CCG-1500 Series
Quick Installation Guide
Version 1.1, August 2023
Technical Support Contact Information
www.moxa.com/support
 2023 Moxa Inc. All rights reserved.
P/N: 1802015102011
*1802015102011*

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CCG-1500 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Moxa Technologies CCG-1500 Series

  • Page 1 CCG-1500 Series Quick Installation Guide Version 1.1, August 2023 Technical Support Contact Information www.moxa.com/support  2023 Moxa Inc. All rights reserved. P/N: 1802015102011 *1802015102011*...
  • Page 2: Package Checklist

    Overview The CCG-1500 Series is a private 5G gateway that acts as a media and protocol converter. These gateways support 5G-to-Ethernet and 5G-to- Serial connections, suitable for both public and private networks. The CCG-1500 Series can also be used as a protocol converter for Modbus TCP/RTU communications, as well as a wireless platform for 5G communications.
  • Page 3 Top View Bottom View CCG-1520 Models Front View Rear View Top View - 3 -...
  • Page 4: Device Dimensions

    Bottom View Device Dimensions Mounting the CCG-1500 Series The CCG-1500 Series can be mounted onto a DIN rail or a wall. The DIN-rail mounting kit is attached to the device by default. The wall- mounting kit can be purchased separately.
  • Page 5: Wall Mounting (Optional)

    STEP 1: Attach the wall mounting kit plates to the side panel of the CCG-1500 Series device using four M3 x 6 mm screws. STEP 2: Use the CCG-1500 Series device with the wall mount plates attached as a guide to mark the correct location of the four screws. The heads of the screws should be less than 6.0 mm in diameter, the shafts...
  • Page 6 9-24 VDC @ 1.33-0.5 A min., Tma = 70°C (min). If you need assistance purchasing a power source, please contact Moxa for more information. Grounding the CCG-1500 Series Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI) by routing the noise from the metal chassis to the connected ground.
  • Page 7: Interface Description

    RS-232RTS/RS-422R+/RS-485D+ RS-232CTS/RS-422R-/RS-485D- SIM Card Sockets The CCG-1500 Series comes with two nano-SIM card sockets for cellular communication. The nano-SIM card sockets are located on the front panel and are protected by a cover. The left socket is for SIM 1 and the right socket is for SIM 2.
  • Page 8: Cellular Interface

    The CCG-1510 models have six antenna connectors while CCG-1520 models have four antenna connectors. The built-in GPS module of the CCG-1500 Series allows the device to use GPS satellite geolocation. To use the GPS function, the antennas must be connected to the SMA connectors.
  • Page 9: Accessing The Web Console

    Accessing the Web Console You can log into the web console of the CCG-1500 Series gateway by connecting a host computer to LAN1 or LAN2 on the device and navigating to the device’s default IP address in a web browser. Please ensure the host computer and CCG-1500 gateway are in the same subnet.
