- Page 1 TIGERFLEX PENT BIKE STORE - ASSEMBLY GUIDE BEFORE YOU START : MAKE SURE ALL PARTS ARE SUPPLIED. CHECK BASE YOU ARE BUILDING ON IS FIRM & LEVEL. WEATHER CONDITIONS ARE FAVOURABLE FOR ASSEMBLING A SHED. WE WOULD RECOMMEND ASSEMBLY AS A 2 PERSON JOB.
- Page 2 TIGERFLEX PENT BIKE STORE - ASSEMBLY GUIDE BLANK SIDE FLOOR HEAVY DUTY TIMBER PANEL BLANK SIDE HEAVY DUTY TIMBER FLOOR PANEL HEAVY DUTY TIMBER HEAVY DUTY TIMBER BLANK SIDE NAIL THROUGH FLOOR INSTALLATION & SIDE PANEL ASSEMBLY. • INSTALL HEAVY DUTY TIMBER AS SHOWN.
- Page 3 TIGERFLEX PENT BIKE STORE - ASSEMBLY GUIDE BLANK SIDE BLANK SIDE BLANK SIDE BLANK SIDE BLANK SIDE NAIL THROUGH SCREW THROUGH SIDE PANEL ASSEMBLY. • SECURE BLANK SIDES TO EACH OTHER IN CORNERS USING 2X 50mm BLANK SIDE SCREWS PER JOIN. SEE DETAIL A.
- Page 4 TIGERFLEX PENT BIKE STORE - ASSEMBLY GUIDE DOOR HEADER DOOR SIDE LH DOOR SIDE RH DOOR BASE SCREW THROUGH DOOR PANEL ASSEMBLY. • SCREW HEADERS TO THE SIDES AS SHOWN (LH & RH) 50mm SCREWS - SCREW THROUGH SEE DETAIL C.
-
Page 5: Door Installation
TIGERFLEX PENT BIKE STORE - ASSEMBLY GUIDE DOOR HEADER DOOR RAIN COVER DROP BOLT DOOR TOP DETAIL MARK POSITION OF DROP BOLT ON DOOR HEADER AND DRILL HOLE DROP BOLT DOOR INSTALLATION. • LAY ASSEMBLED DOOR SIDE PANEL ON A FLAT SURFACE •... - Page 6 TIGERFLEX PENT BIKE STORE - ASSEMBLY GUIDE DOOR SIDE ASSEMBLY SEE SHEET 3 NAIL THROUGH DOOR ASSEMBLY INSTALL. • SECURE BLANK SIDES TO EACH OTHER IN CORNERS USING 2X 50mm SCREW THROUGH SCREWS PER JOIN. SEE DETAIL A. • SECURE PANELS TO FLOOR USING 65mm NAILS •...
- Page 7 TIGERFLEX PENT BIKE STORE - ASSEMBLY GUIDE ROOF PANEL PENT GABLE TOP RH 4FT HIGH SIDE TOP ROOF PANEL PENT GABLE TOP LH 2FT HIGH SIDE TOP FIX GABLE TOPS TO THE EXISTING BUILT STRUCTURE • SECURE THROUGH SIDE PANELS USING 2X 50mm SCREWS PER GABLE TOP FIX HIGH SIDE TOPS TO THE EXISTING BUILT STRUCTURE •...
- Page 8 TIGERFLEX PENT BIKE STORE - ASSEMBLY GUIDE SIDE BARGE BOARD 2x SOFIT BOARDS (FRONT BARGE BOARD TRIMMED TO SIZE) FRONT BARGE BOARD SIDE FINIAL BARGE BOARD BARGE BOARDS & FINIAL ASSEMBLY FELT THE ROOF • FIT BARGE BOARDS TO THE ROOF, TRAPPING OVERHANGING END OF •...
- Page 9 TIGERFLEX PENT BIKE STORE - ASSEMBLY GUIDE COVER LATS COVER LAT COVER LAT COVER LATS & CORNER STRIPS • USE 3x 40mm NAILS TO SECURE IN PLACE - MAKE SURE JOIN IS COVERED • COVER LATS & CORNER STRIPS WILL NEED TRIMMING TO SUIT.
