Main specifications
Overall assembled size : W4.88 x L7.5x H3.05 (m) / 16 x 24 x 10
(ft)
Front door : W3.6 x H2.0 (m) / 11.8 x 6.56 (ft)
Side door: W0.9 x H2.0 (m) / 2.95 x 5.56 (ft)
Prior to assembly
Please read the instructions carefully before installation. It is very
important to follow your local safety regulations and industry
standards during installation. Regulations may include but are not
limited to:
Safety helmets, protective eyewear, and clothing
-
Safety harnesses for all elevated workers
-
Proper ladder, cage, and safety operation
-
Check all components and parts before installation. All parts are marked with
a part number, please refer to the parts list to make sure you have all parts.
Choose a day with low or no wind to install, assembly is hard in heavy wind.
Do not make any alterations to the structure. Do not hang any weights on the
frame during installation, including parts. We are not responsible for any
www.tmgindustrial.com
►
P0 / 19
Toll Free:1-877-761-2819
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for TMG TMG-LPG21
Summary of Contents for TMG TMG-LPG21
- Page 1 Main specifications Overall assembled size : W4.88 x L7.5x H3.05 (m) / 16 x 24 x 10 (ft) Front door : W3.6 x H2.0 (m) / 11.8 x 6.56 (ft) Side door: W0.9 x H2.0 (m) / 2.95 x 5.56 (ft) Prior to assembly Please read the instructions carefully before installation.
- Page 2 Main Specifications: Assembly size : W2.95 x L5.79 x H2.5 (m) / 10ft x 20ft x 8ft Wind proof roller shutter : W2.73 x H2.325 (m) fabric density : 5％ Prior to assembly Please go through the whole instruction manual completely. It is very important to follow your local safety regulations and industry standards during installation.
- Page 3 TMG-LPG21 Part List Parts Graphical Description Length code Post 110X110mm Base cover 190X190mm Base footing plate 170X170mm Base footing screw 4X35mm Expansion bolt M8X7mm Post cover 110X110mm Post cover screw 4X16mm Small cover 18X18X2 Beam 80X140mm B1-B4 Rubber plug Sliding pin...
- Page 4 Rear breakwater screw 4*16mm Hexagon spanner Pergola remote control Small rubber hammer 26*6*2mm Cross head 65mm Auger 3.4mm 5M Power line Silicon sealant 120ml Residual circuit 125w breaker Beam connection 105*35*2mm Aluminium tube 80*30*1mm Orbital left seal 49*38mm Left side orbital 49*38mm*2219mm P1-1 Left side rubber tape...
- Page 5 Left side orbital cover 49*38*2219mm P1-3 Screw for side orbital 5*8mm cover Screw for Side orbital 4.2*38mm Orbital right seal 49*38mm Right side orbital 49*38mm*2219mm P2-1 Right side rubber tape 32*2219mm P2-2 Right side orbital 49*38*2219mm P2-3 cover Front cover 100*100*2720mm Rear cover 100*100*2720mm...
- Page 6 Step 1:Install base footing plate and beam Lay the post A1 flat, install base cover A2 and base footing plate A3 on all post A1, and drilling base footing screw A4. The step applies to the two post on the right ...
- Page 7 Step 2: Install Beam B2、B2-1 Connect the electric wire of Beam B3 & B2，B2 & B2-1. Connect the Beam B2 and B2-1 with Beam connection B10. Align with four holes and install them on middle Post A1 with fixed drills. ...
- Page 8 Step 3:Install B4、B4-1 The main power line passes under Post A1 and connects the power lines of B3 & B4, B4 & B4-1, B4-1 & B1. Connect the Beam B4 and B4-1 with Beam connection B10. Align with four holes and install them on middle Post A1 with fixed drills.
- Page 9 Step 4: Install Aluminium tube A9 Install Aluminum tube A9 on the two middle Post A1 Parts Graphical code ► www.tmgindustrial.com P8 / 19 Toll Free:1-877-761-2819...
- Page 10 Step 5: Install Base footing plate A3 Measuring base distance，make the parallel distances and the diagonal distances equal. Secure the base footing plate A3 with expansion bolt A5. Parts Graphical code Step 6: Install Blades C1-C43 Install the blades C1--C43 in sequence, and drill the sliding pin screw B7 into sliding pin B6 to fix it.
- Page 11 All screw hole plugs with small rubber plug B5. Parts Graphical code C1-C21 ► www.tmgindustrial.com P10 / 19 Toll Free:1-877-761-2819...
- Page 12 Step 7:Install Front breakwater F1 and Rear breakwater G1 Parts Graphical code ► www.tmgindustrial.com P11 / 19 Toll Free:1-877-761-2819...
- Page 13 Step 8: Install Post cover A6 Parts Graphical code www.tmgindustrial.com P12 / 19 Toll Free:1-877-761-2819 ►...
- Page 14 Step 9: Separate Front cover Q1 Remove the screws and open the Front cover Q1 2.Unscrew the two ends of Rolling fabric and motor Q3 and take Rolling fabric and motor Q3 out. Parts Graphical code www.tmgindustrial.com P13 / 19 Toll Free:1-877-761-2819 ►...
- Page 15 Step10: Install Rear cover Q2 Install Rear cover Q2 and screw the screw on the Beam. (PS: please pay attention to installation direction, please make sure the protruding side of the iron is on the outside） Parts Graphical code ►...
- Page 16 Step 11:Install Left & Right side orbital P1-1 & P2-1. Left & Right side orbital P1-1 & P2-1 are mounted on protruding iron blocks on both sides of the Rear cover Q2. Left & Right side orbital P1-1 & P2-1 screw 3pcs Screw for side orbital P4 in Post A1. Parts Graphical code...
- Page 17 Step 12: Install Orbital Left & Right seal P1 & P2 and Left & Right side rubber tape P1-2 & P2-2. Install Orbital Left & Right seal with Screw for side orbital P4. Install Left & Right side rubber tape P1-2 & P2-2 on Left & Right side Orbital P1-1 & P2-1.
- Page 18 Step 13: Install Rolling fabric and motor Q3. Install Rolling fabric and motor Q3， The fabric faces inward; Clip the fabric into Left & Right side rubber tape P1-2 & P2-2. Screw left and right sides of Rolling fabric and motor Q3. Parts Graphical code...
- Page 19 Step 14:Install Left & Right side orbital cover P1-3 & P2-3 and Front cover Q1. Install the Left & Right side orbital cover P1-3 & P2-3 , tap it with a small plastic hammer J; Secure with Screw for side orbital cover P3. ...
- Page 20 Step 15:Connect electric wire. www.tmgindustrial.com P19 / 19 Toll Free:1-877-761-2819 ►...
