SAFETY CONSIDERATIONS

Understand the signal words DANGER, WARNING, and CAUTION. These words are universally used for overall safety.
DANGER identifi es the most serious hazards which will result in severe personal injury or death. WARNING signifi es hazards
which could result in personal injury or death. CAUTION is used to identify unsafe practices resulting in minor personal injury
or product and property damage.
DANGER
• To prevent serious injury from electrical shock, this product must be installed by a
qualified agency.
• Associated voltage potential inside if air handler wiring compartments has the potential
to cause serious injury or death from electric shock. Some installations may require
electrical connections to high voltage sources.
• Before installing the FCMC, turn off all power to your HVAC system.
• When servicing FCMC system or components attached to FCMC system, turn off all
power to these items.
CAUTIONS
• Read entire manual and follow all instructions carefully.
• Follow all local electrical codes during installation.
• All wiring must conform to local and national electrical codes.
• Use caution when mounting components to surfaces that may have concealed wiring
beneath the surface.
• Do not use the ventilation system for removal of fl ammable fumes or gases.
• Do not install ventilation controller in an outdoor location and/or wet location.
• Do not obstruct or cover the fresh air intake or air outlet of the ventilation system.
• Provisions should be made for make-up air requirements based on recommendations set forth
by governing agency to meet applicable building codes and ventilation standards.
WARNING
• Sharp metal edges (ductwork) can cause serious injury from cuts.
• Wear appropriate gloves when cutting, drilling and grinding plenum openings and handling
ductwork.
• Wear appropriate eye protection when drilling, grinding and/or cutting ductwork.
FCMC PRODUCT SPECIFICATIONS:
Power
Input Voltage
Full Load Power
Idle Power
Wiring Requirements
Operating Temperature Range
Operating Humidity Range
Outputs
Fan Output GF
(Maximum Load Current)
Vent (V,V)
(Maximum Load Current)
16-32 VAC
1.28W @ 27.4VAC
270mW @ 27.4 VAC
18-22 AWG, 24 VAC (Min)
10°F to 160°F
5 to 95% RH (non-condensing)
8A inductive @30VAC
8A inductive @30VAC, or 30VDC
780110400 | RevA | 07/23
