CP-118U User's Manual
8-Port RS-232/422/485 Serial Board for Universal PCI Bus
Second Edition, December 2004
www.moxa.com/product
Moxa Technologies Co., Ltd.
Tel:
+886-2-8919-1230
Fax:
+886-2-8919-1231
Web: www.moxa.com
MOXA Technical Support
Worldwide:
The Americas
support@moxa.com.tw
support@moxa.com
