52 ½"
Thank you for choosing Grain Wood Furniture, it is an honor to be in your home!
If you have any questions, feedback, or need replacement parts please contact us at:
grainwoodfurniture.com/help or
Montauk Collection
5-Drawer Chest
REV - 09/2021
Assembly Instructions
32 ½"
support@grainwoodfurniture.com
18"
Made in Brazil
2-person assembly
Model #
Finish
RMT0711
Rustic Walnut
RMT0712
Rustic Off-White
RMT0720
Rustic Grey
RMT0724
Driftwood
PH #2
page 1/17
Advertisement
Related Manuals for GrainWood Montauk RMT0711
Summary of Contents for GrainWood Montauk RMT0711
- Page 1 Assembly Instructions 32 ½" 18" 2-person assembly 52 ½" PH #2 Model # Finish RMT0711 Rustic Walnut RMT0712 Rustic Off-White RMT0720 Rustic Grey RMT0724 Driftwood Thank you for choosing Grain Wood Furniture, it is an honor to be in your home! If you have any questions, feedback, or need replacement parts please contact us at: grainwoodfurniture.com/help or support@grainwoodfurniture.com...
- Page 2 PLEASE READ BELOW BEFORE BEGINNING ASSEMBLY Enlist help from a friend or family member as most items require two Ÿ people for proper assembly. Choose a spacious, open area near where the piece will be located once Ÿ assembled. It is easier to move parts than to relocate the furniture after it is fully assembled.
- Page 3 HARDWARE LIST 56 + 2 FURNITURE ANTI-TIPPING RESTRAINT KIT 4,0x30 2 + 1 26 + 2 3,0x20 3,5x16 20 + 2 M4x22 15x30 4,0x45 40 + 2 6,0x10 72 + 2 8,0x30 ATTENTION Before starting assembly please verify the hardware set is complete.
- Page 4 BOX 1 BOX 2 Qty. Qty. Description Description Part # Part # Right side Cleat Left side Middle crosspiece Drawer right side Rear crosspiece Drawer left side Upper/ lower crosspiece Profile “H” Drawer front Back panel Drawer bottom Hardware Drawer back Drawer bottom support page 4/17...
- Page 5 Tip: Use a hammer in case dowels are hard to install by hand. 3,5x16 8,0x30 page 5/17...
- Page 6 Glide wheels should be positioned towards the front and bottom of the side panel. Need help? Scan the QR code. 6,0x10 RIGHT Side page 6/17...
- Page 7 Glide wheels should be positioned towards the front and bottom of the side panel. Need help? Scan the QR code. 6,0x10 LEFT Side page 7/17...
- Page 8 4,0x45 Attention: There are no predrilled holes for the A1 screws on part Attention: There are no predrilled holes for the A1 screws on part 4,0x30 page 8/17...
- Page 9 4,0x30 Attention: There are no predrilled holes for the A1 screws on part 03. Attention: There are no predrilled holes for the A1 screws on part 4,0x30 page 9/17...
- Page 10 A40 A40 Attention: There are no predrilled holes for the A40 and A42 screws 3,5x16 4,0x45 Make sure back panels are perfectly aligned with side panels and top and there are NO gaps. û ü ü 10x10 page 10/17...
- Page 11 Make sure back panels are perfectly aligned with side panels and top and there are NO gaps. û ü 10x10 page 11/17...
- Page 12 10x10 A5 A5 3,5x16 page 12/17...
- Page 13 3,5x16 page 13/17...
- Page 14 Attention: There are no predrilled holes for the A1 screws on part 08. 1" 4,0x30 page 14/17...
- Page 15 Flip the assembled drawer upside down to install glides. Need help? Scan the QR code. Drawer RIGHT Drawer LEFT 6,0x10 page 15/17...
- Page 16 M4x22 Place the labeled drawer on the top position page 16/17...
- Page 17 FURNITURE ANTI-TIPPING RESTRAINT KIT Install against the furniture Install on the wall Anchors and screws are not included, choose best type based on your wall Install both parts F8 3x20 Tighten them 15x30 together using the safety strap page 17/17...
