INS03
TIGERFLEX®
SHIPLAP APEX
BIKE SHED
GENERAL ASSEMBLY
INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TIGERFLEX SHIPLAP APEX BIKE SHED and is the answer not in the manual?

Questions and answers

Summary of Contents for Tiger TIGERFLEX SHIPLAP APEX BIKE SHED

  • Page 1 INS03 TIGERFLEX® SHIPLAP APEX BIKE SHED GENERAL ASSEMBLY INSTRUCTIONS...
  • Page 2: Before You Get Started

    BEFORE YOU GET STARTED PLEASE READ INSTRUCTIONS CAREFULLY • Check the pack and make sure you have all the parts listed. • When you are ready to start, make sure you have the right tools at hand (not supplied). • Ensure there is plenty of space and a clean, dry area for assembly. TIMBER As with all natural materials, timber can be affected during various weather conditions.
  • Page 3: Maintenance

    Please retain instructions for future reference ROOF COVERING OPTIONS All Tiger buildings are designed to use TigerFelt high grade poly-backed durable mineral roofing felt. If you have ® chosen a different roof covering option – such as EPDM rubberised roof covering or Shed Shingles, please see their separate roofing instructions available on their product pages at tigersheds.com.
  • Page 4: Tools Required

    BEFORE YOU GET STARTED TOOLS REQUIRED: We recommend using the following tools (not supplied): HAMMER RUBBER MALLET DRILL LADDER TAPE MEASURE SHARP KNIFE SPIRIT LEVEL SCREWDRIVER + WOOD SAW FIXING KIT GUIDE: Clout Nails CN13 (13mm Galvanised - QTY Screws (4x50mm - QTY 50) 175) BS25...
  • Page 5 Please retain instructions for future reference BUILDING PACK CONTENTS: For full details of what should be included please see the list that is supplied with the delivery. They are also available on request in pdf form from our helpful Customer Support team – please call 0113 2054189 for Customer Support or use the Items Delivered Query form at tigersheds.com/contact.
  • Page 6: Floor Panel Installation

    TIGERFLEX SHIPLAP APEX BIKE SHED ASSEMBLY GUIDE ® Step 1: FLOOR PANEL INSTALLATION • Install Heavy Duty Bearers as shown • Check your product floor size for the correct diagram (opposite page) Please ensure floor panels are butted up tightly with no gaps (S90) •...
  • Page 7 Please retain instructions for future reference SINGLE FLOOR 6x3*, 6x4* FLOOR PANEL MULTI FLOOR 6x5*, 6x6* FLOOR PANEL FLOOR PANEL...
  • Page 8: Side Panel Installation

    TIGERFLEX SHIPLAP APEX BIKE SHED ASSEMBLY GUIDE ® Step 2: SIDE PANEL INSTALLATION (Detail A) Make sure transport blocks have been removed. NOTE - Hammer off sideways. Do not prise off. • Secure blank back & blank side panel to each other in corners using 3x 50mm (S50) screws per joint.
  • Page 9 Please retain instructions for future reference SIDE PANEL SIDE PANEL FLOOR PANEL SIDE PANEL SIDE PANELS FLOOR JOIST FLOOR PANEL SIDE PANEL SIDE PANEL...
  • Page 10 TIGERFLEX SHIPLAP APEX BIKE SHED ASSEMBLY GUIDE ® Step 3: DOOR SIDE PANEL INSTALLATION • Assemble door side panel as shown. (Before affixing to the shed). (S50) (Detail F) • Screw door header to the left and right hand sides as shown using 50mm screws.
  • Page 11: Door Installation

    Please retain instructions for future reference Step 4: BS25 2TBB DOOR INSTALLATION • Lay assembled door side panel on a flat surface • Place doors into opening. (Detail H) • Leave approx. 4mm gap at side between door and side panel. •...
  • Page 12 TIGERFLEX SHIPLAP APEX BIKE SHED ASSEMBLY GUIDE ® Step 5: COMPLETED DOOR SIDE PANEL INSTALLATION • Secure completed door side panel to existing built structure as shown.. (S50) (Detail L) • Secure in corners using 3x 50mm screws provided per joint. (N65) (Detail M) •...
  • Page 13 Please retain instructions for future reference Step 6: APEX GABLE TOP INSTALLATION • Fix Apex Gable Tops to the existing built structure. • The bottom of the gable top will slot into the top of the cladding on the panel below. Please ensure the gable top is positioned centrally above the side panels before screwing in place.
  • Page 14 TIGERFLEX SHIPLAP APEX BIKE SHED ASSEMBLY GUIDE ® Step 8: CN13 FELT INSTALLATION • Roll out felt along lower part of roof, leaving sufficient overhang to fold down onto roof purlin, approx 75mm/3”. Do not fold underneath roof. (CN13) • Use clout nails to tack top of felt into the roof panel.
  • Page 15 Please retain instructions for future reference Step 10: COVER LAT & CORNER STRIP INSTALLATION • Fit Corner Strips in the corners of the shed, these are plain profiled pieces. • Secure to the shed using 3x 40mm (N40) nails per Corner Strip. (Detail Q) •...
  • Page 16 INS03 Display Agent Woodlands DIY Store Station Yard, Horsforth, Leeds, LS18 5NZ Telephone: 0113 205 4189 Website: tigersheds.com Email: customersupport@tigersheds.com...
