Viking RC-2A Technical Practice

Technical Practice
Control Relay Contacts Remotely
C.O. lines or analog PABX/KSU station ports and allow remote relay operation after the
second or fifteenth ring. A field programmable access code can also be programmed
to prevent unauthorized usage.

Features

• Programmable access code
• Selectable relay time delays
• Selectable ring delay (2 or 15)
• Easy installation with modular jacks and screw
terminals
• Normally open or normally closed relay
• One year warranty
Made in the U.S.A.
Sales...(715) 386 - 8861
Telecommunication Peripheral Products
http://www.VikingElectronics.com
E-mail...Sales@VikingElectronics.com
The RC-2A Remote Controller provides
remote relay operation from any
standard Touch Tone telephone.
The controller is designed to be installed
either locally or remotely.
Installations the RC-2A can be installed
in series on any communications path,
such as Viking's W-Series Doorboxes.
For off-premise applications, the RC-2A
can be installed on a line shared by a key
system, PABX, single line phone or on a
dedicated line. The RC-2A will answer
theu

Applications

Remote Control of:
• High security building entry
• Heating/cooling equipment
• Pumps and fans
• Security systems
• Gates
• Lighting
• PABX/KSU reset

Specifications

Power: 120VAC / 12VDC 500mA UL listed adapter provided
Dimensions: 133mm x 89mm x 44mm (5.25" x 3.5" x 1.75")
Shipping Weight: .9 k (2 lbs)
Environmental: 0° C to 32° C (32° F to 90° F) with 5% to 95%
non-condensing humidity
Connections: (2) RJ-11 jacks and 2 pin screw terminal block
Relay Contact Ratings: .5A @ 125V AC/1A @ 30V DC
RC-2A
Remote Touch
Tone Controller
June 6, 2000
For local
