Main specifications
Overall assembled size : W4.88 x L7.5x H3.05 (m) / 16 x 24 x 10
(ft)
Front door : W3.6 x H2.0 (m) / 11.8 x 6.56 (ft)
Side door: W0.9 x H2.0 (m) / 2.95 x 5.56 (ft)
Prior to assembly
Please read the instructions carefully before installation. It is very
important to follow your local safety regulations and industry
standards during installation. Regulations may include but are not
limited to:
Safety helmets, protective eyewear, and clothing
-
Safety harnesses for all elevated workers
-
Proper ladder, cage, and safety operation
-
Check all components and parts before installation. All parts are marked with
a part number, please refer to the parts list to make sure you have all parts.
Choose a day with low or no wind to install, assembly is hard in heavy wind.
Do not make any alterations to the structure. Do not hang any weights on the
frame during installation, including parts. We are not responsible for any
www.tmgindustrial.com
►
P0 / 9
Toll Free:1-877-761-2819
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for TMG TMG-LPG10
Summary of Contents for TMG TMG-LPG10
- Page 1 Main specifications Overall assembled size : W4.88 x L7.5x H3.05 (m) / 16 x 24 x 10 (ft) Front door : W3.6 x H2.0 (m) / 11.8 x 6.56 (ft) Side door: W0.9 x H2.0 (m) / 2.95 x 5.56 (ft) Prior to assembly Please read the instructions carefully before installation.
- Page 2 Main Specifications: Assembly size : W2.95 x L2.95 x H2.5 (m) / 10ft x 10ft x 8ft Prior to assembly Please go through the whole instruction manual completely. It is very important to follow your local safety regulations and industry standards during installation. Regulations may include but are not limited to: Safety helmets, protective eyewear, and clothing Safety harnesses for all elevated workers...
- Page 3 TMG-LPG10 Part List Parts Graphical Description Length code Post 110X110mm Base cover 190X190mm Base footing plate 170X170mm Base footing screw 4X35mm Expansion bolt M8X7mm Post cover 110X110mm Post cover screw 4X16mm Small cover 18X18X2 Beam B1 80X140mm Beam B2 80X140mm...
- Page 4 R-shape pin 1.8*35mm Front breakwater 65*15mm Front breakwater screw 4*16mm Rear breakwater 125*26mm Rear breakwater screw 4*16mm Hexagon spanner Pergola remote control Small rubber hammer 26*6*2mm Phillips bit 65mm Drill Bit 3.4mm Silicon sealant 120ml Hand crank 1600mm www.tmgindustrial.com P3 / 9 Toll Free:1-877-761-2819 ►...
- Page 5 Step 1:Install Base footing plate and Beam Lay the post A1 flat, install base cover A2 and base footing plate A3 on all post A1, and drilling base footing screw A4. The step applies to the two post on the right ...
- Page 6 Step 2: Install Beam B2&B4. Install Beam B2\B4 on the Post A1,as shown. www.tmgindustrial.com P5 / 9 Toll Free:1-877-761-2819 ►...
- Page 7 Step 3: Install Base footing plate A3. Measuring base distance，make the parallel distances and the diagonal distances equal. Secure the base footing plate A3 with expansion bolt A5. Parts Graphical code Step 5: Install Blades C1-C21. Install the blades C1--C21 in sequence, and drill the sliding pin screw B7 into sliding pin B6 to fix it.
- Page 8 All screw hole plugs with small rubber plug B5. Parts Graphical code C1-C21 ► www.tmgindustrial.com P7 / 9 Toll Free:1-877-761-2819...
- Page 9 Step 6:Install Front breakwater F1 and Rear breakwater G1 Parts Graphical code ► www.tmgindustrial.com P8 / 9 Toll Free:1-877-761-2819...
- Page 10 Step 7: Install post cover A6 Parts Graphical code www.tmgindustrial.com P9 / 9 Toll Free:1-877-761-2819 ►...
