine. Act on the green pushbutton on the control electric panel on the control car (re: part.2 in Hinowa fig.3).
  • Page 51 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA The travel function can be controlled from the ground position only when the machine has to pass pass through reduced-height or narrow spaces. In these cases, to allow the machine to access these spaces, the two-place cage must be removed.

  • Page 52: Parking Of The Machine On A Solpe Or Disconnected Ground

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.9.4.1 PARKING OF THE MACHINE ON A SOLPE OR DISCONNECTED GROUND When parking the machine on a slope or disconnected ground with the stabilizers closed make sure to stall the corners with wedges in order to avoid unintentional movements of the machine.

  • Page 53: Moving The Control Car

    An improper stabilisation of the machine does not allow a proper working stability. HINOWA forbids the use of the machine if not stabilised as prescribed in this manual. The turning over of the machine can cause serious injuries or death to its occupants and ground staff.
  • Page 54 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA IMPORTANT Never rotate the platform with the control car completely lowered; to avoid hitting the stabi- lisers with lower part of the basket, it is necessary and mandatory to lift it of about 1 metre.

  • Page 55: Manual Levelling Of The Control Car

    HINOWA 2.9.7 MANUAL LEVELLING OF THE CONTROL CAR HINOWA platforms are equipped with an automatic levelling device of the control car; this device has been designed so that the basket floor remains always parallel to the ground inde- pendently from the arm movements of the platforms.

  • Page 56: Manoeuvring The Basket Emergency Descent

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.9.8 MANOEUVRING THE BASKET EMERGENCY DESCENT The machine has been planned considering any possible emergency situations such as mechanical breakdowns, electric breakdowns, the operator’s sudden illness etc.). In these cases it is possible to intervene on the machine both from the basket and the ground place in order to bring back the machine to transport configuration or anyhow to bring assistance to the occupant(s) of the control car.

  • Page 57: Activating The Ground Emergency Descent With The Machine In Perfect Working Order

    SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.9.8.2 ACTIVATING THE GROUND EMERGENCY DESCENT WITH THE MACHINE IN PERFECT WORKING ORDER This emergency descent is only allowed in case of: the control car operator is taken ill. IMPORTANT The only aim for using the ground emergency descent is to bring assistance to the operator (s) on board of the control car and to bring the control car near the ground.
  • Page 58 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA To carry out the emergency descent in the above- mentioned conditions operate as follow: Case 1: voltage on rotating the ignition key to ON and with the emergency stop pushbutton deactiva- ted: Position the switch on the hand pump in the position matching the arms movement;...
  • Page 59 2.9.9.2 CLOSED PREMISES To operate in closed premises, HINOWA recommends to opt as much as possible for the electric engine; If it is not possible make sure there is a sufficient change of air to avoid accu- mulating gases harmful to people’s health.
  • Page 60 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA objects. Remember that no safety device can help you when you are in the air with the over- loaded basket, as its emergency descent does not guarantee against turning over. The only way to be safe is to go back as soon as possible within the admitted load limits for the basket according to the working configuration by unloading the basket.
  • Page 61 Highway Code. 2.11.1 LOADING AND UNLOADING ON RAMPS The HINOWA platform has a very high manoeuvrability and stability even when translating. However we recommend the user to operate carefully even during operations apparently simple.
  • Page 62 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA IMPORTANT During the translating and the changing of slant phases, take care not to damage the safety devices situated below the basket and near the first withdraw end. If the change of slant was to be too excessive, change the inclination of the ramps or use longer ramps.
  • Page 63 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.11.2.1 HOW AND WHERE TO HOOK THE PLATFORM To lift the platform, hook it to each support pin of the stabiliser cap as indicated on the pho- tograph below. DANGER Always hook all four feet as the machine could become unbalanced. Always use four separa- te cables, chains or slings;...
  • Page 64 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 2.11.3 TRANSPORT OF THE MACHINE Once loaded on the trailer, fix the machine with tie-rods as shown on the photo below. Check that the dimensions of the machine and the trailer match the prescriptions of the Highway Code.
  • Page 65 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 3.2 LUBRICATING POINTS Recommended oils and lubricants chart. TRACTION HYDRAULIC ENGINE OIL REDUCTION MAKE GREASE -15° +40° UNIT ESSO NUTO H 46 TD 15 W 40 EP 150 BEACON2 CALTEX SIRIUS H 46 WRP150...
  • Page 66 Control the support and the correct distance slipping off and closing the arm. • The possible replacement of the sliding shoes has to be made in an Hinowa authorized workshop 4. MAINTENANCE OF THE MACHINE 4.1 SAFETY REGULATIONS FOR MAINTENANCE OPERATIONS...
  • Page 67 4.2 PERIODIC GENERAL CONTROL After the first 2000 hours, it becomes necessary a general control of the machine, at a certifi- cated centre of Hinowa, which examines the state of the machine and fills in a form furni- shed by Hinowa.
  • Page 68 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 4.2.1 PERIODICAL MAINTENANCE TIMES ONDA PETROL ENGINE INTERVAL (HOURS) BEFORE INTERVEN- SECOND DETAIL STAR- PAGE TION NEED 500 1000 2000 TING. CLEANING • CONTROL AIR FILTER • REPLACEMENT LEVEL CON- • • TROL ENGINE OIL •*...
  • Page 69 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA PERKINS DIESEL ENGINE INTERVAL (HOURS) BEFORE INTERVEN- SECOND DETAIL STAR- PAGE TION NEED 500 1000 2000 TING. CLEANING • FLAT AIR FIL- CONTROL • REPLACEMENT LEVEL CON- • • TROL ENGINE OIL •* •...
  • Page 70 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 4.3 RUBBER TRACK MAINTENANCE 4.3.1 CHECKING TRACK TENSION Park the machine on a solid and flat surface. Lift machine safety and put stable blocks under the crawler frame to support it. Measure distance A from the roller bottom to the rubber track rigid inner part.
  • Page 71 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA PERICOLO DANGER DANGER There is something wrong if the track remains stretched once valve 1 has been turned anti- clockwise or loose after putting grease in grease nipple 2. In any case, never try to remove tracks or dismantle the track tension cylinder, as the high pressure of the grease inside the track is very dangerous.
  • Page 72 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA the track from coming out of the guide rollers. Causes of damages A) Steel ropes breakage An excessive tension causes the breaking of the steel ropes under the following conditions: When there is an excess of stones and foreign material between the track and the crawler frame;...
  • Page 73 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA soil, or repeated sharp changes of direction. 4. The abrasion of the engraved thread can originate especially in case of rotations on con- crete surfaces, gravel or hard surfaces. The conditions for damage indicated in paragraph D point 1, 2, 3 are not to be considered deadly for the track and even if there is a gradual or progressive damage, the track will con- tinue to work.
  • Page 74 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 3. Per allentare il cingolo svitate lentamente la valvola 1 in senso antiorario per non più di un giro. Un giro della valvola 1 è sufficiente per allentare il cingolo. 4. Se il grasso non inizia a drenare, fate lentamente ruotare il cingolo.
  • Page 75 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 6. Make sure the track links are properly meshed onto the sprocket and the track-tensioning sprocket. 7. Adjust track tension (see paragraph 4.3.2 -“Opera- tions to loosen/stretch track”). 8. Place rubber crawler on the ground.
  • Page 76 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 4.5 CHECKING HYDRAULIC OIL LEVEL The check is done when the platform (PLE) and the stabilisers are at rest on flat ground. Check that the oil level is about half the inspection hole A.
  • Page 77 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA Replace the cartridge at each oil replacement and according to the intervals indicated by the maintenance chart (par.4.2) NOTE: Always do the first replacement of the cartridge after the first 50 working hours, to eliminate working residues of tubes and hydraulic components from the hydraulic system.
  • Page 78 The screwhead and the upper part of the stops that hold the sliding blocks on the arm must never come out of the upper outline of the sliding blocks. The replacement of the sliding blocks must always be done in an authorised Hinowa Spa workshop.
  • Page 79 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 4.13 BATTERY: CHECKS AND MAINTENANCE IMPORTANT Never approach flames or cause sparks near the battery (explosive gas). The battery contains sulphuric acid that is highly explosive. Therefore act with maximum care and protect eyes and face.
  • Page 80 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA Fix back the terminals to the battery poles. Then spread them with pure petroleum jelly or other suitable protections. Close back the battery with cover “A” (fig.1). IMPORTANT The recharging voltage must never exceed 14,7 Volt and the recharging intensity must always be limited to 0,2 of the figure indicated on the cover.
  • Page 81 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 5. TROUBLESHOOTING PROBLEM CAUSE SOLUTION The pump is very noisy • The pump does not suck • Replace pump • Worn pump • The pump sucks air • Check oil level in the relative...
  • Page 82 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA PROBLEM CAUSE SOLUTION After finishing work, it is • The overhead part has not • Repeat the procedure of put- impossible to destabilise the been put completely at rest or ting the overhead part at rest...
  • Page 83 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 7. HYDRAULIC SYSTEM 7.1 GOLDLIFT 14.70 HYDRAULIC SYSTEM...
  • Page 84 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 7.2 KEY DIAGRAM GOLDLIFT 14.70 HYDRAULIC SYSTEM Hand pump 2.2 W, 4 IP55 poles, electric engine GX270 QME2 petrol engine 1B30 Diesel engine Double geared pump Pump inlet manifold block 6 way switch Exhaust filter...
  • Page 85 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 7.3 GOLDLIFT 14.70 HYDRAULIC SYSTEM WITH SPEED...
  • Page 86 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA 7.4 KEY DIAGRAM GOLDLIFT 14.70 HYDRAULIC SYSTEM WITH SPEED Hand pump 2.2 W, 4 IP55 poles, electric engine GX270 QME2 petrol engine 1B30 Diesel engine Double geared pump Pump inlet manifold block 6 way switch...
  • Page 87 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA ELECTRIC SYSTEM ELECTRIC DIAGRAM GOLDLIFT/500 (Valid from serial number G23) DESCRIPTION REFERENCE • How to read the electric wiring diagrams • Photocells and ground part electro valve • Outriggers lights • Aerial part safety chain - Outriggers •...
  • Page 88 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA • The control board manages all the machine safety functions and is always shown with a dashed perimeter. To make the system easier to understand, the wiring diagram is also shown inside the control board boxes.
  • Page 89 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA...
  • Page 90 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA...
  • Page 91 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA...
  • Page 92 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA...
  • Page 93 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA...
  • Page 94 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA...
  • Page 95 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA...
  • Page 96 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA...
  • Page 97 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA...
  • Page 98 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA...
  • Page 99 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA...
  • Page 100 SELF-PROPELLED TRACKED PLATFORM GOLDLIFT 14.70 HINOWA...
  • Page 101 Legal and administrative seat: HINOWA S.p.A. I - 37054 NOGARA (VR) via Fontana Tel. +39 0442 539100 Fax +39 0442 539075 hinowa@hinowa.it - marketing: info@hinowa.com www.hinowa.com...
