INSTALLATION INSTRUCTIONS
STEP 8: SLIDE DISHWASHER PARTIALLY INTO
CABINET
DO NOT PUSH AGAINST FRONT PANEL WITH KNEES.
DAMAGE WILL OCCUR.
• Slide dishwasher into the opening a few inches at a time.
• As you proceed, pull the drain hose through the opening under the
sink. Stop pushing when the dish washer is a few inches forward
of adjacent cabinetry.
• Make sure drain hose is not kinked under the dish washer and
there is no interference with the water line, wiring or any other
component.
STEP 9: POSITION DISHWASHER UNDER
COUNTERTOP
• Make sure that wires are secure under the dishwasher and not
pinched or in contact with door springs or other dishwasher
components.
TIP: Check tub insulation blanket, if equipped. It should be
positioned so it is not bunched up or interfering with door springs.
Check by opening and closing the door.
• Push dishwasher into cabinet. The front corners of the dishwasher
door should be flush with cabinet doors. Be careful not to dent
front panel with knees or damage countertop or cabinets with
dishwasher parts.
STEP 10: LEVEL DISHWASHER
WARNING
Dishwasher must be level for proper dish rack
operation and wash performance.
• Place level on door and rack track inside the tub as shown to
check that the dishwasher is level.
Check Level
Front to Back
• Level the dishwasher by adjusting the four leveling legs
individually.
TIP: Pull the lower rack out about halfway. Make sure that the rack
does not roll forward or back into the dishwasher. If the rack rolls
in either direction, you must level the dishwasher again.
• If the door hits the tub, the dishwasher is not installed correctly.
Adjust leveling legs to align door to tub.
NOTE: The maximum adjustment height of the feet is 1.97"
(50 mm).
7
Check Level
Side to Side
Turn the legs to
adjust the level
