Great Plains
12, 15 and 20 Series 3-Point Drills
PRE-DELIVERY MANUAL
MODELS 1200, 1210, 1220, 1500, 1510, 1520, 2000, 2010, & 2020
Table of Contents
Original Instructions
!
Index
Read the operator manual entirely. When you see
this symbol, the subsequent instructions and
warnings are serious - follow without exception.
Your life and the lives of others depend on it!
Illustrations may show optional equipment not
supplied with standard unit.
118-390M
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GREAT PLAINS 1200
Summary of Contents for GREAT PLAINS 1200
- Page 1 Index Great Plains 12, 15 and 20 Series 3-Point Drills PRE-DELIVERY MANUAL MODELS 1200, 1210, 1220, 1500, 1510, 1520, 2000, 2010, & 2020 118-390M Original Instructions Read the operator manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception.
- Page 2 Machine Identification Record your machine details in the log below. If you replace this manual, be sure to transfer this information to the new manual. If you or the dealer have added options not originally ordered with the machine, or removed options that were originally ordered, the weights and measurements are no longer accurate for your machine.
- Page 3 Printed 01/30/2024 | English Great Plains reserves the right to revise and improve its products at any time. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future. The content of this publication may be...
- Page 4 Trademarks of Great Plains Manufacturing, Inc. include: AccuShot, DrillCommand, Max-Chisel, Row-Pro, Singulator Plus, Short Disk, Swath Command, Terra-Tine, Ultra-Chisel, and X-Press. Registered trademarks of Great Plains Manufacturing, Inc. include: Air-Pro, Clear-Shot, Discovator, Great Plains, Land Pride, MeterCone, Nutri-Pro, Seed-Lok, Solid Stand, Terra-Guard, Turbo-Chisel, Turbo-Chopper, Turbo-Max, Turbo-Trill, Ultra-Till, Whirlfilter, and Yield-Pro.
-
Page 5: Table Of Contents
Hitch Requirements ..... . 10 Models 1200, 1500 and 2000... . 10 Models 1210, 1220, 1510, 1520 and 2010. - Page 6 12, 15 and 20 Series 3-Point DrillTable of Contents Index Great Plains | 118-390M | 01/30/2024...
-
Page 7: Introduction
Introduction Introduction Great Plains Manufacturing wants you to be satisfied with any new machine delivered by the Great Plains Trucking network. To ease the assembly task and produce a properly working machine, read this entire manual before assembling or setting up new equipment. -
Page 8: Safety Information
Non-Great Plains components on this machine may contain additional safety information not found in this The notice symbol indicates a potential for machine manual. -
Page 9: Machine Use
Avoid contacting overhead obstructions such as low bridges, overpasses, and power lines. Do not operate near ditches, holes, steep slopes, embankments, or other surfaces which may collapse under the machine’s weight or tip the machine over. Great Plains | 118-390M | 01/30/2024... -
Page 10: Machine Maintenance
Detach the tractor. Secure the implement using blocks. Stay clear of and never step over any rotating parts. Great Plains | 118-390M | 01/30/2024... -
Page 11: Assembly
8. Check for proper tension and alignment on all drive chains. 9. Check that all safety labels and reflectors are correctly located legible. Replace improperly located or damaged. Refer to Safety Great Plains | 118-390M | 01/30/2024... -
Page 12: Unloading
5. Slowly pull the trailer straight out from under the drill. 6. Making sure to keep the drill level front-to-back and side-to-side, slowly lower the drill to the ground 12 inches off the ground. Great Plains | 118-390M | 01/30/2024... -
Page 13: Position Gauge Wheels
12-Foot with Single Gauge Wheels 5 3/4 inches To reposition the arm, use mechanical assistance to lift and support the arm. Remove the two u-bolts, lift Great Plains | 118-390M | 01/30/2024... -
Page 14: Install Drive System
(3) up or Hitch, the extended wing (2) must be mounted to the down until the height matches the shaft. inside of the drill. Order Great Plains part number If the shaft is too far forward or back to enter bearing 120-210H to complete installation. - Page 15 (6). 5. For 20 Series drills, install the right-hand drive by repeating steps 1 through 7. 6. Rotate each gauge-wheel tire several turns while observing the entire drive system. If any chain Great Plains | 118-390M | 01/30/2024...
-
Page 16: Setup
Center Pivot and 4. Repeat steps for other lower link. All Seeds Hitches. If the drill will not be used with a Great Plains hitch, remove the extensions and install the standard pin supports. Pin supports are stored inside the drill box. -
Page 17: Hitching The Tractor To Drill
12151 Parking Stand 5. Adjust the top 3-point link so the top edge of the box is parallel with the ground when drilling. 6. Set your tractor 3-point draft control in the float position. Great Plains | 118-390M | 01/30/2024... -
Page 18: Appendix
9.5L x 15" 6-Ply Rib Implement 12.5L x 15" 10-Ply Rib Implement 9.5L x 15" 8-Ply Rib Implement 16.5L x 16.1" 10-Ply Rib Implement 9.5L x 15" 12-Ply Rib Implement 21.5 x 16.1” SC 10-Ply Rib Implement Great Plains | 118-390M | 01/30/2024... -
Page 19: Warranty
Great Plains reserves the right to make changes in materials or design of the product at any time without notice. This warranty is not valid unless the unit is registered with Great Plains within 10 days from the date of the original purchase. - Page 21 Table of Contents Index...
