- Page 1 INS02 TIGERFLEX® SHIPLAP APEX SHED GENERAL ASSEMBLY INSTRUCTIONS...
-
Page 2: Before You Get Started
BEFORE YOU GET STARTED PLEASE READ INSTRUCTIONS CAREFULLY • Check the pack and make sure you have all the parts listed. • When you are ready to start, make sure you have the right tools at hand (not supplied). • Ensure there is plenty of space and a clean, dry area for assembly. TIMBER As with all natural materials, timber can be affected during various weather conditions. - Page 3 Please retain instructions for future reference CRAFTED BY US, CONFIGURED BY YOU! The innovative modular design of the TIgerFlex ® range means that you can position the door and window panels (if applicable) where you want them to get the best light, best view, best access or most secure setting possible. As there are so many options, please note that while these instructions only show one popular configuration, the window, door and blank panels are interchangeable.
-
Page 4: Tools Required
BEFORE YOU GET STARTED TOOLS REQUIRED: We recommend using the following tools (not supplied): HAMMER RUBBER MALLET DRILL LADDER TAPE MEASURE SHARP KNIFE SPIRIT LEVEL SCREWDRIVER + WOOD SAW SEALANT GUN SEALANT FIXING KIT GUIDE: CN13 Clout Nails (13mm Galvanised - QTY 175) Screws (4x50mm - QTY 50) BS25... - Page 5 Please retain instructions for future reference TIGERFLEX® SHIPLAP APEX SHED GUIDANCE: This guide provides assembly information for the TigerFlex ® Apex Shed range. Images are for reference only and may vary from the product you have supplied. If you have any issues, please contact your supplier. CAUTI O N: CAUTI O N: Al l bui l d i n gs shoul d be erected...
- Page 6 BEFORE YOU GET STARTED - PRE ASSEMBLY What Is TigerFlex ® TigerFlex The original modular shed range, ® eds let you choose where you want to place the door and the windows, giving you the flexibility to decide how you want your shed to look and feel for your garden, for storage, for work or for leisure.
- Page 7 Please retain instructions for future reference CAUTI O N: CAUTI O N: FLOOR PLAN VIEW Al l bui l d i n gs shoul d be erected I t i s advi s abl e to wear gl o ves by two competent adul t s.
-
Page 8: Floor Panel Installation
TIGERFLEX SHIPLAP APEX GENERAL ASSEMBLY GUIDE ® Step 1: FLOOR PANEL INSTALLATION Lay out floor panels supplied as shown. • Single Floor model Shown for reference. • Check your product floor size for the correct diagram (opposite page) Please ensure floor panels are butted up tightly with no gaps (S90) Secure bearers to floor panel using 2x 90mm screws per bearer. - Page 9 Please retain instructions for future reference SINGLE FLOOR 2x3*, 3x3*, 4x3*, 4x4*, 4x6** CAUTI O N: CAUTI O N: Al l bui l d i n gs shoul d be erected I t i s advi s abl e to wear gl o ves by two competent adul t s.
-
Page 10: Side Panel Installation
TIGERFLEX SHIPLAP APEX GENERAL ASSEMBLY GUIDE ® Step 2: SIDE PANEL INSTALLATION Make sure transport blocks have been removed. (Detail A) NOTE - Hammer off sideways. Do not prise off. • Secure side panels to each other in corners using 3x 50mm (S50) screws per join. - Page 11 Please retain instructions for future reference SIDE PANEL SIDE PANEL SIDE PANEL CAUTI O N: CAUTI O N: Al l bui l d i n gs shoul d be erected I t i s advi s abl e to wear gl o ves by two competent adul t s.
-
Page 12: Door Installation
TIGERFLEX SHIPLAP APEX GENERAL ASSEMBLY GUIDE ® Step 3: BS25 2TBB DOOR INSTALLATION SINGLE DOOR: Place door in desired position. Door shown in right hand hinge position. • Leave approx 2mm gap at side between door and door panel. • Leave approx 6mm gap at top between door and door panel. - Page 13 Please retain instructions for future reference DOUBLE DOOR: Double Doors pre-fitted in workshop. CAUTI O N: CAUTI O N: • OPTIONAL: Extra corner strip supplied to be trimmed and installed as door cover piece. • Fit on outside of leading door to cover gap between both doors Al l bui l d i n gs shoul d be erected I t i s advi s abl e to wear gl o ves Secure to right hand door using 3x...
- Page 14 TIGERFLEX SHIPLAP APEX GENERAL ASSEMBLY GUIDE ® Step 3: BS25 2TBB DOOR INSTALLATION (cont.) SINGLE SECURITY DOOR (Fitting Security Bar External) • Check you have all components before starting. (Detail I) • Mark the position of the holes required for the hinge plate & drill a hole for the bolt (8mm / 5/16”). Secure large bolt through drilled hole.
- Page 15 Please retain instructions for future reference SINGLE SECURITY DOOR (Fitting Security Bar Internal) CAUTI O N: CAUTI O N: • Fix wooden blocks (same thickness as framing) before drilling & fixing (Detail N2) screws and bolts. • Due to different shed frame thicknesses, bolts supplied are to cover largest size.
- Page 16 TIGERFLEX SHIPLAP APEX GENERAL ASSEMBLY GUIDE ® Step 4: APEX GABLE TOP INSTALLATION • Fix Apex Gable Tops to the existing built structure. • The bottom of the gable top will slot into the top of the cladding on the panel below. Please ensure the gable top is positioned centrally above the side panels before screwing in place.
- Page 17 Please retain instructions for future reference Step 6: APEX ROOF PANEL INSTALLATION • Attach roof panels as shown. Hook roof panel purlin into Apex Gable Top. (Detail T1) • Before screwing roof panels into place, check there is an even overhang at both ends and that the panels are sitting square before securing along the apex/ridge.
- Page 18 TIGERFLEX SHIPLAP APEX GENERAL ASSEMBLY GUIDE ® Step 8: BARGE BOARD & FINIAL INSTALLATION • Fit Barge Boards to the roof, trapping overhanging end of the felt in between to create a weatherproof seal. (N40) • Secure together using 2x 40mm nails per Barge Board.
-
Page 19: Maintenance
3mm toughened glass pre-fitted as standard. All windows should ® be sealed both inside and out with a silicone or other watertight solution of your choice. We would recommend the Tiger Silicone & Gun Set available at tigersheds.com. CAUTI O N: CAUTI O N:... - Page 20 INS02 Display Agent Woodlands DIY Store Station Yard, Horsforth, Leeds, LS18 5NZ Telephone: 0113 205 4189 Website: tigersheds.com Email: customersupport@tigersheds.com...
