GREAT PLAINS 1200-4800TM Quick Start Manual

Great Plains Manufacturing, Inc.
1200-4800TM Hydraulic Leveling Kit
General Information
These Instructions explain how to install the hydraulic
leveling kit update. This update only applies to the 1200-
4800 Turbo Max. These instructions apply to kit number:
589-532L, HYDRAULIC LEVELING KIT.
Manual Update
Refer to the Turbo Max operator's manual for detailed
safety and maintaining of machine and to parts manual
for part identification.
589-532L Hydraulic Remote Tmax
Leveling Kit S/N GP-C6545+
Part Number
589-533V HOSE KIT LEVEL - TMAX
FITTINGS KIT - LEVEL -
589-534V
TMAX
MANUAL TMAX HYD
586-541M
REMOTE LEVEL
589-249D
589-222D LEVEL GUAGE BRACKET
589-487H LEVEL INDICATOR
CABLE TIE.19X7.25 1.75D
800-112C
802-152C HHCS 1/4-20X2 GR5
802-333C HHCS 5/16-18X3 1/2 GR5
802-474C HHCS 5/16-18X4 1/2 GR5
803-006C NUT-HEX 1/4-20 PLT
803-008C NUT HEX 5/16-18 PLT
WASHER LOCK SPRING 1/4
804-006C
WASHER LOCK SPRING 5/16
804-009C
810-599C
CYL 4X3X1.50 ROD (TIE
810-626C
HYDRAULIC HOSE HOLDER
816-885C
858-059C TM LEVEL DECAL
08/15/2019
Description
VALVE BRACKET
50LB
PLT
PLT
LOCK VALVE
ROD
3/8"
Tools Required
• Basic Hand Tools
• Torque Wrench
Hydraulic Remote Leveling
Refer to Figure 1
Qty.
1
1
1
1
1
1
2
3
1
2
3
2
3
3
1
Null4:
1
1
Figure 1
Hydraulic Remote Leveling
1
TP-69450
586-541M
